Maintenance Advice for Educators
SOUNDFIELD TECHNOLOGY CHECKLIST & MAINTENANCE GUIDE
ASSESS WHICH REDCAT SOUNDFIELD SYSTEM YOUR SCHOOL IS USING
These Redcat Soundfield systems ARE SUPPORTED
Identify your Redcat by its model logo above the screen to assess the compatible microphones.
look
for this
logo
Redcat (RCN)
Post 2022
Flexmike
THESE MIKES ONLY WORK WITH THIS MODEL REDCAT
ALL SPARES ARE AVAILABLE FOR THESE SYSTEMS.
These Redcat Soundfield systems are NOT SUPPORTED and are DISCONTINUED
WHITE REDCAT IR
DISCONTINUED
Redcat IR
THIS MIKE ONLY WORKS WITH THIS MODEL REDCAT
Please note that a Redmike is only compatible with a white Redcat or black IR Redcat shown.
IT IS NOT COMPATIBLE WITH REDCAT ACCESS OR REDCAT POINT TO PAIR SHOWN ABOVE.
ALL SPARES FOR WHITE & BLACK REDCATS IR ARE DISCONTINUED
UConnect SoundHouse, UConnect Mini, Redcat
for this
Sharemike
Redmike IR
THIS MIKE ONLY WORKS WITH THIS MODEL REDCAT
1 /9
hearandlearn.com.au
are part of the
Hear and Learn
Offices Australia wide (03) 9370 9355
look
logo
Redcat Access (RCA)
Pre 2022
Flexmike
THESE MIKES ONLY WORK WITH THIS MODEL REDCAT
BLACK REDCAT IR
DISCONTINUED
Redcat (RC2)
, Topcat
and 975
technology family
Sharemike
Redmike IR
(DISCONTINUED)
Only battery
(NH2A27) available
,
Advertisement
Related Manuals for Hear and Learn Redcat
Summary of Contents for Hear and Learn Redcat
- Page 1 THIS MIKE ONLY WORKS WITH THIS MODEL REDCAT (NH2A27) available Please note that a Redmike is only compatible with a white Redcat or black IR Redcat shown. IT IS NOT COMPATIBLE WITH REDCAT ACCESS OR REDCAT POINT TO PAIR SHOWN ABOVE.
- Page 2 Redcat properly. Plug the DC connector into the DC Input on the Redcat and then plug into an electrical outlet. The Redcat will power on and the blue LED on the front panel will light. HOW TO ASSESS THE MIKES: Power Button Press this button to turn power ON/OFF.
-
Page 3: Charging The Flexmike
Once initial volume level is set, walk around If further fine tuning is required, you may need to the room and listen for overall audio quality. adjust the Tone control on the side of the RedCat. 3 /9 hearandlearn.com.au UConnect SoundHouse, UConnect Mini, Redcat... - Page 4 This equipment is designed to supplement and distribute the user’s voice so they are able to speak in a conversational tone. Having the volume set too high will result in feedback and listener fatigue 4 /9 hearandlearn.com.au UConnect SoundHouse, UConnect Mini, Redcat , Topcat and 975 are part of the...
- Page 5 POSITIONING YOUR REDCAT You may be restricted in your choices of where to place your Redcat in the classroom. As a rule, in the middle of the longest wall is ideal and if possible avoiding the teaching wall.
- Page 6 Maintenance Advice for Educators INSTALLATION AND TROUBLESHOOTING FOR A REDCAT POINT TO PAIR The Redcat Point to Pair speaker / amplifier with power supply, needs to be located, together with the Flexmike and Sharemike. PlEAsE tAkE NotE of thE MoDEl...
- Page 7 Used for charging is required, you may need to adjust the Tone control battery. Red light and connecting when charging in on the side of the Redcat (See page 6). Normal operation audio source to the cradle, green send to Redcat.
- Page 8 This equipment is designed to supplement and distribute the user’s voice so they are able to speak in a conversational tone. Having the volume set too high will result in feedback and listener fatigue 8 /9 hearandlearn.com.au UConnect SoundHouse, UConnect Mini, Redcat , Topcat and 975 are part of the...
- Page 9 INSTALLATION AND TROUBLESHOOTING FOR POINT TO PAIR FLEXMIKE AND SHAREMIKE PlEAsE tAkE NotE of thE MoDEl Redcat (RCN) logo Post 2022 Pairing your Flexmike or Sharemike microphone To 975, Redcat Or Topcat Status light Status light IR sensor Status light IR sensor IR sensor IR transmitters on microphones TopCat IR sensors on RedCat , 975, &...
