Quick Installation Guide
Hitachi Travelstar Z5K500
7mm z-height Hard Disk Drive
Models:
HTS545050A7E380
HTS545032A7E380
HTS545025A7E380
HTS545050A7E381
HTS545032A7E381
HTS545025A7E381
HTE545050A7E380
HTE545032A7E380
Handling precautions
Set the drive down gently to prevent damage from impact or vibration.
Handle the drive carefully by the edges. Do not touch the exposed printed circuit board
or any electronic components.
Do not press on the top or bottom of the drive.
Before handling the drive, discharge any static electricity from yourself and your
clothing. With one hand touch an unpainted metal surface, then touch the ESD bag with
the other hand. Remain in contact with the chassis and the bag for a minimum of two
seconds.
Vibration, shock and static electricity to the drive will damage the precision parts. In
particular, prevent vibration or shock generated by dropping, knocking over or hitting
the drive. Also, avoid touching the electrical components directly, which can discharge
electrostatic energy and damage the drive.
Page 1
version 1.0
Advertisement
Related Manuals for Hitachi Travelstar Z5K500
Summary of Contents for Hitachi Travelstar Z5K500
- Page 1 Quick Installation Guide Hitachi Travelstar Z5K500 7mm z-height Hard Disk Drive Models: HTS545050A7E380 HTS545032A7E380 HTS545025A7E380 HTS545050A7E381 HTS545032A7E381 HTS545025A7E381 HTE545050A7E380 HTE545032A7E380 Handling precautions Set the drive down gently to prevent damage from impact or vibration. Handle the drive carefully by the edges. Do not touch the exposed printed circuit board or any electronic components.
- Page 2 Hitachi Global Storage Technologies Mounting Recommendations The mounting hole locations and size of the drive are shown in the following illustration: Page 2 version 1.0...
- Page 3 Hitachi Global Storage Technologies The drive will operate in all axes (six directions) and will stay within the specified error rates when tilted ±5 degrees from these positions. Performance and error rate will stay within specification limits if the drive is operated in the other permissible orientations from which it was formatted.
- Page 4 Hitachi Global Storage Technologies’ trademarks are authorized for use in countries and jurisdictions in which Hitachi has the right to use, market and advertise the brands. The Travelstar trademark is authorized for use in the Americas, EMEA and the following Asia-Pacific countries and jurisdictions: Australia, Hong Kong, Japan, New Zealand, South Korea and Taiwan.
