- Page 1 AirportLightingCompany An ISO 9001:2015 Certified Company An ISO 9001:2015 Certified Company OWNER'S MANUAL TP312 I-Lux LEDV3 LED Strip Airport Lighting Company | 108 Fairgrounds Drive | Manlius, NY, USA 13104 | (315) 682-6460 | airportlightingcompany.com [MAN] I-Lux TP312 Rev 1...
- Page 2 Manufactured by: Airport Lighting Company 108 Fairgrounds Drive Manlius, New York 13104 (315) 682-6460 Email: info@airportlightingcompany.com Website: www.airportlightingcompany.com Airport Lighting Company | 108 Fairgrounds Drive | Manlius, NY, USA 13104 | (315) 682-6460 | airportlightingcompany.com [MAN] I-Lux TP312 Rev 1...
-
Page 3: Data Sheet
600mm 5 = Style 5 (1 step 5.5A) S = Solar 400mm (Standard) Legend Height or 300 mm Airport Lighting Company | 108 Fairgrounds Drive | Manlius, NY, USA 13104 | (315) 682-6460 | airportlightingcompany.com [MAN] I-Lux TP312 Rev 1... -
Page 4: Specifications
Cat. # CA-I23J2.2SF CA-I23J3.2SF CA-I23J2.6SF CA-I23J3.0SF CA-I23J2.0SF CA-I23J2.4SF CA-I23J2.8SF CA-I23J1.8SF Cat. # Cat. # CA-I23J1.2SF CA-I23J1.6SF CA-I23J1.0SF CA-I23J1.4SF CA-I23J0.8SF Airport Lighting Company | 108 Fairgrounds Drive | Manlius, NY, USA 13104 | (315) 682-6460 | airportlightingcompany.com [MAN] I-Lux TP312 Rev 1... - Page 5 Verification by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. Intertek Page 1 of 2 GFT-OP-11a (22-August-2019) Airport Lighting Company | 108 Fairgrounds Drive | Manlius, NY, USA 13104 | (315) 682-6460 | airportlightingcompany.com [MAN] I-Lux TP312 Rev 1...
-
Page 6: Table Of Contents
..................... . Airport Lighting Company | 108 Fairgrounds Drive | Manlius, NY, USA 13104 | (315) 682-6460 | airportlightingcompany.com... -
Page 7: How To Get Help
(866) 212-1060 EMAIL: support@airportlightingcompany.com WEBSITE: www.airportlightingcompany.com An ISO 9001:2015 Certified Company 108 Fairgrounds Drive Manlius, New York 13104 Airport Lighting Company | 108 Fairgrounds Drive | Manlius, NY, USA 13104 | (315) 682-6460 | airportlightingcompany.com [MAN] I-Lux TP312 Rev 1... -
Page 8: Warranty
Damage caused by lightning, flood and other natural or man-made causes are outside the scope of this warranty. Airport Lighting Company | 108 Fairgrounds Drive | Manlius, NY, USA 13104 | (315) 682-6460 | airportlightingcompany.com [MAN] I-Lux TP312 Rev 1... -
Page 9: General Information
This provides the last layer of protection in the absence of the corrugated wrapping. Damage resulting from improper storage is not covered by warranty. Airport Lighting Company | 108 Fairgrounds Drive | Manlius, NY, USA 13104 | (315) 682-6460 | airportlightingcompany.com [MAN] I-Lux TP312 Rev 1... -
Page 10: Installation
14. Remove the protective plastic on the panels, being careful not to create foreign object debris (FOD). 15. When work is done on the circuit, verify sign operation between dusk and dawn. Airport Lighting Company | 108 Fairgrounds Drive | Manlius, NY, USA 13104 | (315) 682-6460 | airportlightingcompany.com [MAN] I-Lux TP312 Rev 1... -
Page 11: Maintenance
Remove the upper bolts from the top Channel LEDV3 Strip in Mounting Channel Remove the lower bolts from the bottom Airport Lighting Company | 108 Fairgrounds Drive | Manlius, NY, USA 13104 | (315) 682-6460 | airportlightingcompany.com [MAN] I-Lux TP312 Rev 1... -
Page 12: Troubleshooting
LEDV3 LED Strip Operation Airport Lighting Company’s LEDV3 strip light engine uses high efficiency LEDs to illuminate the guidance sign. Per FAA Engineering Brief 67 and TP312, if more than the maximum LED failures allowed occur, the whole sign is to turn off. -
Page 13: Ledv3 Led Strip Replacement
13. Press the Calibrate button on the adaptive monitoring board. 14. Replace the blank panel. 15. Bolt the cabinet back together. Airport Lighting Company | 108 Fairgrounds Drive | Manlius, NY, USA 13104 | (315) 682-6460 | airportlightingcompany.com [MAN] I-Lux TP312 Rev 1... -
Page 14: If The Sign Does Not Operate
4. If the LVCV2-24 has two lighted green LEDS, confirm the Adaptive Monitoring Board has a flashing green LED. If not, replace it. Airport Lighting Company | 108 Fairgrounds Drive | Manlius, NY, USA 13104 | (315) 682-6460 | airportlightingcompany.com [MAN] I-Lux TP312 Rev 1... -
Page 15: Parts List
C7-GDTH Gas Discharge Tube Harness I6-2SP Support Post When ordering: X.X = sign cabinet length (from Cat #) Airport Lighting Company | 108 Fairgrounds Drive | Manlius, NY, USA 13104 | (315) 682-6460 | airportlightingcompany.com [MAN] I-Lux TP312 Rev 1... -
Page 16: Mounting Information
CA-I23J3.6SF CA-I23J1.6SF CA-I23J3.4SF CA-I23J1.4SF Cat. # Cat. # CA-I23J3.2SF CA-I23J2.2SF CA-I23J3.0SF CA-I23J2.0SF CA-I23J2.8SF CA-I23J1.8SF Cat. # CA-I23J2.6SF CA-I23J2.4SF Airport Lighting Company | 108 Fairgrounds Drive | Manlius, NY, USA 13104 | (315) 682-6460 | airportlightingcompany.com [MAN] I-Lux TP312 Rev 1... - Page 17 0.94 CA-I23J1.6SF 1600 1535 0.94 CA-I23J1.4SF 1400 1335 0.94 CA-I23J1.2SF 1200 1135 0.94 CA-I23J1.0SF 1000 0.94 CA-I23J0.8SF 0.94 Airport Lighting Company | 108 Fairgrounds Drive | Manlius, NY, USA 13104 | (315) 682-6460 | airportlightingcompany.com [MAN] I-Lux TP312 Rev 1...
-
