- Page 1 E65T GbS ORIGINAL INSTRUCTIONS www.mahlkoenig.com...
-
Page 2: Table Of Contents
Coffee grinder Contents Overview......3 Adding the coffee beans ....18 Scope of delivery /parts..6 Changing the coffee bean type ..18 General information .... .7 Using the grinder. -
Page 3: Overview
E65T GbS | EN Overview All illustrations are examples. Minor details of your grinder may differ. A ... - Page 4 Coffee grinder B C ...
- Page 5 E65T GbS | EN D E F G ...
-
Page 6: Scope Of Delivery /Parts
Coffee grinder Scope of delivery /parts No. Name Bean hopper (with lid) Controller USB port On/off switch Power cable (with power plug) Release button (thermal overcurrent circuit-breaker) Screws for adjusting the portafilter support (left and right) Collecting tray Portafilter support Portafilter intake Spout Display Clip for the type of bean used... -
Page 7: General Information
In addition to these original instructions, a software manual is available which contains detailed information on the operating software of the grinder. You will find the software manual online via the following link: https://hemro.net/E65T_GbS_Software_Manual * The model designation is derived from the grinder’s specifics: E = espresso grinder, 65 = diameter of the grinding disks (65 mm),... -
Page 8: Explanation Of Symbols Used
Coffee grinder Explanation of symbols used The following symbols and signal words are used in these original instructions, on the grinder, or on the packaging. WARNING! This signal word/symbol indicates a moderate risk, which, if not avoided, can lead to death or serious injury. CAUTION! This signal word/symbol indicates a low risk, which, if not avoided, can lead to minor or moderate injury. -
Page 9: Safety
E65T GbS | EN Safety Intended use The grinder is suitable exclusively for grinding whole roasted coffee beans. Do not use the grinder to grind other products or objects. The grinder is specified for use in the commercial sector, e.g. in commercial enterprises, restaurant kitchens, canteens and hospitals, but not for continuous mass production (continuous operation). - Page 10 Coffee grinder – Do not operate the grinder above an altitude of 2,000 meters (approx. 6562 feet). – Do not immerse the grinder, the power cable or the power plug in water or any other liquids. – Do not clean the grinder with a water jet. –...
- Page 11 E65T GbS | EN – The grinder is not intended for use by children or persons with reduced physical, sensory, or mental capabilities or with a lack of experience and knowledge. Children may not play with the grinder. – Do not leave the grinder unsupervised when it is in operation. –...
-
Page 12: Functioning Of The Grinder
Coffee grinder Functioning of the grinder Grinding according to a recipe The grinder is primarily designed for grinding according to recipe. You can define up to six different recipes . When defining the recipes, you determine specifics such as the portion size and grinding degree (see p. 13 “Recipe specifics“). -
Page 13: Recipe Specifics
E65T GbS | EN Recipe specifics You define the following recipe specifics for each recipe: • Configuration mode: see p. 13 “Configuration modes and portion size“ • Portion size: • Recipe name: e.g. single portion, double portion. • Recipe symbol: is shown in the selection. •... -
Page 14: Grind-By-Sync
Coffee grinder Grind-by-Sync The grinder is equipped with Grind-by-Sync technology which enables wireless communication between the grinder and the espresso machine.* With Grind-by-Sync, espressos with identical specifications can be reproduced at different locations by anyone who operates the appliances. The operator does not have to make any manual adjustments, since the intelligent algorithm precisely controls the distance between the grinding discs, i.e. -
Page 15: Commissioning
E65T GbS | EN Commissioning Checking the grinder and scope of delivery NOTE! Risk of damage! If you do not take care when opening the packaging with a sharp object (e.g. a knife) or you do not handle the grinder correctly when lifting it out of the packaging, the grinder may be damaged. -
Page 16: Basic Handling
Coffee grinder Basic handling Inserting/removing the hopper You require a slot screwdriver for screwing the securing screw for the bean hopper in and out (not supplied). Inserting the hopper 1. Ensure that the grinder is switched off (on/off switch (4) in the 0 position). 2. -
Page 17: Setting The Portafilter Support And Spout
E65T GbS | EN Setting the portafilter support and spout You will need a slot screwdriver to adjust the portafilter support (not supplied). Adjust the portafilter support (9) to the size of the portafilter of your coffee machine (see Fig. C): 1. Ensure that the grinder is switched off (on/off switch (4) in the 0 position). 2. -
