Ouellet OHV Series Instructions

180, 3 Avenue, L'Islet, Quebec, G0R 2C0, CANADA
rd
Tel.: (418) 247-3947, 1-800-463-7043, Fax: (418) 247-7801
www.ouellet.com
INSTRUCTIONS
OHV Series "2 kW to 10 kW"
WARNING
When using electrical appliances, basic precautions should always be taken
to reduce the risk of fire, electrical shock and injury, including the following:
Read carefully these instructions before installation, operation of the heater.
Failure to adhere to the instructions could result in fire, electric shock, serious
personal injury, and death or property damage. Review frequently for continuing
safe operation and instruction of future users, if necessary.
IMPORTANT
INSTRUCTIONS
- Read all instructions before installing or using this heater.
- This heater is hot when in use. To avoid burns, do not let bare skin touch
hot surfaces. Keep combustible materials, like furniture, pillows, bedding,
papers, clothes, and curtains at least 36 in. (915 mm) from the front of
the heater and away from the sides and rear.
- Extreme caution is necessary when any heater is used by or near children or
invalids and whenever the heater is left operating and unattended.
- Do not operate any heater after it malfunctions. Disconnect power at service
panel and have heater inspected by a reputable electrician before reusing.
- To disconnect heater, turn off power to heater circuit at main disconnect panel.
- Do not use outdoors.
- Do not insert or allow foreign objects to enter any ventilation or exhaust
opening as this may cause an electrical shock or fire, or damage the heater.
- To prevent a possible fire, do not block air intakes or exhaust in any way
whatsoever.
- A heater has hot and arcing or sparking parts inside. Do not use it in areas
where gasoline, paint or flammable liquids are used or stored.
- The heater has been designed and certified for ambient heating only. The
maximum ambient operating temperature is 30 °C (86 °F).
- The heater is not designed for use in a humid environment where condensation
may form on the device.
- Use this heater only as described in this manual. Any other use not
recommended by the manufacturer may cause fire, electrical shock, or injury.
- The thermostat should not be considered an infallible device in cases where
maintaining a temperature is considered critical. In these particular cases,
it is imperative to add a monitoring system to avoid the consequences of a
thermostat failure.
- This heater is not approved for use in corrosive atmospheres, wet or very
humid locations such as marine, green house or chemical storage areas.
SAVE THESE INSTRUCTIONS
OPERATING
INSTRUCTIONS
The heater must be properly installed before it is used.
HEATER OPERATION
Fan Delay
Some models (5 kW and less) are designed with a fan delay that
allows the elements to heat-up before the fan turns on, reducing
the "cold blast" effect normally felt with non-fan delayed heaters.
On a call for heat from either the remote (floor level)
thermostat or the unit mounted thermostat the elements
will be energized.
After the elements get warm, a short period of time,
the fan will come on (5 kW and less).
When the thermostat is satisfied the elements will
be deenergized.
The fan will continue to run until the residual heat is
removed from the heater. Then the fan will stop.
Automatic Reset Thermal High Limit
The heater has an automatic reset thermal high limit that will
deenergize the heating elements if the interior temperatures of heater
exceed its setting. The limit will automatically reset when the heater
interior temperatures fall below its setting.
MAINTENANCE
INSTRUCTIONS
The heater motor is permanently lubricated.
Occasional cleaning of the inlet grille will prevent clogging.
Use a vacuum with a brush attachment.
Cleaning should be done while the heater is disconnected
from the main service panel. Wait until the housing and
heating elements cool before performing maintenance.
Any other servicing should be performed by a qualified
technician.
WARRANTY
Please refer to the product sheet at www.ouellet.com.
INS151-200803-09
