Pioneer DVR-440H-AV Service Manual
  1. Manuals
  2. Brands
  3. Pioneer Manuals
  4. DVD Recorder
  5. DVR-440H-AV
  6. Service manual
Pioneer DVR-440H-AV Service Manual

Pioneer DVR-440H-AV Service Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
DVD RECORDER
DVR-440H-AV
DVR-440H-K
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
Model
DVR-440H-AV
WYXK5
DVR-440H-AV
WYXV5
DVR-440H-K
WYXK5
DVR-440H-K
WYXV5
DVR-440H-K
WYXVRE5
This service manual should be used together with the following manual(s):
Model
DVR-640H-AV/WYXK5
PIONEER CORPORATION
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2006
Type
Power Requirement
AC220-240V
AC220-240V
AC220-240V
AC220-240V
AC220-240V
Order No.
RRV3368
4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
RRV3380
Serial No.
Region No.
Please confirm 3rd & 4th
alphabetical letters.
2
&&UK######$$
2
&&DL######$$
2
&&UK######$$
2
&&DL######$$
5
&&DL######$$
Remarks
T – ZZV APR. 2006 Printed in Japan
ORDER NO.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DVR-440H-AV and is the answer not in the manual?

Questions and answers

Related Manuals for Pioneer DVR-440H-AV

Summary of Contents for Pioneer DVR-440H-AV

  • Page 1 PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A. PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936 PIONEER CORPORATION 2006 T –...

  • Page 2: Contrast Of Miscellaneous Parts

    → 562 × 10 → 5621 ............RN1/4PC 5 6 2 1 7 CONTRAST TABLE DVR-440H-AV/WYXK5, /WYXV5, DVR-440H-K/WYXK5, /WYXV5, /WYXVRE5 types and DVR-540H-S/WYXK5 are constructed the same except for the following: Part No. Ref. Mark Symbol and Description DVR-540H-S DVR-440H-AV DVR-440H-AVDVR-440H-K DVR-440H-KDVR-440H-K Remarks...

  • Page 3: Dvd Recorder

    PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A. PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936 PIONEER CORPORATION 2006 T-ZZV APR.

  • Page 4: Safety Information

    SAFETY INFORMATION LABEL CHECK LASER DIODE CHARACTERISTICS IMPORTANT MAXIMUM OUTPUT POWER: 100 mW THIS PIONEER APPARATUS CONTAINS WAVELENGTH: 654 - 662 nm LASER OF CLASS 1. SERVICING OPERATION OF THE APPARATUS LASER DIODE CHARACTERISTICS SHOULD BE DONE BY A SPECIALLY MAXIMUM OUTPUT POWER: 5 mW INSTRUCTED PERSON.
  • Page 5 [Important Check Points for Good Servicing] In this manual, procedures that must be performed during repairs are marked with the below symbol. Please be sure to confirm and follow these procedures. 1. Product safety Please conform to product regulations (such as safety and radiation regulations), and maintain a safe servicing environment by following the safety instructions described in this manual.

  • Page 6: Table Of Contents

    CONTENTS SAFETY INFORMATION ............................. 2 1. SPECIFICATIONS ............................5 2. EXPLODED VIEWS AND PARTS LIST ......................8 2.1 PACKING ..............................8 2.2 EXTERIOR SECTION..........................10 2.3 FRONT PANEL SECTION ........................12 3. BLOCK DIAGRAM AND SCHEMATIC DIAGRAM ..................14 3.1 BLOCK DIAGRAM ........................... 14 3.1.1 OVERALL BLOCK DIAGRAM......................

  • Page 7: Specifications

    1. SPECIFICATIONS DVD-R/-RW, DVD+R/+RW, DVD-RAM General Fine (XP) ......Approx. 1 h Power requirements .

  • Page 8: Supplied Accessories

    Input/Output AV Connectors (21-pin connector assignment) AV connector input/output ..21-pin connector VHF/UHF antenna input/output terminal This connector provides the video and audio signals ....VHF/UHF set 75Ω (IEC connector) for connection to a compatible colour TV or monitor.
  • Page 9 Accessories • RF antenna cable(PAL) ×1 Except DVR-640H-AV (VDE1075) • Power cable ×1 • Remote control ×1 (ADG1127 : WYXK5, WYXV5, (VXX3129) WYXVRE5 types) STANDBY/ON HDD/DVD • Audio / Video cable(1.5m) ×1 PAUSE LIVE TV HOME MENU INFO (red/white/yellow) TOP MENU (VDE1077) DISC GUIDE...