Page 18: Adding The Coffee Beans
Coffee grinder Adding the coffee beans 1. Remove the lid from the bean hopper (1). 2. Pour whole roasted coffee beans into the bean hopper from above. The maximum fill amount should be approx. 1 cm below the edge of the bean hopper. The minimum filling quantity should be approx. -
Page 19: Using The Grinder
E65T GbS | EN Using the grinder NOTE! Risk of overheating! Exceeding the maximum permissible operating cycle can cause the grinder to overheat. – Do not exceed the maximum operating cycle (see p. 29 “Technical data“). – Observe the recommended break when the maximum permissible operating cycle is reached (see p. 29 “Technical data“). -
Page 20: Emptying The Grinder
Coffee grinder 2. Push the portafilter all the way in between the portafilter intake (10) and the portafilter support (9) and release the portafilter. The grinder automatically starts grinding the selected recipe. The increasing grinding time is shown on the display (12) during the grinding process. -
Page 21: Using The Main Menu / Carrying Out Settings
E65T GbS | EN The suspended grinding process is continued automatically until the grinding time has elapsed. Press the controller (2) if you do not wish to continue the grinding process. The display jumps directly to the selected recipe and the previously suspended time is deleted. -
Page 22: Cleaning
Coffee grinder Cleaning CAUTION! Risk of injury! The grinder can fall over and cause injury when it is being moved. – Always place the grinder on a stable surface that will not tilt. – Ask another person for help if the grinder is too heavy. NOTE! Risk of short-circuit! Water penetrating the grinder can cause a short-circuit. -
Page 23: Cleaning The Casing
E65T GbS | EN 3. Clean the installation surface and the underside of the grinder with a damp cloth and dry the surfaces. The surfaces must be dry and free of oil and grease. 4. Place the grinder back onto the cleaned surface. Cleaning the casing 1. -
Page 24: Cleaning The Hopper
Coffee grinder Cleaning the hopper The bean hopper must be cleaned daily to remove any coffee oil residue, which can have a negative effect on the taste. 1. Remove the bean hopper (1) from the grinder (see p. 16 “Removing the hopper“). -
Page 25: Troubleshooting
E65T GbS | EN 3. Remove any excess grinder cleaner from the bean hopper intake (15) and make sure that the seal ring (14) is correctly inserted in the bean hopper intake (15) and is lying flat (see Fig. B). 4. Reinsert the bean hopper and fix it with the securing screw (16) (see p. 16 “Inserting the hopper“). - Page 26 Coffee grinder Problem Cause Solution The grinder • The grinding » Set the coarsest grinding degree is humming mechanism is (= highest possible µm value) and but not blocked. initiate the grinding process. The grinding. grinder will free itself. Then reset the grinding degree to the desired µm value during operation.
- Page 27 E65T GbS | EN Problem Cause Solution The grinder • Coffee beans have » Clean the grinding mechanism does not formed a bridge (see p. 24 “Cleaning the grinding grind con- in upstream of the mechanism“). tinuously or grinder inlet. The the grinder coffee beans are suspends not sliding down.
-
Page 28: Eu Declaration Of Conformity
EU Declaration of Conformity Hemro International AG hereby declares that the grinder complies with Directive 2014/53/EU and further relevant provisions on obtaining CE marking*. The full text of the EU Declaration of Conformity is available at the following URL: www.mahlkoenig.com. -
Page 29: Technical Data
E65T GbS | EN Technical data Model: E65T GbS Voltage | frequency | phase | nominal power: 100 V | 50/60 Hz | 1~ 110–127 V | 60 Hz | 1~ 220–240 V | 50/60 Hz | 1~ Protection type: IPX1 Protection class: Back-up fuse: 16 A-slow/15 A Idle speed 50 Hz: 1400 rpm 60 Hz: 1700 rpm Noise emission (during grinding): 70 dBA Grinding capacity: 3–4 g / ... -
Page 30: Disposal
Mahlkönig products. The customer service department can answer any questions you may have regarding repair and maintenance of your product or spare parts. Blown-up drawings and information about spare parts are also available https://hemro.net/ https://hemro.net/ E65T_GbS_Product E65T_GbS_Instruction_Manual... -
Page 31: Optional Accessories
E65T GbS on the Mahlkönig YouTube channel. » Scan the QR code below to go directly to the YouTube channel with the videos about the E65T GbS: https://hemro.net/E65TGbS__Service_PlaylistYouTube Optional accessories Optional accessories are available for this grinder, including the following parts: •... - Page 32 Hemro International AG Thurgauerstrasse 80 | 8050 Zurich, Switzerland T: +41 44 864 18 00 | F: +41 44 864 18 01 info@hemrogroup.com | www.hemrogroup.com...
