E80 SUPREME
INSTRUCTION MANUAL
www.mahlkoenig.de

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MAHLKONIG E80 SUPREME and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for HEMRO MAHLKONIG E80 SUPREME

Summary of Contents for HEMRO MAHLKONIG E80 SUPREME

  • Page 1 E80 SUPREME INSTRUCTION MANUAL www.mahlkoenig.de...

  • Page 2: Overview

    ESPRESSO GRINDER Overview...
  • Page 3 E80 SUPREME | EN...
  • Page 4 ESPRESSO GRINDER...
  • Page 5 E80 SUPREME | EN...
  • Page 6 ESPRESSO GRINDER...
  • Page 7 E80 SUPREME | EN...
  • Page 8 ESPRESSO GRINDER...
  • Page 9 E80 SUPREME | EN...

  • Page 10: Scope Of Delivery

    ESPRESSO GRINDER Scope of delivery Designa on Designa on Bean hopper (with lid) Grinder lid Bean hopper intake Screws to the fi xed burr Controller Screws to the rotary burr Grinding degree lock Rotary burr On/Off switch Locking screws for the fi x burr fl...

  • Page 11: Table Of Contents

    E80 SUPREME | EN Contents Using the main menu ..26 Overview ......2 Display/naviga on symbols ..26 Scope of delivery ....10 Accessing and leaving General ......12 the main menu......27 Reading and retaining the opera ng Cleaning ......

  • Page 12: General

    ESPRESSO GRINDER General Reading and retaining the opera ng manual Before you start using the E80 SUPREME espresso grinder, carefully read through this opera ng manual and the safety informa on. Only then will you be able to use the E80 SUPREME espresso grinder safely and without danger.
  • Page 13 E80 SUPREME | EN This symbol provides you with important informa on concerning opera on or handling. Declara on of Conformity: Products marked with this symbol fulfi l all applicable community provisions of the European Economic Area. ETL Listed seal of approval: Products marked with this symbol meet the requirements of electrical product safety in the United States of America.

  • Page 14: Safety

    ESPRESSO GRINDER Safety Intended use The grinder is only suitable for grinding whole roast espresso beans. Do not use the grinder to grind other products or objects. The grinder is intended for commercial use but not for con nuous mass produc on.
  • Page 15 E80 SUPREME | EN – Install the grinder only in loca ons where handling of the grind- er can be supervised by trained personnel. – Do not operate the grinder above an al tude of 2000 metres. – Do not immerse the grinder or the power cable/mains plug in water or any other liquids.
  • Page 16 ESPRESSO GRINDER WARNING! Danger for children and persons with reduced physical, sensory or mental capaci es (e.g. some disabled persons, older persons with limited physical and mental abili es) or a lack of experience and knowledge (e.g. older children). – The grinder is not intended for use by children or people with limited physical, sensory or mental abili es or a lack of experi- ence and knowledge.

  • Page 17: Before Using For The Fi Rst Me

    E80 SUPREME | EN Before using for the fi rst me Func oning and basic se ngs This grinder has a Disc Distance Detec on (DDD) func on, which enables the grinding degree to be set based on the distance between the burrs. The quan ty of ground coff...

  • Page 18: Se Ng Up The Grinder And Inser Ng The Bean Hopper

    ESPRESSO GRINDER Please note that the grinder is subject to an extensive func onal test before delivery and may therefore s ll contain coff ee pow- der residue. Se ng up the grinder and inser ng the bean hopper You will need a fl at-head screwdriver (not supplied) for fi xing the bean hopper.

  • Page 19: Se Ng Up The Portafi Lter Support And Spout

    E80 SUPREME | EN Se ng up the portafi lter support and spout You will need a fl at-head screwdriver to adjust the portafi lter support (not included in the scope of delivery). Adjust the portafi lter support (10) to the size of your espresso machine’s portafi...

  • Page 20: Opera On

    ESPRESSO GRINDER Opera on NOTE! Danger of overhea ng! Exceeding the maximum permissible opera ng cycle can cause the grinder to overheat. – Do not exceed the maximum opera ng cycle (see the sec on “Technical data”). – Observe the recommended pause when the maximum permissi- ble opera ng cycle is reached (see the sec on Technical data “...

  • Page 21: Adding Espresso Beans

    E80 SUPREME | EN Adding espresso beans 1. Remove the lid from the bean hopper (1). 2. Pour whole roasted espresso beans into the bean hopper from above. • The maximum fi lling quan ty should be approx. 1 cm below the edge of the bean hopper.

  • Page 22: Selec Ng Recipes

    ESPRESSO GRINDER • Reduce the grinding degree only while the grinder is in opera on. • In order to prevent/eliminate any imbalances in the grinding degree se ng, it is advisable fi rst to set a coarser grinding degree (about one step/unit above the grinding degree re- quired) and then move the grinding degree slider from there down to the fi...

  • Page 23: Star Ng Grinding

    E80 SUPREME | EN Star ng grinding Grinding according to a recipe 1. Select the desired recipe by turning the controller (3) (see the “Selec ng recipes” chapter). 2. Insert the portafi lter between the portafi lter intake (12) and the portafi l- ter support (10) un l it touches the start bu on (11).

  • Page 24: Interrup Ng Grinding

    ESPRESSO GRINDER Interrup ng grinding Grinding stops automa cally when you remove the portafi lter from the por- tafi lter intake(12) and con nues with grinding when you insert the portafi lter back into the portafi lter support again and press the start bu on (11) . 1.
  • Page 25 E80 SUPREME | EN When placing the bean hopper on, make sure that you place the nose of the bean hopper into the corresponding recess in the bean hopper intake. 7. Push the bean hopper down into the bean hopper intake and turn the bean hopper clockwise to fi...

