AVE VI2F-PE1 System Manual

Video intercom 2-wire system
Hide thumbs Also See for VI2F-PE1:

Advertisement

Quick Links

Download this manual
Video intercom
2-wire system
SYSTEM MANUAL
Manual 2-wire video intercom system AVE V44 EASY Rev.015
2025/05/22
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the VI2F-PE1 and is the answer not in the manual?

Questions and answers

Related Manuals for AVE VI2F-PE1

Summary of Contents for AVE VI2F-PE1

  • Page 1 Video intercom 2-wire system SYSTEM MANUAL Manual 2-wire video intercom system AVE V44 EASY Rev.015 2025/05/22...
  • Page 2 Bus cable item VI2F-CV ........................ 39 CONNECTING DEVICES ............................ 40 OUTDOOR STATIONS .......................... 40 In-wall outdoor stations item VI2F-PE1, VI2F-PE2, VI2F-PE4 ............40 Wall-mounted outdoor stations item VI2F-PE1AP, VI2F-PE2AP ..........40 1.3 4-call (VI2F-PEAUX4) and 8-call (item VI2F-PEAUX) auxiliary outdoor columns ....... 41 Outdoor station model Building item VI2F-PE7T ................
  • Page 3 ANSWERING A CALL ..........................73 DOOR OPENER FUNCTION ........................74 AUTOMATIC DOOR OPENER FUNCTION (Doctor' s Office Function) ..........75 INTERCOM CALL ..........................75 MUTE MODE (Mute function) ......................75 Manual 2-wire video intercom system AVE V44 EASY Rev.015 2025/05/22...
  • Page 4 INVITING NEW USERS TO YOUR SYSTEM (SYSTEM SHARING) ............96 DELETING AN ACCOUNT ........................98 ANSWERING A CALL ..........................99 INTERFACING CONFIGURATION OF THE ADVANCED AVE RANGE .............. 101 SYSTEM CONFIGURATION..........................102 2-WIRE SYSTEM PRODUCT OVERVIEW TABLE ................. 102 SINGLE-FAMILY VIDEO INTERCOM SYSTEM ................103 1.2 SINGLE-FAMILY VIDEO INTERCOM SYSTEM WITH WI-FI MONITOR ..........
  • Page 5 Manual 2-wire video intercom system AVE V44 EASY Rev.015 2025/05/22...
  • Page 6 In the case of the sale of AVE S.p.A. products in the countries of the European Union, the Purchaser undertakes to check that the instructions for use of the product in the AVE S.p.A. packaging contain the specific language of the country of destination.
  • Page 7 The AVE video-intercom system complies with the strictest product standards both as regards performance and safety requirements and compliance with the relevant environmental tests. It also contains advanced video surveillance functions (which can be activated during installation of the system) that may be subject to Regulation 679/2016 ("GDPR") and the General Provision of the Video surveillance authority of 8 April 2010.
  • Page 8 Indoor station with 5” LCD item VI2F-PIT5B Indoor station with 7" LCD touch screen display item VI2F-PIT7B Indoor station with 7" LCD touch screen display - Wi-Fi item VI2F-PIT7WF Intercom handset item VI2F-PICAB Manual 2-wire video intercom system AVE V44 EASY Rev.015 2025/05/22...
  • Page 9 Replacement slide for the VI2F-PE4 4-call outdoor station item VI-VTRPE4 Replacement slide for the VI-PEAUX 8-call auxiliary outdoor station item VI-VTRPEAUX Replacement slide for the VI-PEAUX4 4-call auxiliary outdoor station item VI-VTRPEAUX4 Manual 2-wire video intercom system AVE V44 EASY Rev.015 2025/05/22...
  • Page 10 VI-BOX6 VI-BOX4 Rain canopy, item VI-RPBOX3 VI-RPPEXAP VI-RPBOX3 VI-RPPEXAP VI-RPBOX3 VI-RPBOX5 VI-RPBOX3 ■ ■ ■ ■ ■ Multiple installation with VI-PEAUX ■ ■ ■ ■ ■ Multiple installation with VI-PEAUX4 Manual 2-wire video intercom system AVE V44 EASY Rev.015 2025/05/22...
  • Page 11 To access the name plates, proceed as follows: VI2F-PE1-2-4 BUILT-IN OUTDOOR STATIONS : remove the front plate by unscrewing the screw at the bottom of the device, lifting the glass frame and pulling the lower part towards you.
  • Page 12 Mount the outdoor station by first anchoring it to the lugs at the top and then slide the indoor station into the box. Secure the product to the box using the 2 screws supplied with the indoor station. Manual 2-wire video intercom system AVE V44 EASY Rev.015 2025/05/22...
