AQUALYSER
L'électrolyseur combiné
The combined chlorinator
El clorador combinado
Il clorinatore combinato
Der kombinierte Elektrolyseur
De gecombineerde chlorinator
Manuel d'installation et d'utilisation
Installation and user manual
Manual de usuario y instalación
Manuale d'installazione e d'uso
Installations und Gebrauchsanleitung
Installatieen en gebruikershandleiding
WWW.POOLEX.FR

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AQUALYSER and is the answer not in the manual?

Questions and answers

Related Manuals for POOLEX AQUALYSER

Summary of Contents for POOLEX AQUALYSER

  • Page 1 AQUALYSER L’électrolyseur combiné The combined chlorinator El clorador combinado Il clorinatore combinato Der kombinierte Elektrolyseur De gecombineerde chlorinator Manuel d’installation et d’utilisation Installation and user manual Manual de usuario y instalación Manuale d’installazione e d’uso Installations und Gebrauchsanleitung Installatieen en gebruikershandleiding...
  • Page 2 Our products are the result of years of research in the design and manufacture of heat pumps for pools. Our goal is to deliver high-quality products with exceptional performance. We took great care to put together this manual so you can get the most out of your Poolex heat pump.

  • Page 3: Please Read Carefully

    They must be given to the installer and kept by the user. If you lose this manual, please visit our website: www.poolex.fr The warnings and guidelines contained in this manual must be carefully read and understood as they provide important information concerning the safe handling and operation of the chlorinator.

  • Page 4: Table Of Contents

    12. View the history of the last two days 13. Consult the report on errors encountered 14. Contact technical support 5. Application 1. Download & Installation of the «Poolex» application 2. Pairing your combination chlorinator 3. Interface 4. Modify the operating mode...
  • Page 5 5. Changing the production rate 6. Modify the parameters of the selected mode 7. View error history 8. View device data 5. Maintenance 1. Entretien général 2. Cleaning the electrolyser cell 3. Wintering 4. Replacing the electrolysis cell 5. Replacing the dosing pump tube 6.

  • Page 6: Warnings

    1. WARNINGS Installation and maintenance of any upstream electrical components must be per- formed by a qualified electrician. Failing to do so may result in electric shock, serious  injury, property damage and even death. Prior to any maintenance or operation, ensure that the salt chlorinator and any other devices are shut down and the main power supply is off. The salt chlorinator’s external power adaptor must be connected to a main power sup- ply separate from the filtration system (no feedback control), equipped with a 30mA ...

  • Page 7: Description

    2. DESCRIPTION 1. Package contents On receipt, please check that your parcel contains : Aqualyser FLEX Aqualyser TOTAL • the control box with its power cable • the control box containing the elec- trolyser cell and the probe holder, with • electrolyser cell its power cable • the pH dosing pump on the probe •...

  • Page 8: Operating Principle

    2. DESCRIPTION 3. Operating principle Salt chlorination of a pool works by using salt electrolysis to disinfect the water; this electrochemical process converts the salt present in the water into a disinfectant (hy- pochlorite ions).  Once this process is complete, hypochlorite turns back into salt after coming into contact with organic material (bacteria, cells) or under the effect of UV rays or other  sources of light, starting the cycle over again. In order to maintain a good level of disinfectant in the water, the following guidelines must be respected: •...

  • Page 9: Operating Limits

    2. DESCRIPTION The controller also warns you when it is time to replace your pH metering pump (pe- ristaltic pump) or any other component. See section «7. Troubleshooting», page 40, for  more information. WARNING - Salt water chlorination alone will not clear up green water by itself. In the event of algae appearing (e.g. after a period of high temperatures or frequent use), it may be necessary to supplement with chlorine tablets.

  • Page 10: Recommended Rate Tables

    2. DESCRIPTION 5. Recommended rate tables Check your values and correct them at least once a week. Parameter Target values Comments The controller allows you to choose a value between 400 mV and 800 mV. However, it is recommended not to go below 650 (oxidation- mV and not to go above 750 mV.

  • Page 11: Technical Specifications

    2. DESCRIPTION 6. Technical specifications Aqualyser FLEX Aqualyser TOTAL Power supply voltage 100 - 240 Vac ~ 50-60 Hz Max. power / standby 120 W / 5 W Transformer output voltage (Vdc) Output current (A) Operating temperature water 10°C ~35°C Operating temperature air 15°C ~45°C Flow rate 6 to 10 m Dimensions L x H x D (mm) box 200 x 150 x 65 380 x 325 x 260...
  • Page 12 2. DESCRIPTION 2. Electrolyser 3. pH dosing pump and probe holder 60 | EN...
  • Page 13 2. DESCRIPTION 4. FLEX assembly 5. TOTAL (Wall-mounted) EN | 61...

