TORQUE MASTER POWER
COMPACT TILE CUTTER
Safety and Operating Manual
103402NDE
Safety First
Read manual before use. Keep hands, arms and face clear
of blade whilst in use. Always have safety guard in place
when machine is switched on at mains. Always wear Vitrex
Protective Equipment when using hand or power tools.
A QUALITY BRAND OF

Advertisement

loading
Need help?

Need help?

Do you have a question about the Vitrex 103402NDE and is the answer not in the manual?

Questions and answers

Related Manuals for QEP Vitrex 103402NDE

Summary of Contents for QEP Vitrex 103402NDE

  • Page 1 TORQUE MASTER POWER COMPACT TILE CUTTER Safety and Operating Manual 103402NDE Safety First Read manual before use. Keep hands, arms and face clear of blade whilst in use. Always have safety guard in place when machine is switched on at mains. Always wear Vitrex Protective Equipment when using hand or power tools.
  • Page 2 TORQUE MASTER POWER COMPACT TILE CUTTER Safety and Operating Manual Contents Safety Instructions ....................................Assembly and Operating Instructions ..........................Machine Specifications ..................................Care, Maintenance and Warranty .............................. Tel: +44 (0) 1283 245 430 • www.vitrex.co.uk...

  • Page 3: Safety Instructions

    TORQUE MASTER POWER COMPACT TILE CUTTER Safety Instructions SWITCH OFF THE MACHINE IMMEDIATELY IN CASE This manual must be kept in a safe place so that the information that it contains is always available. This operating manual must accompany the equipment if it is transferred to somebody else. 1.

  • Page 4: Straight Cuts

    Assembly Operating Instructions STRAIGHT CUTS To fit or replace the cutting blade, first carefully lift the hinged section of Place the rip guide on the table top and line up with the measurement the table top. Remove screw from splashboard and remove the splash- graduations on either edge to the required size.
  • Page 5 TORQUE MASTER POWER COMPACT TILE CUTTER ANGULAR CUTS MITRE CUTS Press the mitre guide into place on the rip guide. For mitre cuts, raise the hinged section of the table to the required angle (22.5º or 45º). Slacken the diamond shaped knob and set the required angle of cut. Locate the appropriate lugs into the slots provided on the inside edge of the reservoir.

  • Page 6: Machine Specifications

    Machine Specifications 103402NDE 230V 50Hz Power Supply Motor Hi Torque Geared Motor RPM (no load) 4600 rpm Maximum Depth of Cut (new blade) 25mm Maximum Depth of 45º Cut (new blade) 17mm Mitre Cutting Angle 22.5º / 45º Cutting Angles 0º...

  • Page 7: Care, Maintenance And Warranty

    The above guarantee is only valid within the UK and does not affect your statutory rights. The guarantor is QEP Co. UK Ltd., The Maltsters, Wetmore Road, Burton upon Trent, DE14 1LS (Registered No. 04988177 England) Tel: +44 (0) 1283 245 430 • www.vitrex.co.uk...
  • Page 8 QEP Co. UK Ltd., The Maltsters, Wetmore Road, Burton upon Trent, DE14 1LS PRCI SAS - Groupe QEP, Avenue du Moulin De La Jasse, BP 30, 34750 Villeneuve Les Maguelone, France Tel: +44 (0) 1283 245 430 • www.vitrex.co.uk...
