- Page 1 WALL MOUNTED INTELLIGENT TOILET BeBa_24911 BeBa_26880 • REMOTE CONTROL • IPX4 INGRESS PROTECTION • REAR AND FRONT WASH...
-
Page 2: Table Of Contents
CONTENTS SAFETY INFORMATION UNIT MEASUREMENTS PARTS LIST PRODUCT OVERVIEW BEFORE INSTALLATION INSTALLATION REMOTE CONTROL OPERATION CLEANING AND MAINTENANCE REPLACING THE FILTER DRAINING THE WATER TANK TROUBLESHOOTING SUPPORT BATTERY WARNINGS TECHNICAL SPECIFICATIONS... -
Page 3: Safety Information
SAFETY INFORMATION • This manual must be read and fully understood before installing or using the appliance. • This product must not be operated without a connected water supply. • Installation must be in accordance with all relevant local regulations applicable at the time of installation. -
Page 4: Bathroom Zones
BATHROOM ZONES Zone 0: The interior of the bathtub or shower basin. The area around the bathtub or shower basin up to a height Zone 1: of 2.25m above the floor The area stretching to 0.6m outside the bath or shower and Zone 2: above the bath or shower if over 2.25m... - Page 5 INSTALLATION DIAGRAMS - BeBa_24911 NOTE: All images are solely for illustrational purposes as the item can be subject to continual improvement. All dimensions are in mm.
- Page 6 INSTALLATION DIAGRAMS - BeBa_26880...
-
Page 7: Parts List
PARTS LIST Remote Remote Control Toilet (Batteries Not Included) Holder Electrical Cable Coupler Flow Limiter G3/8” – ½” Flexi Hose Flush Pipe and Seal Stop Valve Filter x2 Waste Pipe and Seal Wall Fixing Rods Wall Fixing Nuts Wall Fixing Washers Side Fixing Bolt Sleeve Wall Cushion TOOLS... -
Page 8: Product Overview
Knife File Adjustable Wrench Wire Strippers 12mm Drill bit Hacksaw Drill PRODUCT OVERVIEW... -
Page 9: Before Installation
BEFORE INSTALLATION Recommended installation area. IMPORTANT! Before commencing installation, the water and electrical supplies should be turned OFF. Please note with your wall mounted back to wall toilet, a Flush Pipe and Waste Pipe are supplied, these may not be required as it will be dependant on the cistern to which the toilet is being connected and the position of the soil stack. -
Page 10: Installation
INSTALLATION INSTRUCTIONS Connect the stop valve to the pipe end, ensuring to fit an adequate seal and tighten using a spanner. Once connected and fully tightened, place a bucket under the stop valve, open the stop valve and flush the pipe for at least 10 seconds to remove any debris in the system. - Page 11 Remove the pipes from the wall and push them fully onto and into the back of the toilet pan, using a ruler mark a line level with the back of the pan. Remove the flush pipe and measure and measure the distance between the two marks, this will be dimension From the end of the flush pipe measure dimension L1 and then add 6mm, cut at this point, as shown below.
- Page 12 Pull the seat from the toilet pan (do not turn this upside down). The threaded bolts should be attached to the frame and screwed inwards until 48mm of thread is left exposed, as shown below. Place the toilet cushion against the wall over the threaded bolts and pipe holes Push the toilet base into position against the wall, ensuring that the waste and flush pipes to the rear engage to create a full...
- Page 13 Pull through the flexi pipe and cable, to allow connection to be made with the seat unit. Push the threaded bolt sleeves over the threaded bolts and into the hole in the pan to prevent the metal of the bolt damaged the ceramic, during use.
- Page 14 Strip the end of the household cable to expose the wires for connection to the coupler. When stripped, tidy the ends and connect to the coupler as shown, ensuring the screws are tightened and the wire ends are fully secured. Carry out the same process for the cable attached to the toilet, then connect the coupler sections together.
- Page 15 When checks are completed and no leaks are found and RCD test is passed, the lid assembly can be re-fitted to the pan, feed the flexi pipe and cables carefully under the pan, so as not to trap the pipe or cable or cause any kinks, which will reduce water flow.
