Summary of Contents for RED BAND HBS
- Page 1 ’ PERATOR AFETY ERVICE ANUAL Red Band HBS / ISS-B / IBS Masonry Saw RED BAND UK LTD Tel: 0116 260 2601 Units 41 - 45 • The Warren Fax: 0116 260 2603 East Goscote Ind. Est. sales@redbanduk.co.uk East Goscote • Leicester www.redbanduk.co.uk...
- Page 3 All equipment supplied by Red Band will carry the CE mark, each machine has had the design reviewed and where deemed necessary has been improved to comply with the directive giving the best in safety and quality.
- Page 4 The Machine General Description The Red Band HBS / ISS-B / IBS Masonry Saws are designed for durability and reliability; easily maintained for long and efficient service, covering a wide range of uses within the building trade, also with stone masons, refractory companies or industrial users cutting a wide range of materials.
- Page 5 Blade Guard Steel constructed blade guards are designed to give the maximum coverage without impeding the operator’s vision of the work piece. Blade guards are fixed to the head console for rigidity and safety. Each guard has a built in water channel on the back end to cut down excessive water spray.
-
Page 6: Site Of Work
Site of work Siting the machine Remove from the site anything, which might hinder the working procedure. Make sure the site is sufficiently well lit. Make sure you have a continual adequate view of the working area so you can intervene in the working process at any time. - Page 7 In instances where the recirculating water pump is to be used. Ensure that the water bung located at the rear of the bed/tray is securely in place. Electrically operated water pumps will be wired in our factory prior to despatch. Fill the bed/tray of the saw sufficiently with water, ensuring that the pump is adequately covered.
-
Page 8: Cutting Methods
Cutting methods To use the machine correctly, you must face it with one hand on the handle of the cutting head, and the other on the conveyor cart. You can possibly press on the pedal with one foot. Always keep your hands away from the moving blade. Full depth or fixed cutting In full depth or fixed cutting, the cutting head is locked in a fixed position and the material is pushed into it as shown. -
Page 9: Safety Instructions
Safety Instructions Laws governing safety aspects on machinery vary between countries but the following guides will be useful to all operators: Users should follow carefully any operating instruction given. All electrical connections must be surely made to eliminate contact of live wires with water spray or dampness. -
Page 10: Maintenance
Maintenance Before performing any maintenance to your saw, always ensue that saw is switched off. Drive Belts Check the drive belts regularly, ensuring that the correct tension is maintained. Over tightened belts will cause damage not only to the drive belts, but also the pulleys on which they run and ultimately the blade shaft bearings. -
Page 11: Technical Data
Height 1580 mm 1580 mm 1670 mm Width 750 mm 750 mm 750 mm Length 1400 mm 1600 mm 1700 mm HBS / ISS-B Make Type 132S 132S Power 5.5 KW 7.5 KW Voltage 415V 415V Amps In 11.0 A 15.0A... -
Page 12: Spare Parts List
Bearing – Blade Shaft GS38 Rails : Pair ( GS09 Cover Plate GS39 Belt Guard GS10 Pulley ( GS40 Back Plate Blade Shaft HBS/ISS-B GS11 Pulley ( GS41 Belt ( Blade Shaft IBS Set of 4 HSS/ISS-B GS12 Key - Pulley ( GS42... -
Page 13: Spare Parts Drawing
Spare Parts Drawing... -
Page 14: Troubleshooting
Trouble Shooting Fault-finding procedures Should any fault occur during the use of the machine, turn it off, and isolate it from the electrical supply. Any works dealing with the electrical system or supply of the machine can only be carried out by a qualified electrician. -
Page 15: Conformity Notice
East Goscote Industrial Estate East Goscote Leicester LE7 3XA Declare that the product : Masonry Saw HBS / ISS-B / IBS Is in conformity with the European Machine Directive 98/37/EC And BS EN 12418 : 2000 Alan Newton Director 01/03/2008...