  • Page 14: Exploded Views

    2. DESCRIPTION 8. Exploded views 1. Electrolyser 62 | EN...
  • Page 15 2. DESCRIPTION 2. pH dosing pump and probe holder pH probe ORP probe 1/4" elbow 1/4" coupling Rubber plug Probe device cavity Probe device rubber ring Probe hook base Decora�ve components Waterproof silicone sleeve Fixed bracket Dosing pump EN | 63...
  • Page 16 2. DESCRIPTION 3. TOTAL Overlay sticker Top cover Display screen PC board Control box Big nut PG11 Top cover Electrode set 20g/30g Flow switch & temp probe Injection valve Grounding kit Cell 20g/30g Ball valve Connection A Connection B Fixing bracket Rotating bracket Adaptor Casing...

  • Page 17: Control Panel

    2. DESCRIPTION 9. Control panel 1. Buttons ON / OFF MENU FLEX pH PUMP BOOST ON OFF 7 mm 7 mm TOTAL Button Designation Function Menu Go to menu ON/OFF Start/Stop the device (press briefly) Reset the device (press and hold for 10s.) Start / Stop the pH function BOOST Start / Stop BOOST mode Minus / Previous Move -1 item in a list (menu)  Increment a negative step in a sequence (value)  Decrease the value of the production ratio by -20%. Plus / Next Move +1 item in a list (menu) ...
  • Page 18 2. DESCRIPTION 2. Home screen displays The home screen adapts according to the operating mode chosen. On the ORP control mode home screen : The pH and ORP indicators show the current value in green if it is correct, in yellow if it deviates from the target value and in red if it is urgent to restore the value by manual action.
  • Page 19 2. DESCRIPTION The pH indicator It displays the pH value measured by the probe in real time. Your target value is recalled in gray. The arrow indicates the actual value relative to the target value. The ORP indicator It displays the ORP value measured by the probe in real time. Your target value is recalled in gray.
  • Page 20 2. DESCRIPTION The pH and ORP sensors are sensitive. Renewal once a season is recommended. If your ORP sensor is malfunctioning, you can switch to the other two modes while you wait for it to be replaced. On the Time Control home screen : 13 h The ORP indicator is replaced by a time indicator.
  • Page 21 2. DESCRIPTION 3. Tips for choosing your settings To choose your treatment and/or filtration time intelligently, refer to the table opposite: 10°C  ≤   t °<  2 0°C t°≥  2 8°C or t°≥  3 0°C or Water 20°C  ≤   t °<  2 5°C 25°C  ≤   t °<  2 8°C t°≥ ...

  • Page 22: Getting Started

    3. GETTING STARTED 1. Hydraulic installation When you leave the pool, you should install your circulation pump and filtration system  first. The chlorinator must always be the last piece of equipment in the hydraulic circuit.  The direction of water circulation in Aqualyser must also be respected. If you have other equipment (e.g. a heat pump), be sure to install it upstream of the chlorinator. The Aqualyser FLEX can be turned upside down to adapt to the flow direction of your  hydraulic system. However, for Aqualyser TOTAL, the water must enter on the left and leave on the right of the product.

  • Page 23: Electrical Installation

    3. GETTING STARTED 2. Electrical installation The ORP controller must be electrically connected to the chlorinator, the pH dosing pump and your circulation pump. Please check that they are correctly installed before starting. The names of the fittings are indicated below them. 1. Connect the pH sensor to the ‘PH’ connector. 2.

  • Page 24: Setting

    3. GETTING STARTED 3. Setting When you start up for the first time or after a reset, you need to follow the steps for  setting up the device. 1. Choose your language a. Use the arrows to select your language. b. Press  (OK) to confirm. 2. Define the parameters a. Answer ‘YES’ to the question ‘Do you need to set parameters? The selected  answer is coloured. b. Press  (OK) to confirm. 3. Specify the volume of your pool a.

  • Page 25: Use

    4. USE 1. Unlock the keyboard After 15 minutes without action, the device locks automatically. When locked, the screen displays the icon in the top right-hand corner. To unlock the device, press the back  (OK) keys simultaneously for 5 seconds. 2. Menu screen To enter or exit the menu, use the ‘menu’ or ‘back’...