  • Page 10: Exploded Views And Parts List

    2. EXPLODED VIEWS AND PARTS LIST NOTES: Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List. mark found on some component parts indicates the importance of the safety factor of the part. Therefore, when replacing, be sure to use parts of identical designation.
  • Page 11 (1) PACKING SECTION PARTS LIST Mark No. Description Part No. Mark No. Description Part No. Top Cover See Contrast table (2) > Power Cord See Contrast table (2) NSP 18 Dry Cell Battery (R6P, AA) See Contrast table (2) RF Antenna Cable (PAL) VDE1075 Mirror Sheet VHL1104...

  • Page 12: Exterior Section

    2.2 EXTERIOR SECTION 10 (1/2) 10 (2/2) DVR-640H-AV only Reuse (*) marked parts when exachanging Service LOADER Assy. • Silicon Sheet R9B (DEB1726) x3 • Case Screw S (DBA1250) x2 • Frontboard Screw (DBA1220) x2 DVR-640H-AV only Refer to "2.3 FRONT PANEL SECTION". DVR-640H-AV...
  • Page 13 Aluminum Tape 25 x 25 VEF1060 NSP 11 Service LOADER MAIN See Contrast table (2) Aluminum Tape 180 x 25 VEF1065 Connector Assy PF05PP-S07 Pioneer Name Plate VAM1148 Connector Assy PF13PP-S22 Tray Sheet VEC2500 Flexible Cable 24P See Contrast table (2) Tray Panel...

  • Page 14: Front Panel Section

    2.3 FRONT PANEL SECTION Lubricant Hanarl GEM1041 10 (1/2) FJKB CN7302 10 (2/2) Lubricant Hanarl GEM1041 Door Shaft Lubricant Hanarl to Door Shaft GEM1041 Paste lubricant hanarl (GEM1041) to salient points of both side of the door. DVR-640H-AV...
  • Page 15 (1) FRONT PANEL SECTION PARTS LIST Mark No. Description Part No. FLKY Assy (for service) VXX3111 KEYB Assy (for service) VXX3112 Flexible Cable 12P VDA2116 Door Spring VBK1159 Earth Plate VBK1166 Rubber Foot VEB1349 Sub Key VNK5909 Center Cover VNK5911 LED Lens VNK5913 Main Key...

  • Page 16: Block Diagram And Schematic Diagram

    3. BLOCK DIAGRAM AND SCHEMATIC DIAGRAM 3.1 BLOCK DIAGRAM 3.1.1 OVERALL BLOCK DIAGRAM SEL_IR SEL_IR OPTICAL IR Blaster Blaster PDF015A VHF/UHF Tuner Single/multista PIF AMP ndard VIF/SIF- Filter 5.5M PLL and FM- SCL/SDA 27.28 12.13 Trap PLL/AM IF Trap Filter 10MHz demodulators Filter...
  • Page 17 (DVR-640H-AV CN5601 Only) CN101 IC1102 IC5701 64M FLASH USB control IC S29GL064M90TCI TDOTG242- 0F0C8 USBB P_CONT2 voltage regulator External ROM I/F IC1201 IC3707 MRST 512M SDRAM RESET IC K4H511638C- XRESET UCB3 DDR SDRAM I/F DA T_TO_M SS T to M IC1221 IC3701 512M SDRAM...

  • Page 18: Detection And Encode System Block Diagram

    3.1.2 DETECTION AND ENCODE SYSTEM BLOCK DIAGRAM DVR-640H-AV...

  • Page 19: Power Block

    3.1.3 POWER BLOCK TUJB FLKY IC5001 V+31V DCDC Con SYPS V+12V CN202 CN303 BLUE LED Tuner U301 FLDC+ P_ON P401A IC1001 V+12R1E FL TUBE EV+12.1V FLDC- V+9V V7001 P402A FL-28V FL DRIVER V+12R1SW FAN Circuit IC7001 Audio RED LED MUTE RESET IC(Tu-con) V+5R8E P201A...

  • Page 20: Overall Wiring Diagram

    3.2 OVERALL WIRING DIAGRAM JA801 VKB1157- AV1(to TV) SCRB ASSY CN3801 CN101 CN12 CN11 (VWV2206) DKN1404- VKN2050- VKN1818- VKN1816- VKN1260- DASP# DASP# CS1# CS1# CS0# CS0# SCLK SDIO PDIAG# PDIAG# RESET RESERVED RESERVED INTRQ INTRQ VD3V GNDD DMACK# DMACK# TEMP CSEL CSEL VKN1433- -TBB...
  • Page 21 JA802 VKB1157- AV2(from STB) FAN MOTOR (VXM1125-) COMPONENT OUTPUT VKN1260- U/V IN/OUT JA2010 IR BLASTER JA4001 JA2003 VKB1165- RKN1004- COAXIAL VKB1193-(EU) JA2004 JA536 VKB1159- SR IN OUTPUT1 JA4002 CN5001 RKN1004- B2B-PH-K-S VKN1433- -TBB CN605 only U301 VXF1106- Cb/Pb Cr/Pr 1/4- TUJB ASSY (VXX3109 : DVR-640H-AV) (VXX3108 : DVR-540H-S)