-
Page 16: Remote Control
REMOTE CONTROL Front Wash Rear Wash Dry/ Stop Indicator Lights Decrease Flow Increase Flow/ Massage Retract Nozzle/ Extend Nozzle Night Light Decrease Temperature/ shift Increase Temperature/ Shift FITTING / REPLACING BATTERIES • Different types of batteries or new and used batteries should not be mixed •... -
Page 17: Operation
OPERATION REAR WASH/ FRONT WASH While seated, press the rear wash or front wash button on the remote and the toilet will begin wash mode. Alternatively, the dial on the side of the toilet can be turned clockwise to activate front wash or anticlockwise to activate rear wash. The washing function will run for 3 minutes. -
Page 18: Water Flow
WATER FLOW Change between LOW, MEDIUM or HIGH You can also adjust the water flow using the dial located on the side of the toilet. Turn To adjust the water flow, press the + or the dial clockwise to increase the flow or –... -
Page 19: Indicator Light
AIR DRY MODE When seated, press the Dry button on the remote and air-dry mode will operate for 3 minutes. While the air-dry mode is operating, you can change the following settings: AIR TEMPERATURE ADJUSTMENT Adjust the temperature of the air flow by using the + and - adjust Turn the dial on the side of the seat temperature buttons on the remote. -
Page 20: Night Light
OTHER FEATURES The intelligent toilet comes with other features that improve its ease of use. These can be adjusted when no other function is in operation. NIGHT LIGHT The night light defaults to always on. Alternatively, the night light can be Keep pressing the + or –... - Page 21 REMOTE CONTROL SYNC Step 1 Open the lid and the seat. Turn off the night light using the side control (Refer to the "light Setting") Step 2 Press and hold the STOP button (1) and "-" button (4) at the same time for a few seconds until the first light (5) flashes.
-
Page 22: Cleaning And Maintenance
CLEANING AND MAINTENANCE Daily Remove water drops with a soft lint free cloth to avoid limescale build-up. Weekly Clean all surfaces and corners. Clean the spray nozzle is necessary (see Nozzle cleaning) Monthly Clean the ceramic with low acidic cleaning agents. Every 6 months Replace the filter if required. -
Page 23: Replacing The Filter
REPLACING THE FILTER The filter supplied has a life of 6 months and should be replaced to prevent reduced flow. This can be affected by the water type i.e. Hard Water areas. To replace the filter, you will need to turn off the power supply and the water supply and the seat will need to be removed. -
Page 24: Draining The Water Tank
DRAINING THE WATER TANK The water and power must be cut to the unit before work is started Do not invert the seat. Ensure a water holding container is in place prior to draining Using pliers hold the plug on the tank turn the plug to OPEN and pull out Water will start to drain. After draining is completed, insert the plug and turn to CLOSE. -
Page 25: Troubleshooting
TROUBLESHOOTING Problem Potential cause Suggested action The power supply may not be Ensure the power switch is in the on position and the connected RCD has been reset. The water supply may be Ensure the inlet water valve is in the open position, disconnected and ensure there is adequate water flow to the unit. -
Page 26: Support
2. Something may be covering the Remove the obstructions around the control dial control dial. 3. The night light may be set to Please adjust the night light mode as per "Light ‘Always On’ mode Setting" of operating instructions nozzle goes back after... -
Page 27: Battery Warnings
depositing your equipment. Please contact the local council for details of your local household waste recycling centers. At the time of printing the product contains no substances listed within Annex XIV of the Reach Regulations (EC) 1907/2006. In accordance with Article 59 of the same regulation the following substances are contained within the product at permitted levels: Lead &... -
Page 28: Technical Specifications
TECHNICAL SPECIFICATIONS MODEL BeBa_24911/Beba_26880 ● Rear Wash ● Front Wash ● Oscillating Spray ● Pulsating Spray Wash ● Oscillating and Pulsating Spray Adjustable Water Temperature 5 Steps (Default 3rd) Adjustable Flow Rate 5 Steps (Default 3rd) Adjustable Spray Position 5 Steps (Default 3rd) ●... - Page 29 Wall Mounted Intelligent toilet Model Number: BeBa_24911 / BeBa_26880 Brand: Better Bathrooms Object of Declaration BeBa_24911 and BeBa_26880 Wall Mounted Intelligent toilets The object of the declaration described above is in conformity with the relevant Union harmonisation legislation: Low Voltage Directive 2014/35/EU...
-
Page 30: Declaration Of Performance
Wall Mounted Intelligent toilet Model Number: BeBa_24911/ BeBa_26880 Brand: Better Bathrooms Object of Declaration BeBa_24911 and BeBa_26880 Wall Mounted Intelligent Toilet The object of the declaration described above is in conformity with the relevant Union harmonisation legislation: Construction Product Regulations...
