Page 4
To ensure proper installation, an authorized installer must carry out all installations. Incorrect installation can damage the electrical cabinet. • The VOOL LMC should not be used by Individuals with a lack of experience or knowledge without the supervision of a responsible party. •...
Page 6
EV while avoiding system overloads. About this document Before you start using your LMC, we encourage you to read through this manual carefully. This manual is written to provide you with clear and concise instructions for the safe and efficient use and maintenance of your VOOL LMC.
Page 7
The content of this manual is protected by copyright and other intellectual property laws. The content of this manual may only be copied, modified, reproduced and/or translated with express written permission from VOOL. This manual may only be published, transmitted, displayed or made available to a third party with express written permission from the manufacturer.
Page 9
This ensures the maximum possible charging speeds without overloading the power grid. The lights on the front of the LMC indicate the connection status of the LMC. The LMC can be controlled and monitored with the VOOL Admin portal. The LMC ensures continuous operation even if the network is disconnected, managing loads using locally set parameters in the Admin portal.
Page 10
Risk of shock - Do not insert any foreign objects into the VOOL LMC. • Risk of shock - Do not cut, pierce or otherwise damage the power supply wires. Switch off and do not use the LMC if one or more wires are in any way damaged or exposed. •...
Page 11
2.3.In case of an emergency Always put your own safety and the safety of those around you first. Only when it is safe, switch off the main circuit breaker of the LMC to cut off all power to the LMC.
Page 13
Before installation turn off the power from the fuse box to avoid injury. Install the LMC on a fitting spot on the DIN rail. LMC size is 3,5 modules. Recommended circuit breaker for the LMC is a 6A, 3P, B curve.
Page 14
LMC. If a power meter that supports Modbus protocol is available on-site, and is connected to the same network as LMC, it is possible to use metering data for load management. Contact your local supplier for compatibility.
Page 15
3. Installation 3.4 Connect AC Power Supply 3.4.1 (Three-Phase) Connect Cables to the Designated Connector and Connector to LMC Switch on the LMC and ensure that LEDs light up If any LEDs are unlit, refer to the troubleshooting section in installation manual.
Page 16
3. Installation 3.5 Connecting LMC to Chargers Chargers can be connected to the LMC if they are in the same LAN (local area network) or connected via a CAN connection. 3.5.1 Router VOOL App Bluetooth setup Scenario 1: The Charger(s) and the LMC are in the same LAN connected via Ethernet cables.
Page 17
End resistor Scenario 3: The Charger(s) and the LMC are connected via CAN Using cat 6 cable. System is using only 4th and 5th wire of cat6 cable. Chargers themselves don’t need to be connected to internet and they communicate with our server over can through LMC.
Page 18
Scenario 5: The Charger(s) and the LMC are connected via CAN and LAN. The LMC is connected to the Internet via an Ethernet cable or WiFi and the charger needs to be connected in the same LAN. The last Charger on the CAN line should be equipped with an end resistor to provide reliable communication between the devices.
Page 19
Scan the QR-code or enter the serial number + PIN code which are located on the packaging and on the LMC case. Be sure to connect the devices to the network and add them to the same network as the chargers. Then select which chargers are connected to the LMC from the charger settings.
Page 20
1. Ethernet: Connect an Ethernet cable with Internet connectivity to the Ethernet port on the LMC. (front port) 2. Wifi: After powering up, wait for up to 2 minutes until the LMC creates a Wifi hotspot named ‘LMC ID123456789’ (named after the LMC serial number).
Page 21
3. Installation Autoconfigure If chargers and LMC are connected as shown in the above add all the devices to your site by scanning the QR-s. Then connect all the devices to internet if needed. For CAN connection check if all the cable connections are done in the correct way.
Page 22
Set the size of the building’s main fuse and, if necessary, other settings. • During the installation of the LMC, you must match the current setting with the main fuses’ size and capacity to ensure proper calibration of the DLM system and avoid potential damage.
Page 23
If device is connected online it will appear in the list of devices. Make sure to connect the device(s) online and add them to the same site in the VOOL Portal. Then, select which chargers are connected to LMC on the site setup.
Page 24
Once you have set up the LMC, you are ready to add chargers or link your LMC with existing chargers on the site. 3.10 Install with Previously Installed Current Transformers or Multimeter If a power meter that supports Modbus protocol is available on-site, and is connected to the same network as LMC, it is possible to use metering data for load management.
Page 25
Normal operation. 1000ms OFF LMC application status (LED3) This indicator is connected to processor board (CM4) and will indicate LMC ap- plication status. When system boots, the LED is turned on by hardware, but dimmed (small pull- up current by CM4).
Page 26
For LAN connections check that port LED-s on charger and LMC are lit up. If not check that ethernet cable plugs are made correctly. 3. Make sure the charger and the LMC are in the same local area network. LMC doesn’t create hotspot for wifi configuration.
Page 27
If not check that CAN cable plugs are made correctly. 3. For LAN connections check that RJ45 port LED-s on charger and LMC are lit up. If not check that ethernet cable plugs are made correctly.
Page 28
WARNING • Risk of shock - Do not open the LMC, there are no user-serviceable parts inside. Only qualified technicians should open the LMC for maintenance or repairs. • Risk of shock - Ensure that no water or other liquids enter the LMC.
Page 29
WARNING • Risk of shock - Do not open the LMC, there are no user-serviceable parts inside. Only qualified technicians should open the LMC for maintenance or repairs. • Risk of shock - Ensure that no water or other liquids enter the LMC.
Page 33
8. Warranty Information The VOOL LMC Limited Warranty provides coverage for a period of 5 years (5 years for EU member states) from the date of purchase. The Limited Warranty covers the refund, repair, or necessary replacement of adapters that have manufacturing defects occurring during normal use.
Page 34
If the replacement is necessary, it may be fulfilled with non-original manufacturer’s parts of similar quality. If the costs of repairing or replacing the VOOL LMC exceed its fair market value at the time when the defect was discovered, VOOL will not be responsible for covering such costs.
Page 35
Detailed information about the problem you are experiencing • Details about the attempts you have made to resolve the issue If any disputes or arguments arise between you and VOOL about the VOOL LMC Limited Warranty, Vool will try all possibilities to reach for agreeable resolution.
Page 36
For more information, support, or inquiries, please reach out to us at info@vool.com...
