Hear and Learn UConnect Flexmike Installation And Troubleshooting Instructions

Hear and Learn UConnect Flexmike and Sharemike
PLEASE NOTE: The 975 and microphone(s) are paired together at the factory and all components should be kept together as a system.
Moving them from one system, or room, to another will result in the need to re-pair.

CHARGING THE FLEXMIKE

Before use, the Flexmike should be charged
It will take 5-6 hours for the Flexmike to
obtain a full charge. A fully charged
Flexmike will last for up to 8 hours of use.
If microphones are used daily,they should
be charged each night.
Replacement lithium polymer
battery packs may only be
purchased through
Lightspeed (part # L3.7V).
Attach lanyard
Hang the Flexmike on
the lanyard opposite
the magnetic clasp.

SETTING UP THE FLEXMIKE

Once the Flexmike is charged, follow these steps for use.
Remove the Flexmike from the charger and put
1
it on by connecting the magnetic clasps behind
your neck. Adjust the lanyard so that the top of
the Flexmike aligns with the collarbone.
The Flexmike will automatically power on and
2
mute when it is removed from the charger.
The microphone volume on the Flexmike is set at
3
the factory to the midpoint. It is adjusted by the
up / down buttons on the side of the mic.
While speaking in a normal voice, fine tune the
4
microphone volume. Proper volume level should
be as follows:
• Your voice should be clearly heard by another
person on the other side of the room.
• You should barely be able to hear your
own voice.
• There should not be any audio "feedback" or
squealing outside of 60-90cm (if there is, turn
the volume down slightly).
REMEMBER:
This equipment supplements the user's voice so
they are able to speak in a conversational tone.
Having the volume set too high will result in
feedback and listener fatigue.
• Once initial volume level is set, walk around the
room and listen for overall audio quality.
• If further fine tuning is required, you may need
to adjust the Tone control on the front of the
975 or the side of the RedCat or TopCat.
USHMHG0522
UConnect SoundHouse & Mini, 975 Point to Pair, Redcat Point to Pair & Topcat Point to Pair are part of the
Set Up Installation and Troubleshooting Instructions
Connect cradle charger
Plug power cord into the cradle
charger and then plug into a
power point.
Flexmike
SIDE PANEL CONTROLS AND CONNECTIONS
hearandlearn.com.au
hearandlearn.com.au
Offices Australia wide (03)93709355
Talk/Mute light
Talk
Mute
volume
control
975
FRONT CONTROLS
Got a SoundHouse? Open its door
to see the controls on top of the 975
Tone control:
Adjusts the audio
tone, adding more
bass or treble for a
more rich or crisp
sound.
REDCAT
Charge flexmike
Place the microphones into the cradle
charger. The power status light will glow
red when it is charging.When charging is
complete, the power status light will glow
green. It takes about 5-6 hours to fully
charge the microphone battery.
Align with
Collarbone
Tone control
Tone control:
Select tone for
adjustment
TOPCAT CONTROLS
(INSIDE SPEAKER DOOR)
©Hear and Learn®
Hear and Learn technology family.
