Sealey SA703 Instructions

PARTS LIST FOR:
ITEM PART NO. DESCRIPTION
01. SA703/01 MOTOR HOUSING
02. SA703/02 SET SCREW
03. SA703/03 EXHAUST HANDLE
04. SA703/04 HANDLE GRIP (EXHAUST)
05. SA703/05 EXHAUST DEFLECTOR
06. SA703/06 SPRING PIN
07. SA703/07 THROTTLE LEVER
08. SA703/08 HANDLE GRIP (INLET)
09. SA703/09 INLET HANDLE
10. SA703/10 AIR INLET BUSHING
11. SA703/11 BEARING CAP
13. SA703/13 REAR END PLATE
14. SA703/14 ROTOR BLADE
15. SA703/15 ROTOR
16. SA703/16 SPRING PIN
17. SA703/17 CYLINDER
18. SA703/18 FRONT END PLATE
19. SA703/19 BALL BEARING
20. SA703/20 SPRING PIN
21. SA703/21 COLLAR
22. SA703/22 CLAMP NUT
23. SA703/23 OIL SEAL (V-MODEL)
NOTE: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component
parts without prior notice. IMPORTANT: No liability is accepted for incorrect use of this equipment. WARRANTY: Guarantee is 12
months from purchase date, proof of which will be required for any claim.
Sole UK Distributor, Sealey Group, Bury St. Edmunds, Suffolk.
01284 757500
180mm VERTICAL
AIR POLISHER
SA703
MODEL:
ITEM PART NO. DESCRIPTION
24. SA703/24 BALL BEARING
26. SA703/26 INTERNAL GEAR
27. SA703/27 NEEDLE ROLLER
28. SA703/28 NEEDLE ROLLER
29. SA703/29 PLANET GEAR
30. SA703/30 BALL BEARING
32. SA703/32 PLANET CAGE
33. SA703/33 BALL BEARING
34. SA703/34 O-RING
35. SA703/35 VALVE STEM
36. SA703/36 O-RING
37. SA703/37 VALVE SPRING
38. SA703/38 AIR REGULATOR
39. SA703/39 O-RING
40. SA703/40 O-RING
41. SA703/41 VALVE SCREW
42. SA703/42 PAD
43. SA703/43 PAD NUT
45. SA703/45 BUSHING
47. SA703/47 WRENCH
48. SA703/48 WRENCH
E-mail: sales@sealey.co.uk
01284 703534
Web: www.sealey.co.uk
INSTRUCTIONS FOR :
180mm VERTICAL AIR POLISHER
SA703
MODEL:
Thank you for purchasing a Sealey Product. Manufactured to a high standard this product will, if used according to these instructions
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS,
WARNINGS AND CAUTIONS. USE THIS PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH
IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR PERSONAL INJURY AND WILL INVALIDATE
THE WARRANTY. PLEASE KEEP INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY INSTRUCTIONS
p WARNING! Ensure Health & Safety, local authority, and general workshop practice regulations are adhered to
when using this equipment.
p WARNING! Disconnect from air supply before changing accessories or servicing.
3 Maintain the polisher in good condition (use an authorised service agent).
3 Replace or repair damaged parts. Use genuine parts only. Unauthorised parts may be dangerous and will
invalidate the warranty.
3 Use in a suitable, clean and tidy work area, free from unrelated materials. Ensure that there is adequate lighting.
3 Before each use check pad for condition. If worn or damaged replace immediately.
p WARNING! Always wear approved eye or face and hand protection when operating the polisher.
3 Use face, dust, or respiratory protection in accordance with COSHH regulations.
3 Noise level may exceed 85dB - wear safety ear defenders.
3 Remove ill fitting clothing. Remove ties, watches, rings, other loose jewellery and contain and/or tie back long hair.
3 Wear appropriate protective clothing and keep hands and body clear of pad.
3 Maintain correct balance and footing. Ensure that the floor is not slippery and wear non-slip shoes.
3 Keep children and unauthorised persons away from the work area.
3 Ensure workpiece is secure before operating the polisher. Never hold a workpiece by hand.
3 Avoid unintentional starting.
p WARNING! Ensure that correct air pressure is maintained and not
exceeded. Recommended pressure is 90psi.
3 Keep air hose away from heat, oil and sharp edges.
3 Check air hose for wear before each use and ensure that all
connections are secure.
3 Prolonged exposure to vibration from this polisher poses a health
risk. It is the owner’s responsibility to correctly assess the potential
hazard and issue guidelines for safe periods of use and offer
suitable protective equipment.
7 DO NOT use an attachment which has a speed rating less than the
speed rating of the polisher.
7 DO NOT use the polisher for a task it is not designed to perform.
7 DO NOT operate polisher if any parts are damaged or missing as this may cause
failure and/or personal injury.
7 DO NOT carry the polisher by the hose, or yank the hose from the air supply.
7 DO NOT force, or apply heavy pressure to the polisher, let the polisher do the work.
7 DO NOT place attachments close to your face and do not point at other persons or animals.
7 DO NOT operate polisher when you are tired or under the influence of alcohol, drugs or intoxicating medication.
7 DO NOT carry the polisher with your finger on the power lever.
7 DO NOT direct air from the air hose at yourself or others.
3 When not in use, disconnect from the air supply and store in a safe, dry, childproof location.
SA703 - 1 - 211004
