Governor System
THIRD DESIGN GCU Basic Electrical Diagram of Electronic Governor System
B+
10
Power
8
12
13
Application Supplied
Speed Control Input
Operation Input Voltage:
0-1 Volts at Idle/9+ Volts at High Speed.
48
GCU
Device
Ground
KohlerEngines.com
Kill Tab (Speed Signal)
Speed Signal
14
Green LED Light
Yellow LED Light
1
DLA Driver
2
Controls
6
7
Ignition Module
2B
2A
1A
1B
DLA
24 690 06 Rev. O