  • Page 26: Choosing And Setting The Operating Mode

    4. USE 3. Choosing and setting the operating mode Menu > Work mode 1. To change and/or set the operating mode, go to the menu   and confirm the ‘Work  mode’ menu selection by clicking  (OK). 2. Use the arrows to select the operating mode of your choice. Press (OK) to confirm. You can choose between three operating modes: control by ORP, control by time  or control by flow. Operating modes Description The operation of your chlorinator is automated accor- Control...

  • Page 27: Activating And Configuring The Ph Metering Pump

    4. USE 4. Activating and configuring the pH metering pump  button is used to quickly switch the pH dosing pump on and off. If the dosing pump is deactivated, the «Dosing pump» menu is greyed out and cannot be selected. Then use the button to enter the pH dosing pump parameters. When the dosing pump is activated, the icon is visible at the top right of the screen.

  • Page 28: Calibration

    4. USE 5. Calibration Before using for the first time, or when changing a probe, each probe must be ca- librated. Calibration solutions are not supplied for initial use. The correction enables the probes to be calibrated without having to use a calibration solution. 1. Calibrate the pH sensor Menu > Calibration > Calibration > pH calibration probe a.

  • Page 29: Programming The Filtration Pump (Optional)

    4. USE 4. Correction of the ORP Menu > Calibration > Correction > ORP correction The ORP of the water used for this step must be known. This can be done, for exa- mple, using an ORP tester. a. Rinse the ORP sensor. b.

  • Page 30: Activate Wifi

    4. USE Parameter Description Runtime Running time of the pump during a cycle. Execution time The running time can be neither less than 15 minutes nor more than 120 minutes (2h). The step between two available  values is 15 minutes. Frequency Time interval between stopping and restarting the water pump.

  • Page 31: Changing The Time And Date

    4. USE 8. Changing the time and date The time and date are automatically adjusted after connecting to Wi-Fi. Menu > Config > Time 1. Go to the menu , use the  arrows to select the ‘Configuration’ menu  and confirm. 2. Use the  arrows to select the ‘Time’ menu, then confirm   (OK). If you have wifi enabled, check the synchronisation at this stage. 3. The pre-selected value starts flashing. Use the  arrows to select the value to be changed, then press  (OK).

  • Page 32: Change Screen Brightness

    4. USE 11. Change screen brightness Menu > Brightness 1. Go to the menu , use the arrows to select the ‘Brightness’ menu and confirm. 2. Use the arrows to decrease or increase screen brightness. 3. Use the back arrow to return to the main menu. 12.

  • Page 33: Consult The Report On Errors Encountered

    4. USE 13. Consult the report on errors encountered Menu > History > Report 1. Go to the menu , use the arrows to select the ‘History’ menu confirm. 2. Use the  arrows to select the ‘Report’ menu, then confirm   (OK). This page lists the errors encountered by the device. 3.

  • Page 34: Application

    Poolex application. With the Poolex application, you can share the devices you’ve set up with other Poolex accounts, receive real-time operating alerts and create scenarios with seve- ral devices, based on the application’s weather data (geolocation essential). Using the Poolex application also means taking part in the continuous improve- ment of our products.

  • Page 35: Pairing Your Combination Chlorinator

    2.4 GHz WiFi network (available for most Internet boxes, routers and WiFi access points). 2. Launch the Poolex application and create an account. 3. Press the arrows simultaneously for 5 seconds. On your application, go to the «Add a device» tab.

  • Page 36: Interface

    5. APPLICATION 3. Interface Back to Poolex home page Change device name Boost mode Error alert (red if error) Chlorine production rate Operating mode Reducing production Increasing production Actual ORP Actual pH Target ORP Target pH Water Salinity level temperature Start or stop the combined electrolyser...

  • Page 37: Modify The Operating Mode

    5. APPLICATION Errors are highlighted in red to make it easier for you to keep track of your settings. 4. Modify the operating mode To change the operating mode, press . The operating mode selection window opens. Press the desired operating mode. The default mode, which is ORP control, is recommended to take advantage of all the features of your combined electrolyser.

  • Page 38: Changing The Production Rate

    5. APPLICATION 5. Changing the production rate To change the chlorine production rate, use the buttons. Each press increments +/- 20% production. 1. BOOST mode BOOST mode allows the production rate to be 14:23 increased to 100% for 24 hours. XCHLO SALT CHLORINE Press the pushbutton to the left of the icon to activate or deactivate BOOST mode.

