- Page 1 ELE-PSU305C power supply ELE-PSU305C labvoeding CURRENT VOLTAGE MANUAL HA NDLE IDING...
- Page 2 - 2 -...
-
Page 3: Table Of Contents
TABLE OF CONTENTS Inhoudsopgave Safety precautions - Veiligheidsvoorschriften ............... 4 Packing contents - Inhoud verpakking ................5 Connecting battery / accumulator - Verbinden batterij / accu ........5 Product description - Productomschrijving ..............6 Specifications - Specificaties ....................7 Product overview - Productoverzicht ................8 Operation instructions - Bedieningsinstructies ............ -
Page 4: Safety Precautions Veiligheidsvoorschriften
Deze handleiding bevat belangrijke veiligheidsinstructies die u te allen tijde moet volgen tijdens gebruik van de ELE-PSU305C labvoeding. Zorg voor uw eigen veiligheid en die van uw omgeving. Voor optimaal gebruik, zorg ervoor dat het product wordt gebruikt in de juiste omgeving en omstandigheden. -
Page 5: Packing Contents Inhoud Verpakking
PACKING CONTENTS Inhoud verpakking • ELE-PSU305C power supply • ELE-PSU305C labvoeding • EU power cord • EU netsnoer • Set test leads • Set meetsnoeren (4mm to aligator clip) (4mm naar krokoklem) • User manual • Handleiding • Warranty card •... -
Page 6: Product Description Productomschrijving
PRODUCT DESCRIPTION Productomschrijving The ELE-PSU305C is an extremely compact, regulated DC power supply with a 4-digit display for accurately displaying voltage and current. Designed to be used in laboratories, schools, product lines and other electronics workplaces. The power supply with stepless control has a range up to 30V and 5A, with a resolution of 0.1V and 10mA. -
Page 7: Specifications Specificaties
SPECIFICATIONS Specificaties Specification ELE-PSU305C power supply Voltage- & current range 0 ~ 30 V ; 0 ~ 5 A Input voltage 220 V ± 10% ; 50 Hz Working temperature 0 ~ 40 °C ; Relative humidity: < 80% RH Storage temperature -10 ~ 70 °C ;... -
Page 8: Product Overview Productoverzicht
PRODUCT OVERVIEW Productoverzicht Output voltage / Uitgangsspanning Output current / Uitgangsstroom Constant voltage indicator / C.V. indicator Constant current indicator / C.C. indicator Negative terminal (black) / Min-aansluiting (zwart) Positive terminal (red) / Plus-aansluiting (rood) CURRENT VOLTAGE Current tuner / Stroom instellen Voltage tuner / Spanning instellen Power socket... -
Page 9: Operation Instructions Bedieningsinstructies
OPERATION INSTRUCTIONS Bedieningsinstructies There are two types of power output modes: constant voltage output (CV) and constant current output (CC). The output mode is determined by the voltage and current values set by the user and the load connected by the user. The output voltage or current value of the power supply won’t exceed the voltage and current values set by the user. - Page 10 CONSTANT VOLTAGE / CONSTANT CURRENT CHARACTERISTICS A characteristic of this power supply is that it can automatically change from constant voltage mode to constant currenct mode (or vice versa) if a change in the load connected has been detected. The point of changing state from one mode to the other is called the “conversion point”.
- Page 11 VERBIND EEN BELASTING ZONDER GEBRUIK VAN 4MM (BANAAN) STEKKERS Draai de schroefconnector los door deze tegen de richting van de klok in te draaien. Steek de connector / snoer in de opening. Draai de schroefconnector weer vast door deze met de richting van de klok mee te draaien.
-
Page 12: Fuse Replacement Zekering Vervangen
FUSE REPLACEMENT Zekering vervangen If the fuse blows, the power supply will stop working. First find the cause of the blown fuse and make sure it will not happen again. Then replace the blown fuse with a new one with the same specifications. - Page 13 Als de zekering is opgeblazen zal de labvoeding niet meer werken. Ontdek eerst wat de oorzaak is en zorg dat het niet weer kan gebeuren. Vervang dan de kapotte zekering door een nieuwe met zekering met dezelfde specificaties. Vervang de zekering en zet het zekeringscompartiment terug in de labvoeding.
-
Page 14: Warranty Garantie
WARRANTY Garantie The warranty period of this product starts from the date of purchase. Failures caused by improper use, such as improper handling and improper repair, modification or adjustment of the device are not covered by warranty. Maintenance costs are charged for repairs that exceed the warranty period, and the costs incurred for maintenance are the responsibility of the user. - Page 15 This page is left empty on purpose. Deze pagina is bewust leeggelaten. - 15 -...
- Page 16 For more information or the latest updates, please check eleshop.eu. Questions? Contact Eleshop. Voor meer informatie of de laatste updates, kijk snel op www.eleshop.nl. Vragen? Neem contact op met Eleshop.
