- Page 1 ION TPS Mobile Mobile All-In-One Terminal User's Manual...
- Page 2 Copyright 2017 All Rights Reserved Manual Version 1.0 Part Number: ION-TP5M, ION-TP5N The information contained in this document is subject to change without notice. We make no warranty of any kind with regard to this material, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose.
-
Page 3: Fcc Radiation Exposure Statement
FCC Radiation Exposure Statement This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation. - Page 4 LEGISLATION AND WEEE SYMBOL 2012/19/EU Waste Electrical and Electronic Equipment Directive on the treatment, collection, recycling and disposal of electric and electronic devices and their components. The crossed dust bin symbol on the device means that it should not be disposed of with other household wastes at the end of its working life.
-
Page 5: Revision History
Revision History Changes to the original user manual are listed below: Revision Description Date • Initial release August, 2017... -
Page 6: Table Of Contents
Table of Contents 1. Packing List ........1 1-1. Standard Contents .............1 2. System View ........2 2-1. Tablet................... 2-2. Tablet with Printer Stand........... 2-3. Tablet with Stand..............2-4. Dimensions................. 2-5. Port View................3. System Assembly & Disassembly 7 3-1. Install Tablet to Printer Stand..........7 3-2. - Page 7 The page is intentionally left blank.
-
Page 8: Packing List
Packing List 1-1. Standard Contents a. ION-TP5 Mobile System b. Power adapter c. Power cord d. RJ45-DB9 cable (x2) -
Page 9: System View
System View 2-1. Tablet Item No. Description Power button Top peripheral cover Camera Hand strap Speakers Base contacts Side peripheral cover... -
Page 10: Tablet With Printer Stand
2-2. Tablet with Printer Stand Item No. Description Power button Tablet Tablet release button Thermal printer Paper door button Printer indicator (power, error, and paper) & Paper feed button USB Port Back cover (Ports and printer inside... -
Page 11: Tablet With Stand
2-3. Tablet with Stand Item No. Description Power button Tablet Tablet release button USB Port Back cover (Ports inside) -
Page 12: Dimensions
2-4. Dimensions 10.28" 0.94" 10.28" 7.44"... -
Page 13: Port View
2-5. Port View Item Description RJ11 Cash Drawer RJ45 LAN 2x USB 2.0 RJ 45 COM USB 2.0 19V DC Power in... -
Page 14: System Assembly & Disassembly
System Assembly & Disassembly 3-1. Install Tablet to Stand 1. Slide the tablet into the stand as shown. 3-2. Connect the Power Adapter 1. Use both hands to pull the back cover of the system upward to remove the cover from the system. - Page 15 2. Place the system face down to access the bottom of the stand. 3. Thread the power adapter cable through the hole of the stand as shown in the picture. 4. The power connector is on the right side of the ports (refer to chapter 2-4 c.) and connect the power adapter to the green 19V in port.
-
Page 16: Remove Tablet From The Stand
3-3. Remove tablet from the stand 1. Push the release button on the printer stand and then pull the tablet upward to release it from the stand. * Please note you can only remove the tablet from the stand when the locking switch on the stand is in the "unlock"... - Page 17 3. Wait a few seconds while the tablet unlocks. 4. Once it says "Unlock", press the button on the base and remove the tablet.
-
Page 18: Load The Thermal Printer Paper
3-4. Load the Thermal Printer Paper Note: Do not switch off the system. The printer must be powered on when replacing the printer paper. 1. Press the button on the right side to open the printer door. Cut away the first inch of the paper, to obtain a straight edge and remove the label at the end of the roll. -
Page 19: Specifications
Specifications ION-TP5M/N Model Intel Atom Z3745 Quad Core up to 1.86GHz 4GB DDR3L RAM / 64GB Storage System memory LCD touch panel LCD size 10.1" Maximal resolution 1280 x 800 Touch screen type P-CAP 5 points Multi-touch Wireless communication Wireless LAN 802.11 a/b/g/n , 2.4G / 5GHz Bluetooth 4.0+LE (Class 2, 10 meters) -
Page 20: Jumper Settings
Jumper Settings Cash Drawer Power Setting Function +12V ▲+24V COM Power Setting Function ▲+0V +12V ▲ = Manufacturer Default Setting Jumper open Jumper short...