  • Page 13 1.3 1-call outdoor station item VI2F-PE1 The VI2F-PE1 device is an in-wall or wall-mounted audio/video outdoor station (using the VI- BOX4 box) of the AVE V44 EASY 2-wire video intercom system. The device is equipped with 1 name tag associated with 1 call button.
  • Page 14 1.4 1-call wall-mounted outdoor station item VI2F-PE1AP The VI2F-PE2AP device is a wall-mounted audio/video outdoor station of the AVE V44 EASY 2-wire video intercom system. The device is equipped with 1 call button with corresponding name tag. Access to the tags is possible by unscrewing the screws at the bottom of the device and lifting the device cover.
  • Page 15 1.5 2-call outdoor station item VI2F-PE2 The VI2F-PE2 device is an in-wall or wall-mounted audio/video outdoor station (using the VI- BOX4 box) of the AVE V44 EASY 2-wire video intercom system. The device is equipped with 2 name tags associated with the 2 call buttons.
  • Page 16 1.6 2-call wall-mounted outdoor station item VI2F-PE2AP The VI2F-PE2AP device is a wall-mounted audio/video outdoor station of the AVE V44 EASY 2-wire video intercom system. The device is equipped with 2 call buttons with corresponding name tags. Access to the tags is possible by unscrewing the screws at the bottom of the device and lifting the device cover.
  • Page 17 1.7 4-call outdoor station item VI2F-PE4 The VI2F-PE4 device is the audio/video outdoor station of the AVE V44 EASY 2-wire video intercom system. The device is equipped with 4 name tags associated with the 4 call buttons. The tags can be accessed by unscrewing the central screw at the bottom of the device and then removing the glass cover plate by pulling the lower part outwards.
  • Page 18 1.8 8-call auxiliary outdoor column item VI-PEAUX The VI-PEAUX device allows adding 8 buttons to expand the number of call buttons in the outdoor station. The device is common to the 2-wire Domina Video intercom AVE V44 EASY and IP AVE V44 SMART ranges.
  • Page 19 If a 4-button auxiliary column (item VI-PEAUX4) is installed, the system will still count 8 buttons assigned to it (e.g. installation VI2F-PE1 + 1 x VI-PEAUX4 + 1 x VI-PEAUX: button address on the main outdoor station 1, button addresses on the 4-button auxiliary column from 2 to 9, button addresses on the 8-button auxiliary column from 10 to 17).
  • Page 20 1.10 Outdoor station model Building item VI2F-PE7T The VI2F-PE7T device is the Audio/Video Outdoor Station of the 2-Wire DOMINA AVE V44 EASY video intercom system equipped with a 7" Touch Screen LCD monitor. The technical specifications of the outdoor station with 7" LCD are given here below:...
  • Page 21 Installation on box 2501, horizontal centre ■ distance 60 mm Installation on 2502 box ■ Installation on 2503 horizontal box ■ ■ ■ Installation on 2503 vertical box ■ ■ ■ ■ Manual 2-wire video intercom system AVE V44 EASY Rev.015 2025/05/22...
  • Page 22 2.1 Intercom handset item VI2F-PICAB The VI2F-PICAB device is an audio indoor station for the AVE V44 EASY 2-wire video intercom system. The technical specifications of the intercom handset are given here below: CHARACTERISTICS Height (mm) Product width (mm) Product depth (mm) 52.8...
  • Page 23 Below is the configuration of the dip switches for addressing the handset. DIP SWITCH DIP SWITCH INDIRIZZO APP.TO INDIRIZZO APP.TO RISERVATO Manual 2-wire video intercom system AVE V44 EASY Rev.015 2025/05/22...
  • Page 24 Bus-A Bus 1 - 2 (J1) Bus-B Bell (J3) Front door bell button Bell (J3) Front door bell button DIP SWITCH SW1-1 Master/Slave device selector SW1-2 ON/OFF end-of-line impedance selector Manual 2-wire video intercom system AVE V44 EASY Rev.015 2025/05/22...
  • Page 25 DEVICE RESET To restore the device's factory settings, within 60 seconds of switching it on, press the KEY button for 5 seconds. The device will emit a confirmation sound and restore the default settings. FUNCTIONS ASSOCIATED WITH THE BUTTONS Manual 2-wire video intercom system AVE V44 EASY Rev.015 2025/05/22...
