- Page 1 Doc. No.VFR3000−OMH0003−B 5 Port Solenoid Valve PRODUCT NAME VFR3000 Series MODEL/ Series...
-
Page 2: Table Of Contents
Contents Safety Instructions ---------------------------------------------------------------------------- 2,3 Precautions on Design ---------------------------------------------------------------------- 4,5 Selection ---------------------------------------------------------------------------------------- 4,5 Mounting ---------------------------------------------------------------------------------------- 5 Piping -------------------------------------------------------------------------------------------- 6 Wiring -------------------------------------------------------------------------------------------- 6 Lubrication -------------------------------------------------------------------------------------- 6 Air Supply --------------------------------------------------------------------------------------- 6,7 Operating Environment ---------------------------------------------------------------------- 7 Maintenance ------------------------------------------------------------------------------------ 7 Specific Product Precautions --------------------------------------------------------------- 8 to 11 Trouble shooting ------------------------------------------------------------------------------- 12 Remedy ------------------------------------------------------------------------------------------ 13 VFR3000−OMH0003−B... -
Page 3: Safety Instructions
Safety Instructions These safety instructions are intended to prevent hazardous situations and/or equipment damage. These instructions indicate the level of potential hazard with the labels of “Caution,” “Warning” or “Danger.” They are all important notes for safety and must be followed in addition to International Standards (ISO/IEC) , and other safety regulations. -
Page 4: Limited Warranty And Disclaimer/Compliance Requirements
Safety Instructions Caution 1.The product is provided for use in manufacturing industries. The product herein described is basically provided for peaceful use in manufacturing industries. If considering using the product in other industries, consult SMC beforehand and exchange specifications or a contract if necessary. If anything is unclear, contact your nearest sales branch. -
Page 5: Precautions On Design
- - 4 - - VFR3000 Series 5 Port Solenoid Valve / Precautions 1 Be sure to read before handling. Design / Selection 7. Release of residual pressure Warning For maintenance purposes install a system for releasing residual pressure. Especially in the case of 3-position 1. -
Page 6: Mounting
- - 5 - - VFR3000 Series 5 Port Solenoid Valve / Precautions 2 Be sure to read before handling. Design / Selection 6. Operation for air blowing Caution When using a solenoid valve for air blowing, use an external pilot type. -
Page 7: Piping
- - 6 - - VFR3000 Series 5 Port Solenoid Valve / Precautions 3 Be sure to read before handling. Piping 3. Check the connections. Caution Check if the connections are correct after completing all wiring. 1. Preparation before piping... -
Page 8: Operating Environment
- - 7 - - VFR3000 Series 5 Port Solenoid Valve / Precautions 4 Be sure to read before handling. Air Supply 6. If it is used in an environment where there Caution is possible contact with oil, weld spatter, etc., exercise preventive measures. - Page 9 VFR3000 Series 5 Port Solenoid Valve / Specific Product 1 Be sure to read before handling. With DIN terminal block Lead Wire Connection With terminal block Caution Ground Plug-in type (With terminal block) • Applicable cable O.D. • If you remove the junction cover (1) on the sub-plate, you will Type T: φ6 to φ8 mm...
- Page 10 VFR3000 Series 5 Port Solenoid Valve / Specific Product 2 Be sure to read before handling. Light/Surge Voltage Suppressor Used as a 3 Port Valve Plugging one of the cylinder ports (A or B) enables use as a Plug-in type Non plug-in type normally closed (N.C.) or normally open (N.O.) 3 port valve.
- Page 11 VFR3000 Series 5 Port Solenoid Valve / Specific Product 3 Be sure to read before handling. Change Direction of DIN Connector/Cable Entry Lead Wire Connection Unscrew retaining screw, pull off outer cover, rotate connector Caution block through 180 . Replace cover and tighten screw.
-
Page 12: Specific Product Precautions
VFR3000 Series 5 Port Solenoid Valve / Specific Product 4 Be sure to read before handling. Lead Wire Connection Type 01F D-sub Connector Caution - Wire connection specification Lead wire for both of solenoid A and B sides in manifold are Type 01C Circular Connector connected to connector terminal as COM specifications. -
Page 13: Trouble Shooting
TROUBLE SHOOTING Excessive supply oil am ount (14) Intrusion of foreign m atter (11) Wrong Pressure supplied X port. (In the case of (15) external pilot specification) Burnt coil Higher voltage or wrong coil used Coil splashed by water (10) Air leaks through EXH. -
Page 14: Remedy
REMEDY Remedy Regulate voltage, so that the voltage at the time of the operationbecomes specifications range. Re-wire correctly. Replace part. Replace part or re-wire positively. Replace valve. Replace pilot valve assembly. Adjust pressure so that pilot pressure will fall within operating pressure range during opretation. -If worng oil used, completely air blow to remove oil and replace valve. - Page 15 Revision history □ A Renewal □ B Renewal 1st printing: HT 4-14-1, Sotokanda, Chiyoda-ku, Tokyo 101-0021 JAPAN Tel: + 81 3 5207 8249 Fax: +81 3 5298 5362 http://www.smcworld.com Note: Specifications are subject to change without prior notice and any obligation on the part of the manufacturer. ©...
