Domus BLAZE-PRO Series Installation Manual

BLAZE-PRO Series
Specifications
50W*
Power: 20/30/50W
CCT: 3000K/4000K/5500K
Lumen (±5%): 5060/5470/5360lm
Net Weight 0.72kg
Max Projected Area 0.020m
Dimmable: No
Input Voltage: 240V
CRI: ≥70
CCT (Switchable): 3000K- 4000K-5500K
CCT and Power selectable by DIP switch
Use Allen key (5mm) to unscrew
the dip switch CCT and power
selectable waterproof cover.
Note:
-The lamp must be installed by professional electrician
-Ensure the power supply is switched off before fitting this product
2
5500K 4000K 3000K
100W 70W 50W
Toggle the switch to the desired colour
temperature and power. (Please note don't
operate the switch while power is on.)
29-31 Richland St. Kingsgrove. Sydney NSW 2208 Australia
Phone: 02 9554 9600 | Fax: 02 9554 9433
enquiries@domuslighting.com.au | www.domuslighting.com.au
100W*
50/70/100W
3000K/4000K/5500K
10750/12150/11550lm
1.28kg
0.045m
2
IP Rating:
Beam Angle:
Lifespan:
Power Factor:
5500K 4000K 3000K
100W 70W 50W
-Do not touch the lamp when in use
-Keep away from hot steam and corrosive gas
Installation Manual
Date: April 29, 2025 1:44 PM
200W*
100/150/200W
3000K/4000K/5500K
21970/24380/23470lm
2.60kg
0.087m
2
IP66
120º
20,000hrs
≥0.9
Use Allen key (5mm) to tighten screw
on the waterproof ring and cover.
