Page 3
Soovitame enne toote paigaldamist ja kasutamist lugeda läbi terve juhend. Paigaldamise peab läbi viima autoriseeritud paigaldaja. Palun jälgige kõiki kohalikke regulatsioone. Skannige kaasas olev QR-kood, et pääseda juurde kogu kasutusjuhendile teie eelistatud keeles. We recommend to read the entire manual before installing and operating the product. The installation must be carried out by an authorised installer.
Page 4
To ensure proper installation, an authorized installer must carry out all installations. Incorrect installation can damage the electrical cabinet. • The VOOL LMC should not be used by Individuals with a lack of experience or knowledge without the supervision of a responsible party. •...
Page 5
Kad užtikrintumėte optimalias funkcijas ir veikimą, patikrinkite ir įdiekite naujausią programinės aparatinės įrangos versiją. • Ole hyvä ja lue nämä ohjeet ennen kuin asennat tai huollat VOOL Load Management Controlleria (LMC). • Vältä turvallisuussyistä VOOL LMC:n asentamista ja sen käyttöä lähellä palavia, räjähtäviä, voimakkaita tai palavia materiaaleja, kemikaaleja tai höyryjä.
Page 6
For å sikre riktig installasjon må en autorisert installatør utføre alle slags installasjoner. Feil installasjon kan skade det elektriske kabinettet. • VOOL LMC skal ikke brukes av personer med mangel på erfaring eller kunnskap uten tilsyn fra en ansvarlig part. •...
Page 7
Veuillez lire ces instructions avant d’installer ou d’entretenir VOOL Load Management Controller (LMC). • Pour des raisons de sécurité, évitez d’installer ou d’utiliser le VOOL LMC à proximité de matériaux, de produits chimiques ou de vapeurs inflammables, explosifs, corrosifs ou combustibles.
Page 8
1. Connections 1. Ethernet connection 2. CAN to charger 2. Lights 1. Power ON 2. System status 3. Load Management status For more information about the indication leds see the LMC installation manual.
Page 9
Before installation, disconnect the power supply to prevent electrical hazards. Secure the LMC on the chosen location on the DIN rail. LMC size is 3,5 modules. Recommended circuit breaker for the LMC is a 6A, 3P, B curve. 4. Connect Current Transformers...
Page 10
LMC. If a power meter that supports Modbus protocol is available on-site, and is connected to the same network as LMC, it is possible to use metering data for load management. Contact your local supplier for compatibility.
6. Connect AC Power Supply (Three-Phase) Connect Cables to the Designated Socket and Socket to LMC Switch on the LMC and ensure that LEDs light up If any LEDs are unlit, refer to the troubleshooting section in installation manual. (Single-Phase) Connect Cables to the Designated Socket and...
Page 12
7. Connecting the LMC to Chargers Chargers can be connected to the LMC if they are in the same LAN (local area network) or connected via a CAN connection 7.1.1 Router Scenario 1: The charger(s) and the LMC are connected to the same local network, the Devices are connected to it with separate communication cables.
Page 13
7.2.1 End resistor Scenario 3: The Charger(s) and the LMC are connected via CAN Using cat 6 cable. Chargers themselves don’t need to be connected to internet and they communicate with our server over can through LMC. The last Charger on the line should be equipped with an end resistor to provide reliable communication between the devices.
Page 14
VOOL portal, but load management will continue to function. CAN connection: If only the LMC is connected to the Internet, as shown in section 7.2.1, no device will be visible on the network after the communication is lost.
Page 15
For CAN connection check if all the cable connections are done in a correct way. Add LMC group to each charger. After that restart LMC in app. Then you can activate autoconfiguration. Now LMC will automatically set charger parameters for load management.
Page 16
Scan the QR-code or enter the serial number + PIN code which are located on the packaging and on the LMC case. Be sure to connect the devices to the network and add them to the same network as the chargers. Then select which chargers are connected to the LMC from the charger settings.
Page 17
Ethernet: Connect an Ethernet cable with Internet connectivity to the Ethernet port on the LMC. Wifi: After powering up, wait for up to 2 minutes until the LMC creates a Wifi hotspot named ‘LMC ID123456789’. If the Wifi has already been configured, the hotspot will not appear.
Page 18
Set the size of the building’s main fuse and, if necessary, other settings. • During the installation of the LMC, you must match the current setting with the main fuses’ size and capacity to ensure proper calibration of the DLM system and avoid potential damage.
Page 20
For more information, support, or inquiries, please reach out to us at info@vool.com +372 56567172 Telliskivi 51b, Tallinn ESTONIA...
