- Page 1 User Manual LED Curing Light Ultra-Lite 1000E DUAL Mini LED handpiece fits in your hand perfectly ROLENCE ENTERPRISE INC. No. 18-3, Lane 231, Pu Chung Rd., Chungli, Taoyuan 32083, Taiwan Tel: +886-3 4631999; Fax: +886-3 4631997; sales@rolence.com.tw S-19-01-1110-U0031 V 1.2...
-
Page 2: Table Of Contents
Table of Content Safety Precautions………………………………………………………………………………… p. 3 Product Description & Fields of Application……………………………………………… p. 4 Technical Features………………………………………………………………………………… p. 4~5 Charging base Hand piece Operation Environment Transportation and Storage Environment Package Content…………………………………………………………………………………… p. 5 Additional Symbols………………………………………………………………………………… p. 6 Installation…………………………………………………………………………………………… p. 6~8 Charging base Indicator on the charging base Light Guide / Battery Charging... -
Page 3: Safety Precautions
1. Safety Precautions PLEASE NOTE! Prior to installation and start-up of the unit, carefully read the instructions provided herein! As with all technical devices, the proper function and safe operation of this unit depend on the user’s compliance with the safety recommendations presented in these operating instructions. Before operation, you have to read user manual carefully. -
Page 4: Product Description& Fields Of Application
2. Product Description& Fields of Application The Ultra-lite 1000E DUAL curing light with blue and violet LED is a light curing unit intended for polymerization of light cured dental materials by dental professionals. The Ultra-Lite 100E DUAL incorporates two types of LEDs to achieve broad wavelength with range of 390 to 480nm output to polymerize virtually all light activated resins in the market and a high power mode to produce super fast curing effect. -
Page 5: Operation Environment
Power supply: Lithium battery – 7.4V DC, 2600mAh Wavelength range: 390-480 nm Dimensions: Diameter: 30 mm Length (with/without light guide): 155 / 82 mm Height: 145 mm Weight (with light guide and battery): Roughly 200 g Charging Base and Handpiece Time to charge empty battery: approximate 3 hrs Relative humidity:... -
Page 6: Additional Symbols
5. Additional symbols Attention, Consult accompanying Documents Attention, Consult accompanying Documents Alternating Current Manufacturer Date of manufacture Catalogue number Type BF Applied Part; Type BF Equipment - Protection against electric shock Equipment class: Class II (IEC601-1) - double insulated The equipment complies with the requirements in the Medical Device Directive 93/42 EEC. -
Page 7: Indicator On The Charging Base
6.2 Indicator on the Charging Base Light Checker Window Place light guide here Charging LED indicator gently to measure light LED (orange) flashes when intensity. battery is charging. LED turns ON when charging is completed Power indicator (green LED) illuminates Light intensity indicator when the charging base is (blue LED) illuminates when... -
Page 8: Operation Instruction
Curing time selection: (1) High MODE exposure at constant intensity about 2,000mW/ cm Time selection: 1, 2, 3 seconds (2) Ramp up MODE initial 35~50% energy of high intensity and then switch to high intensity. Time selection: 5 seconds (3 seconds low intensity + 2 seconds high intensity). 10 seconds (8 seconds low intensity + 2 seconds high intensity). -
Page 9: Operating Errors / Trouble Shooting
Damaged light guides must be replaced immediately, since damaged light guide may strongly ► reduces light intensity or injures the patient. Warning signal If the temperature on hand piece is over 50 C, the error code “E2” will show up and buzzer ►... -
Page 10: Measurement Of Light Intensity
significantly shortened. two years). Please contact the dealer to replace with a new battery. If not sure what happen, contact the dealer for further information. Note: We and our authorized distributors will make available on request circuit diagram, component part lists and other information to assist user's appropriate technical personnel to repair the light cure units which are designated by us as repairable. -
Page 11: Disposal
To wash or spray the out surface of power unit and curing gun with water, cleanser and chemical disinfectant is not allowed for it will result electric shock and damage of inner circuit. If this happens, please contact our dealer for inspection before use. ………………………………………………………………………………………………………... -
Page 12: Warranty
13. Warranty 13.1 Malfunction Rolence hereby warrants that for a period of one year from the delivery date, this device shall be free from defects in material and workmanship. In case the machine is found malfunctioned under normal use, Rolence will offer service of free maintenance and parts for replacement. 13.2 Repair Repairs must be only carried out by an authorized Rolence engineer/dealer.
