Summary of Contents for Hunter Skyway
- Page 1 Skyway Installation Manual Model: 51672 Matte Black 52598 Fresh White Fan weight ±2 lbs: 14.7 lbs (6.7 kg) ©2023 Hunter Fan Co. PG4141 r051023...
- Page 2 - All wiring must be in accordance with national and local electrical codes ANSI/NFPA 70. If you are unfamiliar with wiring, use a qualified electrician. c.2 - Use only Hunter replacement parts. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
- Page 3 We recommend that you pull everything out of the box and lay it out. We have grouped the drawn components below with the hardware you’ll need for those Hunter Pro Tip: parts. The screws below are drawn to scale to make it easier to identify what piece of hardware is needed to install each component.
-
Page 4: Choosing The Right Installation Location
A little more information on Angled Mounting: For optimum performance and appearance, a longer downrod should be used with your Hunter ceiling fan when installing on high or angled ceiling. If your ceiling is angled greater than 34° you will also need an Angled Mounting Kit. -
Page 5: Installing The Ceiling Bracket
You have two options for installation. Pick which one works best for your location. Remove any existing Hunter Pro Tip: bracket prior to installation. Only use the provided Hunter ceiling bracket that came in your fan’s box. The machine screws are the ones that came with your outlet box. - Page 6 WARNING Hunter Pro Tip: FAN FALL HAZARD The ground wire attached to the downrod is approximately To prevent SERIOUS INJURY or DEATH: 8 inches.
-
Page 7: Hanging The Fan
1886 Hanging the Fan NOTICE To prevent damage to fan, ALWAYS lift holding either the fan housing or the downrod. Place the downrod ball into the slot in the ceiling bracket. Note: Fan style may vary. Progress Check: Your fan should look like this. Ceiling Bracket Blades Downrod... -
Page 8: Wiring The Fan
Follow these steps to get your fan wired quickly and safely. Follow the route below that best matches your wall switch setup. If you are unfamiliar with wiring or uncomfortable doing it yourself, please contact a qualifi ed electrician. Hunter Pro Tip: You are going to need these:... -
Page 9: Installing The Canopy
Canopy Screw Lift the canopy into place so that the screw holes are aligned. Hunter Pro Tip: Let the tool do the work! A magnetic screwdriver will give you more visibility when Note: securing the canopy. - Page 10 1886 Assembling the LIght Kit 2 of 6 1 of 6 Light Kit Screw Light Kit Screw Align the keyhole slots in the light kit Partially install two of the light kit screws housing with the two screws. Make found in the bag.
-
Page 11: Preparing The Remote
1886 Preparing the Remote The remote control is already paired for use. For To close the battery Remote Function Guide your convenience, a remote compartment, secure Key Press Function function card is packed in the battery door to the transmitter assembly with with your remote. -
Page 12: Troubleshooting
There is no warranty for light bulbs (except where otherwise noted); remote control Please do not ship your fan or any fan parts to Hunter. Delivery will be refused. batteries; fans purchased or installed outside the United States; fans owned by What Does This Warranty Cover? someone other than the original purchaser;... - Page 13 1886 Downrod If you need a different downrod length follow these steps: Follow steps 1-5 to remove standard downrod pipe Here is another view of the downrod assembly unassembled. Follow steps 6-10 to reassemble with new downrod WARNING • VERIFY the downrod •...