  • Page 26 Warning: the device buttons can be used to navigate through the menus as described above. OPEN DOOR ALARM When the “GS” alarm input on the expandable external station (art. VI2F-PE1, VI2F-PE2, VI2F-PE4, VI2F-PE7T) is unbalanced for more than 2 minutes, the DOOR LED flashes to indicate that the door has been left open.
  • Page 27 1 to 10. Confirm by pressing the KEY button. The next parameter will be displayed on the LCD. 3. Press the THREE LINE button to exit the menu. Warning: The device will also exit the menu if there is no operation within 5 seconds. Manual 2-wire video intercom system AVE V44 EASY Rev.015 2025/05/22...
  • Page 28 Indoor station with 7" LCD item VI2F-PIT7B The VI2F-PIT7B device is an audio/video indoor station for the AVE V44 EASY 2-wire video intercom system. The technical specifications of the indoor station with 7" Touch Screen LCD are given here below:...
  • Page 29 Wi-Fi network card for connection to a home router. If the device is connected to the internet, it can be interfaced with the AVE Video V44 application, which allows answering a call and managing gates.
  • Page 30 Maximum absorption 15 mA @30V CONNECTIONS Bus 1 terminals Bus #1 distributor output Bus 2 terminals Bus #2 distributor output L terminal Input power supply N terminal Input power supply Manual 2-wire video intercom system AVE V44 EASY Rev.015 2025/05/22...
  • Page 31 Maximum absorption 15 mA @30V CONNECTIONS Bus 1 terminals Bus #1 distributor output Bus 2 terminals Bus #2 distributor output L terminal Input power supply N terminal Input power supply Manual 2-wire video intercom system AVE V44 EASY Rev.015 2025/05/22...
  • Page 32 N.B. The impedance matching must be set to RC when the signal amplifier is connected as the last amplifier of the Bus branch and set to NC in all other cases. Manual 2-wire video intercom system AVE V44 EASY Rev.015 2025/05/22...
  • Page 33 The RC multi-way switch must be set to ON when the distributor is connected to the end of the Bus line, without any other devices connected on the second pair of input terminals. Manual 2-wire video intercom system AVE V44 EASY Rev.015 2025/05/22...
  • Page 34 OUTDOOR UNIT #3 - RELAY 4 OUTDOOR UNIT #4 - RELAY 3 OUTDOOR UNIT #4 - RELAY 4 OUTDOOR UNIT #5 - RELAY 3 OUTDOOR UNIT #5 - RELAY 4 Manual 2-wire video intercom system AVE V44 EASY Rev.015 2025/05/22...
  • Page 35 • VI2F-PE1-2-4: 1.06 • VI2F-PE1-2AP: ver .1.03 • VI2F-PE7T: ver. 2.43 All previous versions can manage a maximum of 1 external relay. Manual 2-wire video intercom system AVE V44 EASY Rev.015 2025/05/22...
  • Page 36 Inputs for connecting the Bus power supply. Both Bus1 pairs are connected Bus 1 (IN), Bus 1 (IN) in parallel Normally closed contact Common contact Normally open contact DA, DB, GND Serial interface 485 Manual 2-wire video intercom system AVE V44 EASY Rev.015 2025/05/22...
  • Page 37 The impedance matching must be set to RC when the camera interface is connected as the last node of the bus branch and set in NC in all other cases. Manual 2-wire video intercom system AVE V44 EASY Rev.015 2025/05/22...
  • Page 38 Through the interface, it is possible to download the list of names entered in the device, modify the programming of the buttons on the outdoor stations and download the list of MIFARE cards associated with the device. The interface must be managed via the AVE V44 CONFIG software. CHARACTERISTICS Height (mm)
  • Page 39 3.9 Bus cable item VI2F-CV The VI2F-PROG device is part of the AVE V44 EASY 2-wire video intercom system and is the module that allows interfacing a PC with the VI2F-PEx and VI2F-PE7T external stations. CHARACTERISTICS Conductor Copper 2x0.5mm Insulator colours...
  • Page 40 CONNECTING DEVICES OUTDOOR STATIONS 1.1 In-wall outdoor stations item VI2F-PE1, VI2F-PE2, VI2F-PE4 The outdoor stations must be connected to the 2-wire bus. The connection of a single outdoor station is shown below. If more than one outdoor station is to be installed, it is essential to use item VI2F-PEDIST (max.
  • Page 41 Note: auxiliary columns must always be associated with an outdoor station. The extensions associated with the individual buttons are consecutive to the buttons on the installed outdoor station. Two examples are given below. Manual 2-wire video intercom system AVE V44 EASY Rev.015 2025/05/22...
