OUTDOOR PROPANE FIREPIT
Model#:
62133
Item#:
BBQ-211-BK
FOR YOUR SAFETY
If you smell gas:
1. Shut off gas to the appliance
2. Extinguish any open flame
3. If odor continues, immediately
call gas supplier.
FOR YOUR SAFETY
Do not store or use gasoline or
other flammable vapors or liquids
in the vicinity of this or any other
appliance.
OWNER'S MANUAL
Heat Max output: 60,000BTU
WARNING: For outdoor use only.
PLEASE retain this manual for
future reference.
Conforms to ANSI
STD. Z21.97
Certified to CSA
STD. 2.41
5 0 0 5 2 2 3
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for JR Home BBQ-211-BK
Summary of Contents for JR Home BBQ-211-BK
- Page 1 OUTDOOR PROPANE FIREPIT OWNER’S MANUAL Heat Max output: 60,000BTU Model#: 62133 Item#: BBQ-211-BK FOR YOUR SAFETY WARNING: For outdoor use only. If you smell gas: 1. Shut off gas to the appliance 2. Extinguish any open flame PLEASE retain this manual for 3.
-
Page 2: Safety Information
SAFETY INFORMATION DANGER DANGER • EXPLOSION - FIRE HAZARD • CARBON MONOXIDE HAZARD • Keep solid combustibles, such as building materials, • This fire pit is a combustion appliance. All combustion paper or cardboard, a safe distance away from the appliances produce carbon monoxide (CO) during the fire pit as recommended by the instructions. - Page 3 SAFETY INFORMATION WARNING WARNING California Proposition 65 Combustion by-products produced when using is invisible, odorless, and flammable. An odorant is this product contain chemicals known to the State normally added to help detect leaks and can be of California to cause cancer, birth defects, and described as a rotten egg smell.
-
Page 4: Package Contents
PACKAGE CONTENTS PART DESCRIPTION QUANTITY Bakelite Handle Fire Ring Fire bowl Buckle Fire Bowl Base Isolation Plate Ignition Box Control Valve Valve Base Ignition Button Isolation Plate Support Ignition Needle Ignition Cap Folding leg 3.3lbs Lava Rocks Regulator and Hose Assembly Tank Stand... - Page 5 ASSEMB LY INSTRUCTIONS 1.Assemble the control Knob by inserting the ignition cap onto the ignition needle. 2. Assemble the handle on the lid by screw and nuts. 3. Add the Lava Rocks （P）. 4.Connect the hose and regulator to the cylinder. Put cylinder on the cylinder stand.Use a standard 20 lb.
- Page 6 ASSEMBLY INSTRUCTIONS A dented , rusted or damaged propane cylinder may be hazardous and should be checked by your cylinder supplier. Never use a p ropane cylinder with a damaged valve connection. The propane cylinder must be constructed and ma rked in accordance with the specifications for LP gas cylinders of the U.S.
- Page 7 NEVER perform a leak test when smoking. Underside of burner...
- Page 8 Remove the lid...
- Page 9 OPERATION INSTRUCTIONS WARNING FOR YOUR SAFETY Be careful when attempting to manually ignite this fire pit. holding in the control knob for more than 10 seconds before igniting the gas will cause a ball of flame upon ignition. When fire pit is ON: Burner will display tongues of blue and yellow flame.
-
Page 10: Care And Maintenance
OPERATION INSTRUCTIONS 9. Fire pit is away from gasoline or other flammable liquids or vapors. 10. Fire pit is away from windows, air intake openings, sprinklers and other water sources. 11. Fire pit is at least 24 in. on rear and at least 24 in. on sides from combustible materials. 12. - Page 11 Cover fire pit to protect exterior surfaces and to help prevent build-up in air passages. Caution: Always allow fire pit to cool before attempting service.
-
Page 13: Warranty
Light bulbs and fuses are not covered under this warranty. If you have any questions regarding the warranty or service, please contact us at customercare@jrhome.com. Customer Service: JR Home Products Unit 306 - 19100 Airport Way, Pitt Meadows, BC V3Y 0E2 Toll Free: 1-800-561-5550 E-mail: customercare@jrhome.com...
