- Page 1 ION TP5 All-In-One Terminal User’s Manual v1.2...
- Page 2 Copyright 2015 All Rights Reserved Manual Version 1.2 Part Number: TP5 The information contained in this document is subject to change without notice. We make no warranty of any kind with regard to this material, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose. We shall not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this material.
- Page 3 CE MARK This device complies with the requirements of the EEC directive 2004/108/EC with regard to “Electromagnetic compatibility” and 2006/95/EC “Low Voltage Directive”. This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference.
- Page 4 LEGISLATION AND WEEE SYMBOL 2012/19/EU Waste Electrical and Electronic Equipment Directive on the treatment, collection, recycling and disposal of electric and electronic devices and their components. The crossed dust bin symbol on the device means that it should not be disposed of with other household wastes at the end of its working life.
- Page 5 USER INFORMATION REQUIREMENTS Products shall be shipped with informational materials to notify customers of the following: 1. A description of power management settings that have been enabled by default. 2. A description of the timing settings for various power management features and instructions for properly waking the product from Sleep Mode.
-
Page 6: Revision History
Revision History Changes to the original user manual are listed below: Revision Description Date • Initial release July 2015 • Instruction on locking the back cover added April 2016 • Instruction on installing the LCM module added • Rear 8” LCD installation instructions and specifica- September 206 tions added... -
Page 7: Table Of Contents
Table of Contents 1. Packing List ......1 1-1. Standard Accessories ..........1 1-2. Optional Accessories ..........2 2. System View ......3 2-1. Front View ...............3 2-2. Side View ..............5 2-3. IO Port View ............6 3. Assembly & Disassembly ..7 3-1. - Page 8 6. Jumper Settings ...... 16 6-1. Printer Board Settings ..........16 Appendix: Driver Installation ..17 viii...
- Page 9 The page is intentionally left blank.
-
Page 10: Packing List
Packing List 1-1. Standard Accessories a. TP5 System b. Power adapter c. Power cord d. RJ45-DB9 cable (x1) e. Driver CD... -
Page 11: Optional Accessories
1-2. Optional Accessories a. MSR module b. LCM module c. Rear LCD module... -
Page 12: System View
System View 2-1. Front View TP5E View angle of 0 degrees Item No. Description MSR module Thermal printer open door button Thermal printer Printer indicator(power, error, and paper) & Paper feed button... - Page 13 TP5F View angle of 0 degrees Item No. Description MSR module...
-
Page 14: Side View
2-2. Side View TP5E TP5F Item No. Description MSR module System cover (IO board and thermal printer inside on TP5E) -
Page 15: Io Port View
2-3. IO Port View TP5E Item No. Description Cash Drawer USB 2.0 (x2) COM port USB 2.0 DC 19V in TP5F Item No. Description USB 2.0 (x2) COM port USB 2.0 DC 19V in... - Page 16 2-4. Dimensions TP5E 370.6 mm 196.6 mm 363.3 mm 165 mm 350 mm 188.9 mm TP5F 365.6 mm 196.6 mm 363.3 mm 105 mm 350 mm 188.9 mm...
-
Page 17: Assembly & Disassembly
Assembly & Disassembly 3-1. Unlocking the Back Cover 1. On some models the back cover of the system is secured by two locking screws which are located at the bottom of the stand. 2. To open the back cover, place the system face down, Insert a flat head screwdriver or a small coin into the groove of the screw and turn to the Unlock position to unlock. -
Page 18: Installing The Power Adapter
3-3. Installing the Power Adapter The system is equipped with a 90W power adapter. Please connect it to the system as shown below. 1. Follow the steps decribed in Chapter 3-1 to remove the rear housing. 2. Place the system face down to access the bottom of the stand. -
Page 19: Peripheral Installation
Peripheral Installation 4-1. Installing the MSR 1. Remove the dummy cover. 2. Connect the MSR cable to the connector on the system side. 3. Put the MSR module in place and fasten the screws (x2) on the back to secure the module. -
Page 20: Installing The Lcm Module
4-2. Installing the LCM Module 1. Follow the steps decribed in Chapter 3-1 and 3-2 to open the back cover of the system, then remove the LCM cover from the back housing. 2. Attach the LCM module and fasten the screws (x4). 3. -
Page 21: Loading The Thermal Printer Paper
4-3. Loading the Thermal Printer Paper 1. Press the button on the right side to open the thermal printer module. 2. Place the paper roll inside the printer slot, pull out a length of paper and then close the cover over the end of the paper. -
Page 22: Installing The Rear Lcd Module
4-4. Installing the Rear LCD Module 1. Follow the steps decribed in Chapter 3-1 and 3-2 to open the back cover of the system, then remove the LCM cover from the back housing. 2. Attach the rear LCD display module and fasten the screws (x4). 3. -
Page 23: Specifications
Specifications... -
Page 25: Jumper Settings
Jumper Settings 6-1. Printer Board Settings Printer Board ON=Down OFF=Up Hardware Reset Function Normal * N/C Reset Interface Select... - Page 26 Appendix: Driver Installation The shipping package includes a Driver CD, where all drivers and utilities can be found. Please insert the Driver CD into a computer with a CD drive and open the “index.htm” file and select the terminal model. For more information please visit www.pos-x.com...