  • Page 42 VI2F-PE7T outdoor station with the button-type outdoor stations (items VI2F- PE1… VI2F-PE4). Note: the maximum number of outdoor stations that can be installed on a system is 5. Manual 2-wire video intercom system AVE V44 EASY Rev.015 2025/05/22...
  • Page 43 Once the operation has been carried out, the monitor will be able to receive calls from all the external stations of the system but will only be able to manage the monitoring and unlocking of the selected external stations. Manual 2-wire video intercom system AVE V44 EASY Rev.015 2025/05/22...
  • Page 44 Once the operation has been carried out, the monitor will be able to receive calls from all the external stations of the system but will only be able to manage the monitoring and unlocking of the selected external stations. Manual 2-wire video intercom system AVE V44 EASY Rev.015 2025/05/22...
  • Page 45 The indoor station has an input to which a front door bell button can be connected: when the button is pressed, the indoor station emits an acoustic signal. Manual 2-wire video intercom system AVE V44 EASY Rev.015 2025/05/22...
  • Page 46 Manual 2-wire video intercom system AVE V44 EASY Rev.015 2025/05/22...
  • Page 47 3 MISCELLANEOUS ITEMS 3.1 Bus power supply item VI2F-ALI The VI2F-ALI is part of the AVE V44 EASY 2-wire video-intercom system and represents its primary power source. Each device can manage up to 32 indoor stations (monitors or handsets) and 3 outdoor stations.
  • Page 48 3.2 Bus power supply item VI2F-ALI600MA The VI2F-ALI600MA device is part of the AVE V44 EASY 2-wire video intercom system and can be used as a BUS power supply unit for single-family systems with 1 outdoor station and 1 indoor station or as a local 30VDC power supply unit for the auxiliary power supply to Wi-Fi monitors.
  • Page 49 3.3 Signal amplifier item VI2F-AMPLI The VI2F-AMPLI is part of the AVE V44 EASY 2-wire video-intercom system and represents its auxiliary power source. Each device can manage up to 16 indoor stations. The maximum number of devices that can be installed (indoor stations) on the branch must be calculated according to the sum of their maximum consumption.
  • Page 50 3.4 Signal distributor for outdoor stations item VI2F-PEDIST The VI2F-PEDIST device is part of the AVE V44 EASY 2-wire video intercom system and is a signal distributor to several outdoor stations. The device allows the connection of up to four outdoor stations.
  • Page 51 3.5 Signal distributor for indoor stations item VI2F-PIDIST The VI2F-PIDIST device is part of the AVE V44 EASY 2-wire video intercom system and is a signal distributor to several indoor stations. The device makes it possible to install indoor stations in several apartments. Each device can manage four separate lines: up to four indoor stations can be installed on each line.
  • Page 52 3.6 Relay module item VI2F-RELAY The VI2F-RELAY device is part of the AVE V44 EASY 2-wire video intercom system and is a relay actuator module, which can be used in conjunction with an outdoor station. If the addresses of this module and of the outdoor station are the same, the indoor monitor can unlock the relay contact while monitoring, calling and communicating with the outdoor station.
  • Page 53 3.7 Ringtone repeat relay module VI2F-RELAY2 The VI2F-RELAY2 device is part of the AVE V44 EASY 2-wire video intercom system and is a relay actuator module for repeating the indoor station ringtone. If this module is set to the same address as the indoor station, an incoming call will activate both the relay module and the call on the device.
  • Page 54 The impedance matching must be set to RC when the camera interface is connected as the last node of the bus branch and set in NC in all other cases. Manual 2-wire video intercom system AVE V44 EASY Rev.015 2025/05/22...
  • Page 55 #3 #4 #5 #6 Address Reserved configuration - not to be used Address 1 Address 2 Address 3 Address 4 Address 5 … Address 12 Address 13 Address 14 Address 15 Manual 2-wire video intercom system AVE V44 EASY Rev.015 2025/05/22...
  • Page 56 3.9 Outdoor station programming interface item VI2F-PROG The VI2F-PROG device is part of the AVE V44 EASY 2-wire video intercom system and is the module that allows a PC to interface with the VI2F-PE7T outdoor station. Manual 2-wire video intercom system AVE V44 EASY Rev.015...
  • Page 57 "MASTER" and the other 3 must be configured as "SLAVE" (see figure 2). DEVICES THAT CAN BE INSTALLED ON THE SYSTEM The following table shows the maximum number of devices that can be installed on a 2-wire system: Manual 2-wire video intercom system AVE V44 EASY Rev.015 2025/05/22...
