OUTDOOR PROPANE FIREPIT
Model#: FR1010-T-72
Item#: FP-303
FOR YOUR SAFETY
If you smell gas:
1. Shut off gas to the appliance
2. Extinguish any open flame
3. If odor continues, immediately
call gas supplier.
FOR YOUR SAFETY
Do not store or use gasoline or
other flammable vapors or liquids
in the vicinity of this or any other
appliance.
ANSI Z21.97-2014, CSA STD 2.41-2014 Outdoor Decorative Gas Appliances
OWNER'S MANUAL
R
WARNING: For outdoor use only.
PLEASE retain this manual for
future reference.
For cus tomer service, parts
or warranty issues:
Call 1-800-561-5550 or e-mail
customercare@jrhome.com
R
C
US
R
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FR1010-T-72 and is the answer not in the manual?

Questions and answers

Related Manuals for JR Home FR1010-T-72

Summary of Contents for JR Home FR1010-T-72

  • Page 1 OUTDOOR PROPANE FIREPIT OWNER’S MANUAL Model#: FR1010-T-72 Item#: FP-303 FOR YOUR SAFETY WARNING: For outdoor use only. If you smell gas: 1. Shut off gas to the appliance 2. Extinguish any open flame PLEASE retain this manual for 3. If odor continues, immediately future reference.

  • Page 2: Package Contents

    PACKAGE CONTENTS latch hole hole PART DESCRIPTION QUANTITY Door Frame) Side Panel 4 Bolt 6 22mm Washer Bolt 8 40mm Nut M8 Washer Spring Washer Bolt 6 25mm Washer Allen Conneting Rod Gas Tank Bracket (side) Gas Tank Support (bottom) Glass Beads 2boxes/4bags Protective Fire Pit Cover...

  • Page 3: Hardware Contents

    HARDWARE CONTENTS Bolt(8*40mm) Bolt (6*25mm) Bolt (6*22mm) Nut(M8) Washer Washer Washer Qty. 4 Qty. 8 Spring washer Qty. 4 Wrench Screwdriver Qty 1 Allen wrench SAFETY INFORMATION Please read and understand this entire manual before attempting to assemble, operate or install the product.
  • Page 4 SAFETY INFORMATION DANGER DANGER • EXPLOSION - FIRE HAZARD • CARBON MONOXIDE HAZARD • Keep solid combustibles, such as building materials, • This fire pit is a combustion appliance. All combustion paper or cardboard, a safe distance away from the appliances produce carbon monoxide (CO) during the fire pit as recommended by the instructions.

  • Page 5: Burn Hazard

    SAFETY INFORMATION WARNING WARNING California Proposition 65 • This product is fueled by propane gas. Propane gas Combustion by-products produced when using is invisible, odorless, and flammable. An odorant is this product contain chemicals known to the State normally added to help detect leaks and can be of California to cause cancer, birth defects, and described as a rotten egg smell.
  • Page 6 ASSEMB LY INSTRUCTIONS 1.Connect Side Panels D E FG with Bolt (6 *25mm)/ Washer (J) as shown in Figure 1 using Allen Wrench . (NOTE:Don't over tighten the bolt.) (The two holes help fix the Gas Tank Bracket and Gas Tank Support in step 2.) Hardware Used hole2...
  • Page 7 ASSEMB LY INS TRUCTIONS 3. Attach the 4 - Bolt(8*40mm) (I) to the holes of the Table Top (C). Then align the Bolts with the holes in the assembled panels. Attach the Table Top to the assembled panels with 4 - Washer/Spring Washer/Nuts (I). NOTE:Tighten all the Bolts and Nuts.
  • Page 8 ASSEMB LY INSTRUCTIONS 5. Pour the Glass Beads (Q) around the Burner (B). Put the Burner Cover (A) on the Burner when the fire pit table is NOT in use. When the fire pit is completely cool, you may cover it with Protective Fire Pit Cover (R).
  • Page 9 ASSEMBLY INSTRUCTIONS A dented , rusted or damaged propane cylinder may be hazardous and should be checked by your cylinder supplier. Never use a p ropane cylinder with a damaged valve connection. The propane cylinder must be constructed and ma rked in accordance with the specifications for LP gas cylinders of the U.S.
  • Page 10 NEVER perform a leak test when smoking. Underside of burner...

  • Page 12: For Your Safety

    OPERATION INSTRUCTIONS WARNING FOR YOUR SAFETY Be careful when attempting to manually ignite this fire pit. olding in the control knob for more than 10 seconds before igniting the gas will cause a ball of flame upon ignition. When fire pit is ON: Burner will display tongues of blue and yellow flame.

  • Page 13: Care And Maintenance

    OPERATION INSTRUCTIONS 9. Fire pit is away from gasoline or other flammable liquids or vapors. 10. Fire pit is away from windows, air intake openings, sprinklers and other water sources. 11. Fire pit is at least 24 in. on rear and at least 24 in. on sides from combustible materials. 12.
  • Page 14 Caution: Always allow fire pit to cool before attempting service.

  • Page 16: Warranty

    Light bulbs and fuses are not covered under this warranty. If you have any questions regarding the warranty or service, please contact us at customercare@jrhome.com. Customer Service: JR Home Products Unit 306 - 19100 Airport Way, Pitt Meadows, BC V3Y 0E2 Toll Free: 1-800-561-5550 E-mail: customercare@jrhome.com...