  • Page 39: View Error History

    5. APPLICATION 7. View error history When an error is detected, the button turns red. Then use the button to access the error history. The date is entered in the format “year /  month / day”. See section «2. Diagnosis and resolutions», page 94, for details and solutions associated with each error. EN | 87...

  • Page 40: View Device Data

    5. APPLICATION 8. View device data Data from each probe (salinity, temperature, ORP, PH, flow rate) and energy consumption. These data are presented in the form of a graph over the hours. Use the arrows to the left of the date to see the data from the previous day and the arrow to the right of the date to return to the present day.
  • Page 41 5. APPLICATION Salt Temp Energy Pump Salt Temp Energy Pump Salt Temp Energy Pump 00:00 07:00 00:00 07:00 2024/06/10 2024/06/10 2024/06/10 Salt Temp Energy Pump Salt Temp Energy Pump 00:00 07:00 00:00 07:00 2024/06/10 2024/06/10 EN | 89...

  • Page 42: Maintenance

    5. MAINTENANCE 1. Entretien général Periodic maintenance is very important for long-term operation. These operations must be carried out systematically and meticulously, following the advice below. • Periodically check the level of the tank containing the pH-minus solution, to prevent the dosing pump from running empty. •...

  • Page 43: Wintering

    5. MAINTENANCE Procedure :  1. Cut off all power and close the return valves as appropriate. 2. Disconnect the transformer cable. 3. Unscrew the threaded nuts around the PVC fittings that connect the cell to the  pipes. 4. Empty the residual water (let it flow into a container to put it back in the pool). 5. Remove the cell completely from the union fittings. DO NOT pull or carry the cell  by its cable. 6. Using a cleaning cap (e.g. ref. CL-TSLCAP), plug one end and hold the cell in a verti- cal position, cap down. 7. Pour the descaler directly into the cell until it covers all the plates. 8.

  • Page 44: Replacing The Dosing Pump Tube

    When you want to store the pump (in winter for example) you have to protect the peristaltic hose. It is recommended to dose clean water to avoid the chemical attack of 5. MAINTENANCE the hose when the pump is stored. Rotate the roller holder in clockwise sense to move the pump to the position of the figure in fact it is recommended to not leave pressed the hose near the suction part.

  • Page 45: Dépannage

    6. DÉPANNAGE In case of green water (coming out of wintering, very high temperature), the electrolyser will not be able to catch up with the water. A one-off addition of chlorine tablets may be necessary. To do this, do not put the chlorine directly into the skimmer, but rather into a floating diffuser.

  • Page 46: Diagnosis And Resolutions

    6. DÉPANNAGE 2. Diagnosis and resolutions Your controller is equipped with a self-diagnosis system for faults and regular mainte- nance tasks. Please refer to the table opposite for more information. Code Error Solution Turn off power. Check wiring/temp. Check the water temperature limits (min/max). The normal ope- rating range for water temperature is between 10°C and 45°C. If your pool water temperature is < 10°C, consider winterizing your product.
  • Page 47 6. DÉPANNAGE Code Error Solution Check the pump wiring. Check that the suction and discharge pipes do not contain impu- rities. Impurities can damage the pump body pipe and cause an anomaly in the discharge. Check the condition of the pump filter. A clogged filter can  cause a decrease in flow. Add salt. The normal operating range for salt concentration is 2700-4500 ppm.
  • Page 48 6. DÉPANNAGE Code Error Solution Restart the device. Calibrate the pH/ORP sensor (3 months/time) Electrode set replacement check (6 months/time) Electrode set replacement check (accumulated 10,000 hours) Peristaltic pump hose replacement check (cumulative 12 months) Peristaltic pump replacement check (800 cumulative hours) 96 | EN...

  • Page 49: Warranty

    7. WARRANTY Poolstar warrants to the original owner against defects in materials and workmanship of the ORP Controller for a period of five (5) years or 10,000 hours of operation. Probes are consumable components not covered by the warranty. The date on which the guarantee comes into effect is the date of the last invoice. The guarantee does not apply in the following cases: •...
  • Page 50 Asistencia técnica - Assistenza tecnica - Technische unterstützung - Technische bijstand www.assistance.poolstar.fr c o n t a c t @ p o o l s t a r . f r Poolex is a brand of the group : 03-2025 WWW.POOLEX.FR...