  • Page 58 The maximum number of outdoor stations that can be installed on the 2-wire system is 5. The system allows two programming modes: • Dip-switch mode: default configuration of in-wall outdoor stations (items VI2F-PE1, VI2F-PE2, VI2F-PE4); • Button mode: configuration to be activated on in-wall outdoor stations (items VI2F- PE1, VI2F-PE2, VI2F-PE4), default configuration on wall-mounted outdoor stations (items VI2F-PE1AP, VI2F-PE2AP).
  • Page 59 Within 60 seconds of switching back on, press one of the call buttons for 3 seconds: the device will emit a long beep to confirm the reset. d. Switch off the device and reopen the DOOR contact. Manual 2-wire video intercom system AVE V44 EASY Rev.015 2025/05/22...
  • Page 60 If a 4-button auxiliary column (item VI-PEAUX4) is installed, the system will still count 8 buttons assigned to it (e.g. installation VI2F-PE1 + 1 x VI-PEAUX4 + 1 x VI-PEAUX: button address on the main outdoor station 1, button addresses on the 4-button auxiliary column from 2 to 9, button addresses on the 8-button auxiliary column from 10 to 17).
  • Page 61 Open the file and change the button/flat association (see example) File downloaded from the outdoor station Button mapping table (2-wire system) Building No. Button number (*) Flat number (*) 0001 0002 0003 0004 0005 0006 0007 0008 Manual 2-wire video intercom system AVE V44 EASY Rev.015 2025/05/22...
  • Page 62 Button number (*) Flat number (*) 0008 0007 0006 0005 0004 0003 0002 0001 • Save the file, import it into the configuration software and send it to the outdoor station. Manual 2-wire video intercom system AVE V44 EASY Rev.015 2025/05/22...
  • Page 63 CARD PROGRAMMING The system allows the management of the main relay of the outdoor stations (item VI2F-PE1, VI2F- PE2, VI2F-PET7) through the use of cards with MIFARE technology (item 44339CHU-MB). Outdoor stations items VI2F-PE4 and VI-PEAUX do not support the card reading/programming function.
  • Page 64 The procedure for accessing the Card registration menu is as follows: a. In stand-by mode (system at rest), touch the card reader located on the outdoor station with the MASTER card: the device will emit a confirmation "beep". Manual 2-wire video intercom system AVE V44 EASY Rev.015 2025/05/22...
  • Page 65 If no operations are performed for 15 seconds, the system exits the user card programming procedure. d. At the end of the procedure, touch the reader with the MASTER card to exit the programming menu. Manual 2-wire video intercom system AVE V44 EASY Rev.015 2025/05/22...
  • Page 66 If no operations are performed for 15 seconds, the system exits the user card programming procedure. d. At the end of the procedure, touch the reader with the MASTER card to exit the programming menu. Manual 2-wire video intercom system AVE V44 EASY Rev.015 2025/05/22...
  • Page 67 If no operations are performed for 15 seconds, the system exits the user card programming procedure. d. At the end of the procedure, touch the reader with the MASTER card to exit the programming menu. Manual 2-wire video intercom system AVE V44 EASY Rev.015 2025/05/22...
  • Page 68 If no operations are performed for 15 seconds, the system exits the user card programming procedure. h. At the end of the procedure, touch the reader with the MASTER card to exit the programming menu. Manual 2-wire video intercom system AVE V44 EASY Rev.015 2025/05/22...
  • Page 69 If no operations are performed for 15 seconds, the system exits the user card programming procedure. e. At the end of the procedure, touch the reader with the MASTER card to exit the programming menu. Manual 2-wire video intercom system AVE V44 EASY Rev.015 2025/05/22...
  • Page 70 2-wire bus. Start the V44 CONFIG program and activate the serial communication. Press "Card Configuration" button and then press "Export File" to save device configuration to your PC. Manual 2-wire video intercom system AVE V44 EASY Rev.015 2025/05/22...
  • Page 71 6 digits. Then, send the configuration to the VI2F-PE7T device by pressing the "Send Configuration" button. Manual 2-wire video intercom system AVE V44 EASY Rev.015 2025/05/22...
  • Page 72 If the extension is not known, it is possible to display the list of extensions by pressing the "figure" button (located at the top of the screen); scroll through the list of extensions and select the desired one. Manual 2-wire video intercom system AVE V44 EASY Rev.015 2025/05/22...
  • Page 73 When a call is answered from a "SLAVE" station, the LCD of that station is switched on (the LCD of the MASTER indoor station is switched off). To end the call, press the handset button again. Manual 2-wire video intercom system AVE V44 EASY Rev.015 2025/05/22...
