MAXXFAN
INSTALLATION INSTRUCTIONS,
INFORMATION AND OPERATING GUIDE
READ AND SAVE THESE INSTRUCTIONS
NOTE: Refer to supplied Operating Instructions regarding the model you have purchased.
The MAXXFAN installs into a standard RV roof opening of 355mm x 355mm.
To determine if your roof opening is correctly sized, simply remove the interior ceiling garnish
trim ring of your existing roof vent and measure the ceiling opening or verify the opening is
large enough by sliding the MAXXFAN interior garnish trim ring into the opening.
Due to the EXHAUST / INTAKE LOUVERS that face the rear of the vehicle, the MAXXFAN
requires a roof area clear of obstructions such as air conditioners, storage boxes, etc. for at
least 203 mm to the rear of the existing standard roof vent flange outer rear edge.
The MAXXFAN is designed for a minimum roof thickness of 25mm to a maximum of
90mm. If your roof thickness is less than 25mm, build additional thickness at the ceiling
opening using wood or other suitable material. Longer Ganish Rings are available to allow
installation in caravans with thicker roof sections.
The MAXXFAN is designed for a nominal 12 Volt DC system and requires a circuit capable
of supplying a minimum of 5 amp service to the MAXXFAN. Confirm that the circuit you
intend to use will accommodate the additional load. Circuit must be fused and must use the
proper gauge stranded wire for electrical connections.
WARNING!
To reduce risk of fire, injury to persons or damage to property, only use
in the manner intended by AIRXCEL, INC. Should you have questions, please contact
your AIRXCEL/MAXXAIR Distributor.
More information https://www.caravansplus.com.au
FOR MAXXFAN
5100KIA • 7000KIA • 7500KIA
AIRXCEL, INC. – RV Products Division / MAXXAIR
3050 N. St. Francis St. • Wichita, KS 67219 • USA
®
Deluxe MODELS
®
P/N: 11F90001KIA
02-2023
Advertisement
Table of Contents
Related Manuals for MAXXFAN Deluxe 5100KIA
Summary of Contents for MAXXFAN Deluxe 5100KIA
- Page 1 MAXXFAN interior garnish trim ring into the opening. Due to the EXHAUST / INTAKE LOUVERS that face the rear of the vehicle, the MAXXFAN requires a roof area clear of obstructions such as air conditioners, storage boxes, etc. for at least 203 mm to the rear of the existing standard roof vent flange outer rear edge.
- Page 2 In addition, the Remote Control model will automatically close the vent cover. If the MAXXFAN does not beep when power is connected, go back to step #3. Confirm that proper STEP 3 connections were made and 12 volt power is on and available.
- Page 3 RV roof thickness. To accomplish this, measure the distance from the vehicle ceiling surface to each corner of the MAXXFAN Control Plate. Most RV roofs have some slope, so measuring each corner is necessary. The Garnish ring should be cut 6mm to 12.5mm longer than the dimensions measured at each...
-
Page 4: Warranty
Alkaline Material), Silicone Oil or Greases (avoid those containing Aromatic Hydrocarbons or other additives). Review the contents of your cleaning materials carefully. For additional information regarding your NEW MAXXFAN Deluxe, please refer to the INFORMATION AND OPERATING GUIDES for your particular model on the following pages. More information https://www.caravansplus.com.au... -
Page 5: Serial Number Label
SERIAL NUMBER LABEL The serial number label is located underneath the round insect screen. NOTE: The MAXXFAN is designed to be fully opened or fully closed when the vehicle is moving. CAUTION: When removing screen for cleaning, turn the MAXXFAN OFF and remove the vehicle 12 volt power to the MAXXFAN. -
Page 6: Keypad Controls
Press this key once for less than three (3) seconds to enter Auto Mode, three (3) quick beeps will confirm the MAXXFAN has entered Auto Mode. To EXIT Auto Mode, press the ON/OFF key. Initial factory set point for the thermostat is 26°C. - Page 7 REMOTE CONTROL OPERATING GUIDE WIRELESS REMOTE CONTROL FOR MAXXFAN ® Deluxe MODELS 7000KIA • 7500KIA FAN ON & POWER OFF - Press this button: • To start the fan • To turn the fan off • To exit Auto Mode VENT LID POSITION - Press this button to open or close the vent lid •...
-
Page 8: Duration Of Warranty
Coast RV Pty Ltd trading as Coast to Coast RV Services ABN 49 097 104 492 - ACN 101 461 330 PO Box 6287, Silverwater NSW 1811 AUSTRALIA Ph (02) 9645 7600 - Fax (02) 9645 7699 Email: warranty@coastrv.com.au Web: www.coastrv.com.au Coast to Coast RV Services PO Box 58-054, Botany AUCKLAND 2163 NEW ZEALAND... -
Page 9: Warranty Limitations
5 RESPONSIBILITY FOR COSTS OF CLAIM UNDER THIS WARRANTY 5.1 The Supplier is responsible for the costs directly associated with repairing or replacing the Goods in accordance with clause 2.1 only. 5.2 Any works required to be completed in addition to fixing the Defect are the responsibility of the Client. - Page 10 8 RIGHTS AT LAW 8.1 The benefits given to the Client under this warranty are in addition to other rights and remedies of the Client at law in relation to the Goods. 8.2 In Australia our Goods come with guarantees that cannot be excluded under the Australian Consumer Law.
- Page 11 PAGE INTENTIONALLY LEFT BLANK More information https://www.caravansplus.com.au...
-
Page 12: Warranty Claim Form
WARRANTY CLAIM FORM Warranty Provider’s Name Coast RV Pty Ltd trading as Coast to Coast RV Services ABN 49 097 104 492 – CAN 101 461 330 Warranty Provider’s Address PO Box 6287, Silverwater NSW 1811 Australia OR; PO Box 58-054 Botany AUCKLAND 2163 New Zealand Client: Contact No.
