- Page 1 Rock Install Guide...
-
Page 2: Installation Prerequisite
OSDP Panel max cable length: 4000 ft - 24 AWG (1,219 m), max length between nodes: 1640 ft - 24 AWG (500 m) Parts Included 1x Alcatraz AI Rock X 1x Mounting plate 1x Panel Wiring harness 1x Reader Wiring harness... - Page 3 Step 1 – Mount 2-gang switch box in wall For best performance, place within 6” (150mm) of door Leave minimum of 1/2” (13mm) between 2-gang switch box 2-gang and door frame switch box 62” (157cm) from floor to center of box Badge reader mounted at Screw tabs must be in...
- Page 4 Step 2 – Wire cable harness to badge reader and access control panel Connection Overview Alcatraz AI Rock X PoE+ Ethernet Unshielded Cat5e/Cat6 OSDP/Wiegand Cables Access Control Badge Panel Reader It is possible to reuse existing Wiegand wiring for OSDP, however, using...
-
Page 5: Panel Wiring
Panel Wiring OSDP Wiegand 12 VDC IN ✓ ✓ BLACK ✓ LED Green ORANGE ✓ LED Red BROWN Beeper YELLOW Hold BLUE Aux IN GRAY ✓ ✓ D0 (+ RS485A) GREEN ✓ ✓ D1 (– RS485B) WHITE Tamper VIOLET Aux OUT Aux 12-24 VDC IN WHITE / RED ✓... - Page 6 Step 3 – Thread cables through and attach mount plate to 2-gang box Attach mount plate to 2-gang box with provided screws, paying attention to point the arrow towards door Arrow towards door Check mount plate Check to ensure tamper magnet is attached Use any side of mount plate to check level...
- Page 7 Step 4 – Plug in and seal cables Panel Cable PoE+ Ethernet Reader Cable For outdoor installs, use provided gasket kit Install gasket seals Press fit gasket seal retainer into place When not using Panel or Reader cables, use provided plugs as needed.
- Page 8 Step 5 – Attach Rock to wall plate Align threaded plate with opening on side of Rock X and press onto mount Hold in place while screwing down Arrow and narrow plate opening towards door T15 Security Torx Key Glass facing door 8/32 x 1/4 Security Screw x2 Rock X has TAMPER detection: Removal of Rock X from wall mount...
-
Page 9: Post-Installation Check
Step 6 – Post installation check Rock Power up The Rock must have PoE+ (802.3at Type 2, minimum 30W), or Auxiliary power (12-24 VDC, minimum 600mA) The bootup sequence will not be successful if the Rock does not have sufficient power, and may go into a reboot loop Booting Panel Power Status icons and a progress bar appear in... - Page 10 Door should unlock and the installation is now complete, you may proceed with commissioning - access the Alcatraz AI Admin Portal Guide by scanning the QR code on the back cover of this document for more info *If a mask is being worn, an animation to pull down the mask will be...
- Page 11 Internal Internal communications are Power cycle. Contact Support if it Comms Down down. persists. Icon is able to read an Alcatraz QR Code AI generated QR code shown to Icon will disappear after Onboarding. Receptive the camera. Rock accepts network...
- Page 12 à son utilisation. CE Marking Alcatraz AI hereby declares that these facial authentication devices are in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. WARNING: This product can expose you to chemicals including DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm.