  • Page 74 The relays of the outdoor station No. 1 only can be unlocked using the handset (Item VI2F- PICAB). The operation can also be performed without lifting the handset. Manual 2-wire video intercom system AVE V44 EASY Rev.015 2025/05/22...
  • Page 75 The “Mute” mode has a maximum duration of 10 hours after which the devices automatically return to “normal” operating mode by reactivating the ring tones, in order to avoid the loss of calls due to the “Mute” mode being forgotten to be active. Manual 2-wire video intercom system AVE V44 EASY Rev.015 2025/05/22...
  • Page 76 The door connected to the outdoor station can be opened by simply holding a card (item 44339CHU- MB or 44339CHU-MT), previously assigned to the system, against the card reader symbol. The system allows the association of 50 cards on the VI2F-PE1, VI2F-PE2, VI2F-PE1AP, VI2F-PE2AP stations and of 200 cards on the VI2F-PE7T station.
  • Page 77 Videos are only stored on an SD card (not supplied), which must be inserted into the SD card slot on the device. The devices accept SD cards from 2GB to 32GB. Manual 2-wire video intercom system AVE V44 EASY Rev.015 2025/05/22...
  • Page 78 The VI2F-PIT4B and VI2F-PICAB outdoor stations do not support the function described above. 13 REPLACEMENT OF NAME TAGS The outdoor stations (items VI2F-PE1, VI2F-PE1AP, VI2F-PE2, VI2F-PE2AP, VI2F-PE4, VI2F-PEAUX, VI2F-PEAUX4) are equipped with name tags that are placed in the corresponding call button.
  • Page 79 INDOOR STATIONS, MEANING OF MENUS 12.1 Indoor handset (Item VI2F-PICAB) Manual 2-wire video intercom system AVE V44 EASY Rev.015 2025/05/22...
  • Page 80 LCD screen. Attention: "block DTD" feature available from SW version 1.52 or later. In Stand-by mode, briefly press the button to access the intercom call: Manual 2-wire video intercom system AVE V44 EASY Rev.015 2025/05/22...
  • Page 81 3 (dry contact relay on the auxiliary relay); 4. Press the button to move between outdoor stations; 5. Press the button to end the call. Manual 2-wire video intercom system AVE V44 EASY Rev.015 2025/05/22...
  • Page 82 When a call is received from an external station, the device will start ringing and the image from the external station's camera will be displayed on the indoor "Master" station. The call can be answered by pressing the HANDSET button. Manual 2-wire video intercom system AVE V44 EASY Rev.015 2025/05/22...
  • Page 83 The photographs are stored in the device’s internal memory. If an SD card is installed on the device (not supplied), it is possible to save a 15-second video: during a call, press the “Record” button Manual 2-wire video intercom system AVE V44 EASY Rev.015 2025/05/22...
  • Page 84 If you lose the password to access the advanced configuration menu, you can access the menu by typing the code 801801 to reset the device password. Note: the reset procedure does not delete previously recorded photographs and videos. Manual 2-wire video intercom system AVE V44 EASY Rev.015 2025/05/22...
  • Page 85 Management of the “advanced” functions of the system (to be activated in the “settings” menu): • Wired Home Automation: interfacing with the AVE DOMINA PRO home automation system; • Smart Home Automation: interfacing with the connected AVE DOMINA SMART civil series;...
  • Page 86 Internet, allow automatic updating of the same. The automatic updating of the date and time inhibits manual configuration of the same. • Automatic synchronization: if the device is connected to the Internet, the date and time are automatically synchronized. Manual 2-wire video intercom system AVE V44 EASY Rev.015 2025/05/22...
  • Page 87 • Display: number of side-by-side maps displayed by the home automation page; • Show IoT connection: display of the connection icon to the connected AVE civil series. The icon is shown in the top right corner of the device's LCD;...
  • Page 88 • Other: by pressing the + and - buttons, it is possible to select the melody that the device emits with each other alarm signal. • AVE alarm: by pressing the + and - buttons, it is possible to select the melody that the device emits with each other signal (alarms, alarms from the SMART HOME).
  • Page 89 Date and weather: activation of the weather section of the home page. SYSTEMS Domina Pro: activation of the button to access the interface to the web server of the AVE DOMINA PRO wired system Domina Smart: activation of the button to access the interface to the root node of the AVE DOMINA SMART system.
  • Page 90 DOMINA SMART system. By pressing the “Default Address” button, the address is reset to the default parameters 192.168.1.12. The root node address can be found via the AVE Cloud APP by checking the addresses of the devices in the field.