  • Page 26: Using The Main Menu

    ESPRESSO GRINDER Using the main menu You can use the main menu to call up device data and to change individual se ngs. You will fi nd precise instruc ons on how to use the grinder so - ware in the enclosed so ware instruc ons. Display/naviga on symbols Symbol Meaning...

  • Page 27: Accessing And Leaving The Main Menu

    E80 SUPREME | EN Accessing and leaving the main menu 1. Press the controller (3) 2 mes to call up the main menu on the dis- play (14). 2. Turn the controller to select the desired menu item (see chapter on “Dis- play/naviga on symbols”).

  • Page 28: Cleaning

    ESPRESSO GRINDER Cleaning CAUTION! Risk of injury! When being moved the grinder can fall and cause injury. – Place the grinder on a stable, fl at surface so that it cannot wob- ble. – Ask another person for help if the grinder is too heavy. NOTE! Risk of short-circuit! Water entering the grinder can cause a short-circuit.

  • Page 29: Cleaning The Grinder Installa On Surface

    E80 SUPREME | EN Cleaning the grinder installa on surface 1. Switch off the grinder (On/Off switch (5) to “0”) and remove the power plug from the socket. 2. Li the grinder by the casing using both hands and place it onto a clean surface.

  • Page 30: Cleaning The Bean Hopper

    ESPRESSO GRINDER Cleaning the bean hopper The bean hopper must be cleaned daily to remove any coff ee oil residue, as this can have a detrimental eff ect on the taste. 1. Lock the bean hopper (1) by pushing in the slider (18). 2.

  • Page 31: Cleaning The Grinding Mechanism With Grindz Tm

    E80 SUPREME | EN Cleaning the grinding mechanism with GRINDZ • The manufacturer recommends using GRINDZ grinder cleaner. For more informa on about GRINDZ , visit www.mahlkoenig.de. • The grinding mechanism should be cleaned every 2–5 days. 1. Lock the bean hopper (1) by pushing in the slider (18). 2.

  • Page 32: Cleaning The Grinding Mechanism Manually

    ESPRESSO GRINDER Cleaning the grinding mechanism manually • The grinding mechanism should be cleaned every 2–5 days. • Manual cleaning is an alterna ve to cleaning the grinding mechanism with GRINDZ • Wear gloves when cleaning the grinding mechanism manual- •...

  • Page 33: Cleaning The Fl Apper

    E80 SUPREME | EN Cleaning the fl apper The fl apper should be cleaned every 2–5 days. 1. Remove the grinder lid (25), proceed as described in chapter “Cleaning the grinding mechanism manually” steps 1–4. 2. Remove the fl apper (33) from the recess in the grinder. 3.

  • Page 34: Adjus Ng The Burrs

    ESPRESSO GRINDER recess in the removal tool slightly off -centred beneath the burr. Guide the removal tool into the centre of the burr and remove the burr by li ing it upwards. 5. Remove the residual coff ee grounds from the grinding chamber using a handheld vacuum cleaner.

  • Page 35: Changing The Fl Apper

    E80 SUPREME | EN The marking on the intermediate plate (41, 42) and the deepest groove of the marking on the adjustment ring (37, 38) must lie levelly on top of one another (see Fig. M and N). Push the adjustment ring lock back- wards so that the adjustment ring snaps into the intermediate plate.

  • Page 36: Troubleshoo Ng

    ESPRESSO GRINDER Troubleshoo ng Fault Cause Remedy  Insert the power plug into a properly • The power The grinder is plug is not installed socket. not grinding, plugged into a the display is socket. not lit up.  Insert the bean hopper (see chapter •...
  • Page 37 E80 SUPREME | EN Fault Cause Remedy  Release the lock on the grind adjust- The grinder is • The grinding humming but mechanism is ment and set the grinding degree to not grinding. clogged. “10”. Start the grinding process. The grinder clears itself.
  • Page 38 ESPRESSO GRINDER Fault Cause Remedy  Contact your service partner The grinder • The start but- does not ton is faulty. (see the sec on “Maintenance and grind con- service”). nuously or the grinding process stops intermi ently.  Remove the spout or clean the spout The grinder’s •...
  • Page 39 E80 SUPREME | EN Fault Cause Remedy  Align the spout correctly with the por- The grinder • The spout is does not not correctly tafi lter used. deposit the aligned with grounds into the portafi lter. the centre of the inserted portafi...

  • Page 40: Technical Data

    ESPRESSO GRINDER Technical data Model: E80 Supreme Voltage/frequency: 100 V; 50/60 Hz 110–127 V; 60 Hz 220–240 V; 50/60 Hz Protec on type: IPX1 Protec on class: Fuse: 16 A-slow/15 A Idle speed: 50 Hz: 1 400 rpm 60 Hz: 1 700 rpm Sound emission value (during grinding):...

  • Page 41: Disposal

    E80 SUPREME | EN Disposal Disposing of the packaging Dispose of the packaging by correctly sor ng the recyclable ma- terials. Dispose of card and cardboard as waste paper, and fi lm as recyclable materials. Disposing of the grinder Old appliances may not be thrown into the commercial/domes c waste! If you can no longer use your grinder, you are legally obliged as a user to dispose of old appliances separately from commercial/do-...
  • Page 42 ESPRESSO GRINDER...
  • Page 43 E80 SUPREME | EN...
  • Page 44 Hemro International AG Länggenstrasse 34 | 8184 Bachenbülach, Switzerland T: +41 44 864 18 00 | F: +41 44 864 18 01 info@hemrogroup.com | www.hemrogroup.com...
