- Page 1 VOOL Load Management Controller Installation Manual...
-
Page 2: Table Of Contents
Mount the LMC Connect current transformers Connect previous current transformers/multimeter Connect AC power supply Connecting LMC to Chargers 16-18 Connect to VOOL Network Add the LMC in the VOOL Portal Adjust settings Multipoint or Multilevel Load management Troubleshooting Maintenance Inspection Cleaning... -
Page 3: Safety Instructions
Safety Instructions... - Page 4 To ensure proper installation, an authorized installer must carry out all installations. Incorrect installation can damage the electrical cabinet. • The VOOL LMC should not be used by Individuals with a lack of experience or knowledge without the supervision of a responsible party. •...
-
Page 5: Preface
Preface... -
Page 6: About
EV while avoiding system overloads. About this document Before you start using your LMC, we encourage you to read through this manual carefully. This manual is written to provide you with clear and concise instructions for the safe and efficient use and maintenance of your VOOL LMC. -
Page 7: Original Instructions
The content of this manual is protected by copyright and other intellectual property laws. The content of this manual may only be copied, modified, reproduced and/or translated with express written permission from VOOL. This manual may only be published, transmitted, displayed or made available to a third party with express written permission from the manufacturer. -
Page 8: Product Overview
Product Overview... -
Page 9: Intended Use
This ensures the maximum possible charging speeds without overloading the power grid. The lights on the front of the LMC indicate the connection status of the LMC. The LMC can be controlled and monitored with the VOOL Admin portal. The LMC ensures continuous operation even if the network is disconnected, managing loads using locally set parameters in the Admin portal. -
Page 10: Status Leds
Risk of shock - Do not insert any foreign objects into the VOOL LMC. • Risk of shock - Do not cut, pierce or otherwise damage the power supply wires. Switch off and do not use the LMC if one or more wires are in any way damaged or exposed. •... -
Page 11: Emergency
2.3.In case of an emergency Always put your own safety and the safety of those around you first. Only when it is safe, switch off the main circuit breaker of the LMC to cut off all power to the LMC. -
Page 12: Installation
Installation... -
Page 13: Mount The Lmc
Secure the LMC on the chosen location on the DIN rail. 3.2 Connect Current Transformers The LMC comes with three current transformers available in 50A, 100A, and 200A configurations. They are split-core type, meaning they don’t require disconnection of power cables for installation. -
Page 14: Connect Previous Current Transformers/Multimeter
LMC. If a multimeter that supports the Modbus protocol is available on-site, it can be directly connected to the LMC. Both devices need to be in the same LAN. Cable to be connected to LMC Ethernet port. -
Page 15: Connect Ac Power Supply
3.4 Connect AC Power Supply 3.4.1 (Three-Phase) Connect Cables to the Designated Connector and Connector to LMC Switch on the LMC and ensure that top and bottom LED light up If any LEDs are unlit or red, refer to the troubleshooting section. -
Page 16: Connecting Lmc To Chargers
3. Installation 3.5 Connecting LMC to Chargers Chargers can be connected to the LMC if they are in the same LAN (local area network) or connected via a CAN connection. 3.5.1 Router VOOL App Basic setup Scenario 1: The Charger(s) and the LMC are in the same LAN connected via Ethernet cables. - Page 17 End resistor Scenario 3: The Charger(s) and the LMC are connected via CAN. The LMC is connected to the Internet via an Ethernet cable. The last Charger on the line should be equipped with an end resistor to provide reliable communication between the devices.
-
Page 18: Connect To Vool Network
1. Ethernet: Connect an Ethernet cable with Internet connectivity to the Ethernet port on the LMC. 2. Wifi: After powering up, wait for up to 2 minutes until the LMC creates a Wifi hotspot named ‘LMC ID123456789’. If the Wifi has already been configured, the hotspot will not appear. -
Page 19: Add The Lmc In The Vool Portal
If device is connected online it will appear in the list of devices. Make sure to connect the device(s) online and add them to the same site in the VOOL Portal. Then, select which chargers are connected to LMC on the site setup. -
Page 20: Adjust Settings
3.9 Multipoint or Multilevel Load management *If you are installing multiple LMCs for multi-residential, or commercial properties, contact directly support@vool.com for detailed instructions Once you have set up the LMC, you are ready to add chargers or link LMC with existing chargers on the site. -
Page 21: Troubleshooting
4. Troubleshooting If the LMC encounters an issue, the status light ring turns red. In the VOOL App or Portal the error is identified with a code that indicates what issue has occurred. Below you can find an overview of the possible causes and solutions for each error code. -
Page 22: Maintenance
WARNING • Risk of shock - Do not open the LMC, there are no user-serviceable parts inside. Only qualified technicians should open the LMC for maintenance or repairs. • Risk of shock - Ensure that no water or other liquids enter the LMC. -
Page 23: Discard
If you are unsure about where to dispose of the equipment, please reach out to the government waste-disposal department in your country. Do not dispose of the LMC or any of its components with your regular household waste. -
Page 24: Technical Specifications
Technical Specifications... - Page 25 Station master 64 chargers + other smart appliances Dynamic load management DLM (1) and DPM (1) (1) In combination with Charger and/or Multiphaser, LMC enables dynamic load management and dynamic phase management for 100% grid utilization. DLM response time Below 50ms...
-
Page 26: Warranty Information
Warranty Information... - Page 27 8. Warranty Information General Terms The VOOL LMC Limited Warranty provides coverage for a period of 3 years (3 years for EU member states) from the date of purchase. The Limited Warranty covers the refund, repair, or necessary replacement of adapters that have manufacturing defects occurring during normal use.
- Page 28 If the replacement is necessary, it may be fulfilled with non-original manufacturer’s parts of similar quality. If the costs of repairing or replacing the VOOL LMC exceed its fair market value at the time when the defect was discovered, VOOL will not be responsible for covering such costs.
- Page 29 Detailed information about the problem you are experiencing • Details about the attempts you have made to resolve the issue If any disputes or arguments arise between you and VOOL about the VOOL LMC Limited Warranty, Vool will try all possibilities to reach for agreeable resolution.
- Page 30 For more information, support, or inquiries, please reach out to us at info@vool.com...
