- Page 1 English 13:1 U LTRA SIDE SAND FILTER INSTALLATION & OPERATION MANUAL Please read carefully and retain for future reference...
- Page 2 These installation instructions are an integral part of the product. They must be given to the installer and retained by the user. If you lose your manual, please refer to www.poolex.fr The indications and warnings contained in this manual must be read carefully and understood, as they provide important information on the safe handling and operation of the filter.
- Page 3 English ТаЫе of contents Packaging ................................... 3 Safety instructions ..............................4 Operating principle ..............................5 lnstallation ................................. 6 Commissioning ................................8 Overview of 6-way valve functions ........................... 9 Practical tips ................................10 External filter cleaning ............................10 Wintering ................................10 TrouЫeshooting and maintenance .........................
- Page 4 English Safety instructions Installation and maintenance of upstream electrical parts must be carried out by a professional electrician. Otherwise, there is a risk of electrocution, serious injury, property damage and even life-threatening consequences. Before any maintenance or operation, make sure that all machines, especially the circulation pump, are de energized so that the filter is no longer under pressure: Never operate the 6-way valve while the pump is running.
-
Page 5: Operating Principle
English Operating principle Your pool filter is the main component of your technical room, ensuring clean, clear water, followed by the chemical treatment elements. To achieve this, the filter must contain a filter media, which may be sand or glass. This filter media enables the mechanical elimination of all waste, larger than the filtration fineness of the media used, suspended in the water and introduced by nature or by swimmers. -
Page 6: Installation
Diameter B Valve Max. flow Model required (kg) required (kg) swimmi {m3/h) (mm) (mm) fittings ng pool {m')* PF-ULT500S 1"1/2 PF-UL T600S 1"1/2 PF-ULT675S 2" PF-ULT775S 2" 23,5 PF-ULT875S 2" 30,5 * Approximation based on a filtration time of approximately 6 hours. -
Page 7: Installation Steps
English Installation steps Valve assemblyFilter assembly Assembling the filter and its components : 1. Use PVC fitting adhesive to glue the union to the end of the 6-way valve's lower elbow tube. 2. Place the union nut on the elbow tube before gluing. 3. - Page 8 English Go to service WASHING 1. Check that the filter pump is not powered. If necessary, switch it off at the control panel. SEWAGE 2. Press the handle on the 6-way valve and turn it to the WASH position. If necessary, check that the valve installed on the drain pipe is in the open position, and open it if necessary.
- Page 9 English Reminder of the different functions of the 6 -way valve & To avoid damaging the multiway valve seal, always press the handle before turning it, and always turn it clockwise. POSITIONS FONCTIONS FILTRATION Permet de filtrer l'eau de la piscine (position normale) LAVAGE Permet de nettoyer le filtre en inversant le flux dans le filtre RINCAGE...
- Page 10 English Practical tips Your pool filter is the main component of your equipment room, ensuring clean, clear water. Next come the chemical treatment elements. To achieve this, the filter must contain a filter media, which may be sand or glass. This filter media enables the mechanical elimination of all waste, larger than the filtration fineness of the media used, suspended in the water and introduced by nature or man.
- Page 11 English Troubleshooting and maintenance To avoid any accidents, it is essential to de-energize the circulation pump and reduce the filter pressure using the air bleed screw. To avoid damaging the multiway valve seal, always press down on the handle before turning it, and always turn it clockwise.
- Page 12 English Exploded view and filter parts Code Description f--- -- � � !rnl 89010701 Drain plug with O-ring C!_jf----------,® • >-- --- - ® 06011032 Stainless steel pressure gauge, vertical outlet, 40psi/2.7bars ,,.. � - -----, E190109 Threaded/threaded adapter for pressure gauge/purge screw ii!: !!!!! 01201022...
- Page 13 English Exploded views and spare parts for valves 1"1/2 valve Poignee de vanne Description Insert poignee Rondelle poignee Vis et ecrou M6x30 Couvercle vanne 6 voies 1"1/2 {Noir) Joint boisseau de vanne Rondelle boisseau �_,.(3) Joint torique de couvercle Ressort Boisseau de vanne 1"1/2 Joint etoile �...
-
Page 14: Warranty
English Warranty Poolstar warrants to the original owner that the Poolex ULTRA SIDE Filter will Ье free from defects in materials and workmanship for а period of ten (10) years for the tank and three (3) years for all other parts except wear parts (gaskets and strainers).
