One Link Cummins PCC2100 GTS Installation Manual

Installation Instructions:
1. Put the generator in stop mode.
2. Disconnect the positive battery terminal.
(Do not reconnect the positive battery
terminal until step 19.)
3. Using the magnetic mounts, mount the
One Link inside of the generator enclosure
close to the controller. (Be sure the
mounting location is away from weather
exposure.)
4. Connect the ring connector on the bare
red wire of the battery wiring harness to the
positive (+) battery terminal.
5. Connect the ring connector on the bare
black wire of the battery wiring harness to
the negative (-) battery terminal.
6. Route the brown
blue wire from the One Link I/O cable to the
battery wiring harness installed in steps 4
and 5.
7. Using one of the included lever wire
connectors, connect the bare
from the battery wiring harness to the
wire and orange
cable.
8. Using one of the included lever wire
connectors, connect the bare
the battery wiring harness to the
from the One Link I/O cable.
wire, orange
black
wire from the One Link I/O
red
1 (888) 366-7886
wire, and
wire
blue
wire from
brown wire
Cummins PCC2100 GTS
Installation Guide
One Link v3/v3b
Panel:
Parts List:
OLM003B
OLSC005