  • Page 22: Tujb Assy (1/4)

    3.3 TUJB ASSY (1/4) Q3011 2SD2114K(VW)-TLB UMD2N-TLB AMUTE1 R3318 Q3010 1-C4 1K UMD2N-TLB R185 Q3011 TUJB ASSY(1/4) V+5V 1-A3 TU_CON (VXX3109 : DVR-640H-AV) MUTECTL V+5R8E Q103 (VXX3108 : DVR-540H-S) D101 R111 1SS355-TRB V+5V C107 R110 SAMUTE Q104 Q105 D105 C153 DAP202U-TLB Q105 R166...
  • Page 23 V+12R1E TU_CON P_CONT V+5F V+12R1E V+12R1 P_ON EV+12R1 R151 C309 V+5R8E Q314 Note1 EV5R8 R184 C302 R4007 C128 470u CN303 C130 1000u B5B-PH-K-S C4005 FLSTB FLSTB R4026 10 k FLCLK FLCLK C101 FLDATA FLDATA R127 4.7 k R105 6.8 k R188 100 k V+5F...

  • Page 24: Tujb Assy (2/4)

    3.4 TUJB ASSY (2/4) TUJB ASSY(2/4) R3001 C711 R701 R3164 L_SWIN L_IN (VXX3109 : DVR-640H-AV) 10kD 10/50 (VXX3108 : DVR-540H-S) V+12R1SW R707 8.2kD <AUDIO SELECTOR BLOCK> Note7 IC701 BA4560RF-TBB 1/10YB 1/10YB IC701 R3510 BA4560RF-TBB R3511 0.1/25YF 0.1/25YF R708 8.2kD 0.1/25YF Note9 R2016 180F...
  • Page 25 V+5VI C403 C404 V+5VI Q401 L401 L402 15µ 18µ 2SA1576A(QR)-TLB R402 R403 Y_IN 270F Q409 2SC4081(QR)-TLB R425 TEXTVIN 1-D2 Note8 IC2002 MM1503XN-TRB Note8 C2109 Y3IN IN 1 1/10 Note8 Note8 R196 Note8 V+5VI IN 2 AV2 Vin 1/10 SELV1 R195 R196 Note SELV1 : 1503...

  • Page 26: Tujb Assy(4/4)

    3.5 TUJB ASSY(3/4) KN401 ***(VNF1084- -T) KN402 ***(VNF1084- -T) KN403 ***(VNF1084- -T) KN404 ***(VNF1084- -T) KN405 VNF1084- -T V+5R1 R3701 <OUTPUTS> V+5R1 JA4003 3 2 1 Q3701 SPDIF 1-A4 C3701 D3709 R3704 V+5V JA4002 D4005 R4028 RKN1004- R118 SEL_IR 1SS355-TRB R4029 JA4001 R129...
  • Page 27 TUJB ASSY(3/4) (VXX3109 : DVR-640H-AV) (VXX3108 : DVR-540H-S) V+5R1 Q2001 R2005 SPDIF 1-C1 C2032 R2008 DIGITAL 1/50 R2007 AUDIO OUTPUT JA2004 VKB1159- D2004,D2005:UMZ6R8N-TLB JA2010 R2026 VKB1165- C2035 1000/6.3 YOUT R2011 75F(2125) C2034 470/6.3 CBOUT R2023 75F(2125) V+5V C2033 470/6.3 CROUT R2025 75F(2125) Q3210...
  • Page 28 3.6 TUJB ASSY(4/4) TUJB ASSY(4/4) (VXX3109 : DVR-640H-AV) (VXX3108 : DVR-540H-S) VXF1106- U301 <U/V TUNER BLOCK> 10 11 13 14 15 16 17 L301 CTF1399- -T L5004 CTF1399- -T V+5R1 L901 V+5R1 CTF1399 MULTI SOUND DECODER IC901 MSP3417G-TBB (EU,YPW) Note R910 EU,YPW (*** ) Note R910 EU,YPW (*** ) LCYA101J2520-T L903...
  • Page 29 V+31V V+5TU V+5R8E R6317 R302 10(2125) R304 R303 10(2125) 12(2125) Q6001 R5012 UMF21N-TLB 12(2125) Q6001 UMF21N-TLB TU_CON RFTHRU XRST1 STACHG TU_VIN TU_RIN TU_LIN C923 0.01 R918 R919 3.3k 3.3k C926 0.01 R921 R922 3.3k 3.3k UMF21N C B2 B C2 DVR-640H-AV...
