Summary of Contents for ROLENCE ENTERPRISE ROLENCE ELiTEDENT MS-1
- Page 1 User Manual ® ® ROLENCE ELiTEDENT MS-1 ULTRASONIC SCALER (25/30K) ROLENCE ENTERPRISE INC. No. 18-3, Lane 231, Pu Chung Rd., Chungli, Taoyuan 32083, Taiwan TEL: 886-3-4631999 FAX: 886-3-4631997 www.rolence.com.tw S-19-01-1214-U0001 V1.6...
-
Page 2: Table Of Contents
Table Of Contents Section Section Title Page Number Description of Contents Number Precautions……………………………………………………………………………………………..3 1.1 Precautions for All Systems 1.2 Precautions for Ultrasonic Prophylaxis Procedure Introduction…………………………………………………………………………………………..4 Intended Use……………………………………………………………………………………………4 Specification………………………………………….………………………………………………...4 Contraindications and Warnings…………………………………………………………………5 5.1 Contraindications 5.2 Warnings Infection Control……………………………………………………………………………………….5 6.1 General Infection Control Recommendations 6.2 Water Supply Recommendations Installation Instructions……………………………………………………………………………6 7.1 General Information... -
Page 3: Section 1: Precautions
Section 1: Precautions Prior to installation and start-up of the ultrasonic scaler, carefully read the instructions provided herein! 1.1 Precautions for All Systems Do not place the ultrasonic scaler on or next to a radiator or other heat source. Excessive heat may damage the ultrasonic scaler’s electronics. -
Page 4: Section 2: Introduction
Section 2: Introduction Rolence Enterprise Inc. is an ISO 13485 certified 2.2 Supplies and Replacement Parts manufacturer of Ultrasonic Scalers. All the products Contact your local Rolence dealer to order supplies are FDA registered and compliant with EN standard or replacement parts. There are no serviceable parts (CE Marking). -
Page 5: Section 5: Contraindications And Warnings
Section 5: Contraindications and Warnings 5.1 Contraindications 5.2 Warnings ‧ Ultrasonic Systems should not be used for ‧ Persons who are fitted with cardiac pacemakers, restorative dental procedures involving the defibrillators and other active implanted medical condensation of amalgam. devices, have been cautioned that some types of ®... -
Page 6: Section 7: Installation Instructions
Section 7: Installation Instructions 4. User Manual. 7.1 General Information 5. Ultrasonic Inserts (Optional). ® If the installation of your ELiTEDENT ultrasonic scaler is performed by someone other than 7.5 System Installation ® trained Rolence distributor personnel, care should ‧ The ELiTEDENT MS-1 is designed for both be taken to observe the following requirements horizontal and vertical placement on a level... -
Page 7: Elitedent ® Ultrasonic Scaler Description
® Section 8: ELiTEDENT Ultrasonic Scaler Description 8.1 System Controls – Rear Panel MS Handpiece Cable Power Socket Solenoid Water Inlet Handpiece Holder Securely holds the Sterilizable Sleeve of Foot Pedal Connector Handpiece when system Connect foot pedal here, is not being used. ensure it is firmly seated. -
Page 8: Section 9: Accessories
8.3 Sterilizable Sleeve of Handpiece Assembly ® The ultrasonic scaler is multi-frequency unit compatible with all Cavitron 25Khz or 30 Khz inserts. The system will automatically detect the insert frequency, no need to switch any button. For more oral hygiene care, the handpiece sleeve can be dismantled and autoclaved. See below: Sterilizable Sleeve of Handpiece Enable to dismantle and... -
Page 9: Section 10: Techniques For Use
Section 10: Techniques For Use ‧ 10.1 Patient Positioning ‧ In general, it is suggested a "feather-light-touch" ‧ be used both supra and subgingivally. The motion ‧ For optimal access to both the upper and lower of the activated tip and acoustic effects of the arches, the backrest of the chair should be irrigating fluid, in most cases, is adequate to adjusted to a 45∘... -
Page 10: Section 11: System Maintenance And Care
Section 11: System Maintenance and Care Daily Maintenance and flush the water line at maximum water flow It is recommended that you perform the following for 30 seconds. maintenance procedures to help minimize bio-film 4. When ready, place a sterilized insert into the ®... -
Page 11: Section 12: Trouble Shooting
Section 12: Trouble shooting ® Although service and repair of the ELiTEDENT Ultrasonic Scaler should be performed by ROLENCE (Power Indicator Light is lit.) dealer personnel, the following are some basic 1. Check that the Foot Pedal Connector is fully trouble shooting procedures that will help avoid seated in the Foot Pedal Receptacle on the back of unnecessary service calls. -
Page 12: Section 15: Warranty
Section 15: Warranty 15.1 Malfunction Rolence hereby warrants that for a period of one year from the delivery date, this device shall be free from defects in material and workmanship. In case the machine is found malfunctioned under normal use, Rolence will offer service of free maintenance and parts for replacement. - Page 13 ANNEX I Guidance and manufacturer’s declaration-electromagnetic emissions The MS-1 is intended for use in the electromagnetic environment specified below. The customer or the user of the MS-1 should assure that it is used in such an environment. Emission test Compliance Electromagnetic environment-guidance RF emissions Group 1...
- Page 14 Guidance and manufacturer’s declaration-electromagnetic immunity The MS-1 is intended for use in the electromagnetic environment specified below. The customer or the user of the MS-1 should assure that it is used in such an environment. Immunity test IEC 60601 Compliance level Electromagnetic test level environment-guidance...
- Page 15 Guidance and manufacturer’s declaration-electromagnetic immunity The MS-1 is intended for use in the electromagnetic environment specified below. The customer or the user of the MS-1 should assure that is used in such and environment. Immunity test IEC 60601 test Compliance Electromagnetic environment-guidance level level...
- Page 16 Recommended separation distance between portable and mobile RF communications equipment and the MS-1 The MS-1 is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The customer or the user of the MS-1 can help prevent electromagnetic interference by maintaining a minimum distance between portable and mobile RF communications equipment (transmitters) and the MS-1 as recommended below, according to the maximum output power of the communications equipment.
