Introduction
The Twinflex sounder allows for audible indication
when the fire alarm system enters a fire alarm condition.
This device is compatable with the Twinflex 2-wire range
of fire alarm equipment and comprises a 2-wire zone powered
sounder. The device may be installed on the same zone as
the Twinflex ASD detector/sounder and associated Twinflex devices.
Before Installation
The sounder must be installed in compliance with the control panel installation manual (26-0959). The installation
must also meet the requirements of any local authority. For maximum performance the sounder should be installed
in compliance with BS5839 Pt1.
Spacing
The sounder should be mounted securely and care should be taken to ensure the device is accessible for future
testing or replacement. FIKE recommends spacing of sounders in accordance with BS5839 Pt1, and any local
authority requirements.
Device Installation
Fix the back box in a suitable position using at least two screw holes/slots, remembering to allow enough cable
length for installation. All wiring must be installed in compliance with the recommendations laid out by any local
authority as well as any special recommendations documented in the control panel installation manual.
Care should be taken when terminating devices to ensure all cables are correctly sleeved and connections are
secure. Improper connections will prevent a system from responding properly in the event of a fire. This product is
maintenance free do not attempt disassembly.
Follow the steps below to ensure the IP65 rating is maintained.
1. Drill suitable holes in the base for IP65
rated gland type using O rings to maintain
the rating.
INSTALLATION
INSTRUCTIONS
F0296337 TWINFLEX SOUNDER
2. Affix the Base to the wall using the
slots in the base for the screws and
using the supplied gasket fitted to
maintain the IP65 rating.
Gasket
Document No. 26-1879-03.
Subject to change.
FIKE.COM
3. Fit product to the base using
the suppied O ring to maintain
the IP65 rating.
