- Page 1 Concord ASSEMBLY INSTRUCTIONS Light Post w/ Planter Box (19 7/8" W x 103 1/2" H) ZP19081 60 MIN Approximate assembly time Want to see a video on how to assemble this product? Scan the QR code www.zippity-outdoor.com VER. 121824...
- Page 2 To better help you, Your product number (ZP19081) please have the following Your original product box NEED ASSEMBLY HELP? If you are having problems with assembly or installation of this product, please contact at: 704-892-5222 / 877-234-6196 support@zippity-outdoor.com NEED TO RETURN?
- Page 3 18 in 18 in 103 1/2 in Top View Planter Depth: 5" or 9.5" (See Steps 6a/6b for details) Planter Volume: 0.9 cu ft or 1.75 cu ft (See Steps 6a/6b for details) 22 1/4 in 19 7/8 in...
- Page 4 LAY OUT MATERIALS We recommend 2 people for a smoother Tools required for a smoother installation assembly. experience. Power Drill with Phillips Bit Level Recommended: For optimal stability, you will need to fill the lower chamber with roughly 50 lbs of weight. Sand bags or small rocks are recommended.
- Page 5 LAY OUT MATERIALS LIGHT POST Corner Post (4) Board (12) 2 1/8" x 2 1/8" x 22" 5/8 " x 4 1/2" x 17 1/2" Floor Support Board (4) Top Board (4) 1 1/2 " x 4 1/2" x 17 1/2" 5/8"...
- Page 6 LAY OUT MATERIALS LIGHT POST Inside Floor Board (4) Outside Floor Board (4) 5/8" x 4 1/2" x 17 3/4" 5/8" x 4 1/2" x 17 3/4" Wooden Post Cap (1) Bottom Light Post (1) 3 1/4" x 3 1/4 " x 1 1/4 " 3"...
-
Page 7: Hardware And Accessories
LAY OUT MATERIALS HARDWARE & ACCESSORIES Post Bracket (2) Hook (1) L-Bracket (4) Post Caps (8) Dowel (2) Spacer (4) - Page 8 LAY OUT MATERIALS HARDWARE & ACCESSORIES 5/8" Self-Tapping Screw 5/8" Round Head Self-Drilling Screw (32) (18) 1 3/8" Countersunk Wood Screw (8) 2" Countersunk Wood Screw (2) 3 3/4" Hex Bolt (6) Spring Lock Washer (6) Nut (6) Flat Washer (12) Nut Wrench (2)
- Page 9 Assemble on box or other smooth surface to prevent scratching Place 2 spacers under your bottom boards (B).
- Page 10 Repeat steps 2-3 to create an additional panel...
- Page 11 Place spacer under your floor support boards (C).
- Page 13 Use this option for a 5" deep planter box. Top support boards should be on the opposite 2 sides as the bottom support boards.
- Page 14 Use this option for a 9.5" deep planter box.
- Page 17 Ensure that bottom post is leveled vertically before placing your screws.
- Page 18 (Recommended) Temporarily remove your end boards for your next step.
- Page 19 Ensure that bottom post is leveled vertically before placing your screws. Secure the lower middle floor boards once your post is level.
- Page 20 Ensure that bracket is secured to both sides of the bottom post.
- Page 21 Return the top end boards.
- Page 22 Hook can be installed anywhere at top of post (I).
- Page 25 Ensure that top post leveled vertically before placing your screws.
- Page 30 Recommended: Before adding soil, fill the bottom chamber of the planter with sandbags, small rocks, or other dense material to maximize the stability of the light post. It is advised to fill the lower chamber with at least 50 lbs of weight. Temporarily remove outer floor boards to fill lower chamber.
- Page 31 144 in Recommended: Light span 12 ft...
- Page 32 6935 Reames Rd. Ste. K. Charlotte, NC 28216 support@zippity-outdoor.com 704-892-5222 877-234-6196 www.zippity-outdoor.com...
