  • Page 1 EVO TP6W All in One POS Terminal User Manual v1.0...
  • Page 2 Copyright 2020 All Rights Reserved Manual Version 1.0 The information contained in this document is subject to change without notice. We make no warranty of any kind with regard to this material, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose. We shall not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this material.
  • Page 3 CE MARK This device complies with the requirements of the EEC directive 2014/30/EU with regard to “Electromagnetic compatibility” and 2014/35/EU “Low Voltage Directive”. This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference.
  • Page 4 LEGISLATION AND WEEE SYMBOL 2012/19/EU Waste Electrical and Electronic Equipment Directive on the treatment, collection, recycling and disposal of electric and electronic devices and their components. The crossed dust bin symbol on the device means that it should not be disposed of with other household wastes at the end of its working life.
  • Page 5 Revision History Changes to the original user manual are listed below: Revision Description Date • Initial release January 2020...

  • Page 6: Table Of Contents

    Table of Contents 1. Packing List ........1 1-1. Standard Accessories .............1 1-2. Optional Accessories ............2 2. System View ........3 2-1. Front & Side View ............3 2-2. Rear View .................3 2-3. IO Ports View..............4 2-4. System Dimensions ............5 3. System Assembly & Disassembly 6 3-1.
  • Page 7 ........ 14 ....... 16 6- 1. D86U Motherboard ............16 6-1-1. Motherboard Layout ............16 6-1-2. Connectors & Functions ..........17 6-1-3. Jumper Setting ..............18...
  • Page 8 The page is intentionally left blank. viii...

  • Page 9: Packing List

    Packing List 1-1. Standard Accessories a. System b. Power adapter c. Power cord d. RJ45-DB9 cable (x2)

  • Page 10: Optional Accessories

    1-2. Optional Accessories a. MSR b. Fingerprint reader c. LCD 2nd display d. 2-line Customer display...

  • Page 11: System View

    System View 2-1. Front & Side View Description Touch screen Fingerprint (option) MSR (option) Power button Stand front cover Stand 2-2. Rear View Description VESA top cover Cable cover...

  • Page 12: Io Ports View

    2-3. IO Ports View D86U Motherboard f g h Description HDD slot Power button DC 19V in COM 1, 2, 3 (from right to left) USB 2.0 x 2 Cash drawer USB 3.0 x 4...

  • Page 13: System Dimensions

    2-4. System Dimensions 19.9" 18.1" 8.5" 8"...

  • Page 14: System Assembly & Disassembly

    System Assembly & Disassembly Disassemble the Stand 3-1. 1. Loosen the thumb screw (x1) and slide the stand towards the IO panel to release it from the system. 2. Reverse the steps above to attach stand to the system. 3-2. Remove the Cable Cover 1.

  • Page 15: Install The Power Adapter

    Install the Power Adapter 3-4. The system is equipped with a 90W power adapter. Please follow the steps to install the power adapter. 1. The stand is designed to allow for clean cable management. There is a cable channel through the stand, which has a quick access cover. Please pull the front cover of the stand outwards.

  • Page 16: Peripheral Installation

    Peripheral Installation Install the MSR Module 4-1. 2. Insert the MSR module in place and fasten the screws (x2) on the back to secure the module.

  • Page 17: Install The Fingerprint Module

    Install the Fingerprint Module 4-2. 2. Insert the Fingerprint module in place and fasten the screws (x2) on the back to secure the module.

  • Page 18: Install The Customer Display

    Install the Customer Display 4-3. 1. Follow the steps in Chapter 3-1 to diassemble the stand from the LCD panel. 2. Remove the thumb screw (x1) from the VESA top cover and then pull the cover 3. Attach the LCM module to system by fastening the thumb screw (x1). 4.

  • Page 19: Install The Second Display

    Install the Second Display 4-4. 1. Follow the steps in Chapter 3-1 to diassemble the stand from the LCD panel. 2. Remove the thumb screw (x1) from the VESA top cover and then pull the cover up. 3. Attach the 10.1"' 2 display module to system by fastening the thumb screw (x1).

  • Page 20: Cash Drawer Installation

    4-5. Cash Drawer Installation You can install a cash drawer through the cash drawer port. Please verify the pin assignment before installation. Cash Drawer Pin Assignment Signal Cash drawer 2 In Cash drawer 1 Out Cash drawer 1 In 12V / 19V (or 24V) Cash drawer 2 Out Cash Drawer Controller Register The Cash Drawer Controller use one I/O addresses to control the Cash Drawer.
  • Page 21 Bit 7: Reserved Bit 6: Reserved Bit 5: Reserved Bit 4: Cash Drawer 1 pin output control. = 1: Opening the Cash Drawer = 0: Allow close the Cash Drawer Bit 3: Cash Drawer 1 pin input control. = 1: the Cash Drawer closed or no Cash Drawer = 0: the Cash Drawer opened Bit 2: Reserved Bit 1: Reserved...
  • Page 22 Model Name EVO TP6W Mainboard D86U i3-6100U 2.3GHz, LLC 3M(15W, EIA) CPU support 1x DDR3L SO-DIMM up to 8GB, System memory 1600MHz Graphic memory Intel HD graphic (Gen 9) DX12 and OCL4.2 LCD Touch Panel LCD size 18.5” LED (1 CH LVDS) Brightness (cd/m²)
  • Page 23 Model Name EVO TP6W Mainboard D86U Storage temperature -4°F ~ 140°F (-20°C ~ 60°C) Humidity 20% ~ 85% RH non-condensing 100mm x 100mm VESA standard holes Note: The VESA hole is a through hole and the screw type is required to be M4 x 4.0mm. DO NOT...

  • Page 24: D86U Motherboard

    6-1. D86U Motherboard 6-1-1. Motherboard Layout SATA1 USB3 RJ45_1 SATA0 CN21 USB2 SKT1 CN19 CN22 CN15 USB1 CN23 MINI_PCIE1 CN10 CN20 SKT2 JP1 CN4 CN24 DDR3_A1 CN28 CN17 CN25...

  • Page 25: Connectors & Functions

    6-1-2. Connectors & Functions Connector Function Front I/O board HDD LED connector USB connector System FAN connector LPT port connector Smart device connector Debug port CN10 Speaker & MIC connector CN11 40 pin external connector CN12 Audio connector(right) CN13 Audio connector(left) CN14 CN15 two color LED...

  • Page 26: Jumper Setting

    6-1-3. Jumper Setting Cash Drawer Power Setting Function COM1/COM2/COM3 Power Setting COM1, COM2 and COM3 can be set to provide power to your serial device. 1. Power on the system, and press the <DEL> key when the system is booting up to enter the BIOS Setup utility.
  • Page 27 LCD ID Setting LVDS Output Panel# Resolution Bits Channel Interface LVDS 800 x 600 Single Panel LVDS 800 x 600 Single Panel LVDS 1024 x 768 Single Panel LVDS 1024 x 768 Single Panel LVDS 1366 x 768 Single Panel LVDS 1366 x 768 Single...
