- Page 1 ELE-PSU3010CH power supply ELE-PSU6005CH power supply DC POWER SUPPLY VOLTAGE CURRENT POWER USB-C Quick Charge BATTERY OUTPUT USB-A MA N UAL HANDLE I DI NG...
- Page 2 This manual is applicable to multiple models of power supplies within a series. Each model is named slightly different. In this manual we refer to each power supply of this series as ELE-PSU-CH. Deze handleiding is van toepassing op meerdere modellen labvoedingen binnen een serie. Ieder model heeft een net iets andere, specifieke naam.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Inhoudsopgave Safety precautions - Veiligheidsvoorschriften ............... 4 Packing contents - Inhoud verpakking ................5 Connecting battery / accumulator - Verbinden batterij / accu ........5 Product description - Productomschrijving ..............6 Specifications - Specificaties ....................7 Product overview - Productoverzicht ................8 Operation instructions - Bedieningsinstructies ............ -
Page 4: Safety Precautions Veiligheidsvoorschriften
SAFETY PRECAUTIONS Veiligheidsvoorschriften This manual contains important safety instructions that must be followed at all time in the operation, and in the storage/working environment, of the ELE-PSU-CH power supply. To ensure your personal safety, and ensure that the performance of this product is optimal in its environment, please read this manual carefully before using. -
Page 5: Packing Contents Inhoud Verpakking
PACKING CONTENTS Inhoud verpakking • ELE-PSU-CH power supply • ELE-PSU-CH labvoeding • EU power cord • EU netsnoer • Set test leads • Set meetsnoeren (4mm to aligator clip) (4mm naar krokoklem) • User manual • Handleiding • Warranty card •... -
Page 6: Product Description Productomschrijving
PRODUCT DESCRIPTION Productomschrijving The ELE-PSU-CH is a single channel, regulated DC power supply with a 4-digit display for accurately displaying voltage and current. Designed to be used in laboratories, schools, product lines and other electronics workplaces. The power supply with stepless control has a large range up to 30V or 60V and 5A or 10A, with a high resolution of 10mV and 1mA. -
Page 7: Specifications Specificaties
SPECIFICATIONS Specificaties Specification ELE-PSU3010CH ELE-PSU6005CH Number of channels Voltage- & current range (per channel) 0 ~ 30 V ; 0 ~ 10 A 0 ~ 60 V ; 0 ~ 5 A Max. total power 300 W 300 W Input voltage 230 V ±... -
Page 8: Product Overview Productoverzicht
PRODUCT OVERVIEW Productoverzicht DC POWER SUPPLY Output voltage / Uitgangsspanning / Uitgangsstroom Output current Output power / Uitgangsvermogen VOLTAGE Constant voltage indicator C.V. indicator Constant current indicator CURRENT C.C. indicator Voltage tuner / Spanning instellen Current tuner / Stroom instellen POWER USB-C Power display indicator... -
Page 9: Operation Instructions Bedieningsinstructies
OPERATION INSTRUCTIONS Bedieningsinstructies There are two types of power output modes: constant voltage output (CV) and constant current output (CC). The output mode is determined by the voltage and current values set by the user and the load connected by the user. The output voltage or current value of the power supply won’t exceed the voltage and current values set by the user. - Page 10 When the USB-ports are used separately, quick charging mode is used. When used simultaneously, normal charging mode is used. CONSTANT VOLTAGE / CONSTANT CURRENT CHARACTERISTICS A characteristic of this power supply is that it can automatically change from constant voltage mode to constant currenct mode (or vice versa) if a change in the load connected has been detected.
- Page 11 will now continuously stay yellow. Press the “OUTPUT” button to start the charging process. The charging display indicator will light up and the display will show the charged value (Ah). • Charging will not start if the connection is incorrect (e.g. reversed polarity), the condition of the battery is too low or the battery is damaged.
- Page 12 draaien. VERBIND EEN BELASTING MET GEBRUIK VAN 4MM (BANAAN) STEKKERS Plug de banaanstekker direct loodrecht in het gat van de schroefconnector. VERBIND EXTERN APPARAAT MET USB OPLAADPOORT Deze USB-poort wordt niet beïnvloed door de spanning- en stroominstellingen van de labvoeding. CONSTANTE SPANNING / CONSTANTE STROOM EIGENSCHAPPEN Een kenmerk van deze voeding is dat hij automatisch kan overschakelen van constante spanningsmodus naar constante stroommodus (of omgekeerd) als er een verandering in...
- Page 13 • Normaliter wordt de laadspanning op 1,15 keer de batterijspanning ingesteld. En de laadstroom wordt ingesteld op 0,2C, waarbij C de totale capaciteit van de batterij in Ah is. Voorbeeld: voor een 5000mAh batterij dient de laadstroom dus op 1A te worden ingesteld. •...
-
Page 14: Fuse Replacement Zekering Vervangen
FUSE REPLACEMENT Zekering vervangen If the fuse blows, the power supply will stop working. First find the cause of the blown fuse and make sure it will not happen again. Then replace the blown fuse with a new one with the same specifications. -
Page 15: Warranty Garantie
HOGE SPANNING! GEVAARLIJK! Vervang de zekering alleen als dit echt noodzakelijk is. Voordat u de zekering vervangt, zorg ervoor dat de labvoeding is uitgeschakeld en de netsnoer uit het stopcontact is gehaald zodat deze niet meer met de netstroom verbonden is. WARRANTY Garantie The warranty period of this product starts from the date of purchase. - Page 16 For more information or the latest updates, please check eleshop.eu. Questions? Contact Eleshop. Voor meer informatie of de laatste updates, kijk snel op www.eleshop.nl. Vragen? Neem contact op met Eleshop.