  • Page 91 Download the AVE VIDEO V44 application from the APP STORE or GOOGLE PLAY and register the new user. To associate the mobile phone, simply enter the settings menu and then the "Cloud Intercom Settings"...
  • Page 92 CONFIGURING THE AVE VIDEO V44 APP The V44 EASY system is equipped with the AVE VIDEO V44 APP, which allows remote interaction with the system. The operations that can be performed remotely are: • Answering a call; • Releasing the electro-locks;...
  • Page 93 11. Complete registration by pressing the "Register" button; 12. To log out, go to Account/Settings/Logout menu; 13. Close the APP; 14. Launch the APP again and log in using the username and password you created earlier. Manual 2-wire video intercom system AVE V44 EASY Rev.015 2025/05/22...
  • Page 94 2 ASSOCIATING THE DEVICES WITH THE APP The device that can be associated with the AVE VIDEO V44 App is the 7" Wi-Fi touch screen (item VI2F-PIT7WF). All other 2-wire system devices are not suitable for remote control. Perform the following steps to associate a device with the App: 1.
  • Page 95 2. Select the device to be deleted; 3. Press the button with the 3 horizontal bars to access the parameters of the device; 4. Press the "Dissociate device" button; 5. Confirm the operation. Manual 2-wire video intercom system AVE V44 EASY Rev.015 2025/05/22...
  • Page 96 5 INVITING NEW USERS TO YOUR SYSTEM (SYSTEM SHARING) To share your system with other users, proceed as follows: Download the AVE VIDEO V44 App on the mobile phone of the person you are inviting and carry out the registration procedure.
  • Page 97 INVITATION VIA AN INVITATION CODE a) Access the Account menu; b) Press "System Management"; c) Press "You have an invitation"; d) Enter the invitation code provided by the system owner; e) Press "Confirm" Manual 2-wire video intercom system AVE V44 EASY Rev.015 2025/05/22...
  • Page 98 The actual deletion of an account will take place within 7 days from the date of the request; during this period, it is possible to restore the account by requesting the reactivation code directly in the APP. Manual 2-wire video intercom system AVE V44 EASY Rev.015 2025/05/22...
  • Page 99 7 ANSWERING A CALL The AVE VIDEO V44 APP can only accept a call from an outdoor station if the indoor station is a Wi- Fi monitor with a routing function to it. The call is forwarded to the APP at the same time as it is received at the indoor station.
  • Page 100 At the bottom of the page, it is always possible to display the seconds remaining until the end of the call. • Press the arrow in the top left corner to close the page and return to the device list page. Manual 2-wire video intercom system AVE V44 EASY Rev.015 2025/05/22...
  • Page 101 It is recommended to request the list of devices already verified and functioning with AVE office. ** The other monitors of the 2-wire system cannot communicate with the devices of the "advanced"...
  • Page 102 Wall-mounted 2-call video intercom outdoor station Items not directly belonging to the 2-wire video intercom system: Identifier in the Item code Description diagram Door bell button Electro-lock Door opening control contact Manual 2-wire video intercom system AVE V44 EASY Rev.015 2025/05/22...
  • Page 103 Alternatively VI2F-CV Bus cable In addition to the above, it is possible to install: Identifier in Item code Description Quantity the diagram Door bell button Electro-lock Door opening control contact Manual 2-wire video intercom system AVE V44 EASY Rev.015 2025/05/22...
  • Page 104 Touch screen VI2F-CV Bus cable In addition to the above, it is possible to install: Identifier in Item code Description Quantity the diagram Door bell button Electro-lock Door opening control contact Manual 2-wire video intercom system AVE V44 EASY Rev.015 2025/05/22...
  • Page 105 Bus cable In addition to the above, it is possible to install: Identifier in Item code Description Quantity the diagram Door bell button Up to 4 Electro-lock Door opening control contact Manual 2-wire video intercom system AVE V44 EASY Rev.015 2025/05/22...
  • Page 106 VI2F-CV Bus cable In addition to the above, it is possible to install: Identifier in Item code Description Quantity the diagram Door bell button Electro-lock Door opening control contact Manual 2-wire video intercom system AVE V44 EASY Rev.015 2025/05/22...
  • Page 107 In addition to the above, it is possible to install: Identifier in Item code Description Quantity the diagram Door bell button Electro-lock Door opening control contact 1.6 DUPLEX VIDEO INTERCOM SYSTEM (1 outdoor station and 1 indoor station) Manual 2-wire video intercom system AVE V44 EASY Rev.015 2025/05/22...
