Summary of Contents for cultsport SmartrunDavie
- Page 1 Model: SmartrunDavie Note: Following the principles of sustainable development, we may modify machines when necessary and will not notify again. It all depends on the actual product.
- Page 2 CONTENTS 1. Product Brief .....................1 2. Security Precautions and Warning ............3 3. Installation Instructions ................5 4. Using Instructions ..................9 5. Routine Maintenance and Instructions ........... 13...
-
Page 3: Product Brief
1. Product Brief A. Multifunctional Motorized Treadmill B. Single function Motorized Treadmill... - Page 4 Main parameters and parts list Main technical parameters Parameters Names Description Input power voltage AC220-240V(50/60Hz) Speed 1.0-20 km/h Running surface 1450*580 mm Expand dimensions 2040*930*1440 mm Multifunction Running (Sit up, massager, dumbbells, twister) Packing list Name units Complete machine Protective cover Accessory Bag Accessory bag list Name...
- Page 5 2. Security Precautions and Warning Tips: Before folding the treadmill, make sure that the gradient is "zero". Please read the instructions carefully before use. Notice: ◆ Indoor using and storing the treadmill, avoid dampness, and cannot be spilled by water. ◆...
- Page 6 ◆ Don't use machine for more than 2 people at the same time, and don't get close to the machine when it is in use. ---- Or it may be an accident or injury due to falls. ◆ People who can’t express their consciousness or can’t operate the machine by themselves cannot use the treadmill.
-
Page 7: Installation Instructions
3. Installation Instructions When installing, simple fix all screws first, then tighten screws when the installation of frame is done. 1.Put the machine flat on the ground. Remove the screw of the console M8 * 28, lock the console and column, connect the column signal wires with the console signal wires. - Page 8 M5*14 Above are steps of single function installation, multifunctional machines need to be installed after you complete the steps above and then continue with the following installation: 5. Use 5# inner hexagon spanner and screw M8*22 to lock the massager frames on the columns.
- Page 9 M8*15 8. Put the foams through the massager frames and put the dumbbells on the frame. 9. Plug the power line as showing below: 10. Put the safety key on the picture showing place and press the start button to start the treadmill.
-
Page 10: Using Instructions
4. Using Instructions Using treadmill 1. Insert the power plug properly and turn on the switch (in red color) (1). When the light is on, there will be beep sound, and then the screen will be light up (Systems of TFT screen takes more time to enter the start interface). - Page 11 We advise to add silicon oil according to the following schedule: A. Lightweight user (use the machine less than 3 hours every week): Please add oil every one month. B. Heavyweight user (use the machine more than 7 hours every week) please add the oil every half moth In order to maintain your treadmill and extend the life of the machine, it is suggested that after your continued use of one hour, turn off the machine and let it rest for 10 minutes before...
- Page 12 keys to adjust the speed of the treadmill. And press the speed quick key to cycle the speed of 3, 6, 9, 12km/h. 5.4.6 Program key In standby mode, pressing this key can cycle the options from manual mode to automatic programs.
- Page 13 INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE Meaning of error codes Fault code Failure Description fault handling Communication Abnormal: Possible Cause: the communication between the lower controller and when the power is on, the console is blocked, check each joint between the controller and connection between lower...
-
Page 14: Routine Maintenance
5. Routine maintenance Warning: Before cleaning or maintaining products, please be sure the power plug of the treadmill is pulled out. Cleaning: Comprehensive cleaning will extend the using life of the electric treadmill. Remove dust periodically in order to keep the parts clean. Be sure to clean running belt with both sides of the exposed portion, which will reduce the accumulation of impurities. - Page 15 Please adjust the tightness of the multi-wedge belt into the state that it could be flipped by 80%. Step 3: Finally lock the motor base, and install the front cover. Customer Care Support Email: support@cultsport.com Website: www.cultsport.com Toll free: 1800-572-6402/1800-572-6303...