  • Page 108 VI2F-PE2 2-call outdoor station VI2F-PIDIST Distributor for indoor stations VI2F-PICAB Handset VI2F-PIT4B Video intercom indoor station with 4.3" LCD Alternatively VI2F-PIT7B Video intercom indoor station with 7" LCD Touch Alternatively Manual 2-wire video intercom system AVE V44 EASY Rev.015 2025/05/22...
  • Page 109 Bus cable In addition to the above, it is possible to install: Identifier in Item code Description Quantity the diagram Door bell button Up to 2 Electro-lock Door opening control contact Manual 2-wire video intercom system AVE V44 EASY Rev.015 2025/05/22...
  • Page 110 Bus cable In addition to the above, it is possible to install: Identifier in Item code Description Quantity the diagram Door bell button Up to 2 Electro-lock Door opening control contact Manual 2-wire video intercom system AVE V44 EASY Rev.015 2025/05/22...
  • Page 111 Bus cable In addition to the above, it is possible to install: Identifier in Item code Description Quantity the diagram Door bell button Up to 4 Electro-lock Door opening control contact Manual 2-wire video intercom system AVE V44 EASY Rev.015 2025/05/22...
  • Page 112 When a visitor calls the indoor station, the user can answer by lifting the handset or pressing the handset button on the touch screens. Manual 2-wire video intercom system AVE V44 EASY Rev.015 2025/05/22...
  • Page 113 Bus cable In addition to the above, it is possible to install: Identifier in Item code Description Quantity the diagram Door bell button Up to 4 Electro-lock Door opening control contact Manual 2-wire video intercom system AVE V44 EASY Rev.015 2025/05/22...
  • Page 114 Bus cable In addition to the above, it is possible to install: Identifier in Item code Description Quantity the diagram Door bell button Up to 9 Electro-lock Door opening control contact Manual 2-wire video intercom system AVE V44 EASY Rev.015 2025/05/22...
  • Page 115 Bus cable In addition to the above, it is possible to install: Identifier in Item code Description Quantity the diagram Door bell button Up to 9 Electro-lock Door opening control contact Manual 2-wire video intercom system AVE V44 EASY Rev.015 2025/05/22...
  • Page 116 1.12 MULTI-FAMILY VIDEO INTERCOM SYSTEM (1 outdoor station and 36 indoor stations) Manual 2-wire video intercom system AVE V44 EASY Rev.015 2025/05/22...
  • Page 117 Bus cable In addition to the above, it is possible to install: Identifier in Item code Description Quantity the diagram Door bell button Up to 36 Electro-lock Door opening control contact Manual 2-wire video intercom system AVE V44 EASY Rev.015 2025/05/22...
  • Page 118 (connected to the UP output of the first signal amplifier) must be installed by connecting them to the OUT output. A maximum number of 8 signal amplifiers can be connected to the system. Manual 2-wire video intercom system AVE V44 EASY Rev.015 2025/05/22...
  • Page 119 INCORRECT CONFIGURATION • Do not connect a signal amplifier "at the tail end" of a signal distributor Manual 2-wire video intercom system AVE V44 EASY Rev.015 2025/05/22...
  • Page 120 C. INCORRECT CONFIGURATION • Do not connect two or more branches to the same point. Manual 2-wire video intercom system AVE V44 EASY Rev.015 2025/05/22...
  • Page 121 E. INCORRECT CONFIGURATION • Do not connect multiple outdoor stations directly to the system power supply. For the correct connection of multiple outdoor stations,install the signal distributor VI2F-PEDIST. Manual 2-wire video intercom system AVE V44 EASY Rev.015 2025/05/22...
  • Page 122 3 MISCELLANEOUS The outdoor stations "mod. Villa" (items VI2F-PE1, VI2F-PE2, VI2F-PE4) can be installed on square/rectangular columns with a minimum side dimension of 100 mm. Drilling jigs for the column are shown below for installation with the VI-BOX3C support plate or VI- RPBOX3 rain canopy.
  • Page 123 HORIZONTAL INSTALLATION: 5 VI-BOX3N boxes VERTICAL INSTALLATION: 5 VI-BOX3N boxes Check with the sales network for availability of rain canopies for installations of more than three horizontal and two vertical units. Manual 2-wire video intercom system AVE V44 EASY Rev.015 2025/05/22...
  • Page 124 Manual 2-wire video intercom system AVE V44 EASY Rev.015 2025/05/22...
  • Page 125 NOTES: For the duration and conditions of the warranty for each product, please refer to www.ave.it and to the latest sales catalogue. The products must be marketed in their original packaging, otherwise the retailer and/or installer is obliged to apply and forward to the user the instructions accompanying the product and/or posted on www.ave.it and in the latest sales catalogue.
