4 Specifications

Amplifier section
RMS output power stereo mode
Front Hi
250 W per channel (3 Ω), 1 kHz, 30% THD
Front Lo
250 W per channel (3 Ω), 100 Hz, 30% THD
Subwoofer Ch
400 W per channel (2 Ω), 100 Hz, 30% THD
Total RMS stereo mode power
FTC output power stereo mode
Front Hi
150 W per channel (3 Ω), 400 Hz to 20 kHz, 1% THD
Front Lo
60 W per channel (3 Ω), 70 Hz to 200 Hz, 1% THD
Subwoofer Ch
75 W per channel (2 Ω), 60 Hz to 100 Hz, 1% THD
Total FTC stereo mode power
Tuner, terminals section
Preset memory
Frequency modulation (FM)
Frequency range
Antenna terminals
Amplitude modulation (AM)
Music port (front)
Sensitivity
Terminal
AUX Input
Disc section
Discs played [8 cm (3") or 12 cm
(5")]
Pick up
Wavelength
Audio output
Number of channels
FL = Front left channel
FR = Front right channel
SW = Subwoofer channel
*MPEG-1 Layer 3
USB section
USB port
USB standard
Media file format support
USB device file system
USB port power
Bit rate
General
Power supply
Power consumption
Dimensions (W x H x D)
Mass
Operating temperature range
Operating humidity range
Power Consumption in standby mode
1400 W (30% THD)
FM 30 stations
AM 15 stations
87.9 MHz to 107.9 MHz (200 kHz step)
87.5 MHz to 108.0 MHz (100 kHz step)
75 Ω (unbalanced)
520 kHz to 1710 kHz (10 kHz step)
100 mV, 4.7 kΩ
Stereo, 3.5 mm (
CD, CD-R/RW(CD-DA, MP3*)
790 nm(CD)
2.1 ch (FL, FR, SW)
USB 2.0 full speed
MP3 (*.mp3)
FAT12, FAT16, FAT32
500 mA (max)
16 kbps to 320 kbps (playback)
AC 120 V, 60 Hz
220 mm x 334 mm x 250 mm
5 " 1 "
(8 / x 13 /
8 8
3.4 kg (7.5 lbs)
0 °C to +40 °C
(+32 °F to +104 °F)
35% to 80% RH
(no condensation)
Note:
1. Specifications are subject to change without notice.
Mass and dimension are appropriate
2. Total harmonic distortion is measured by the digital spectrum
analyzer.
System: SC-AKX75P-K
495 W
1 "
/ ) jack
8
Pin jack
120 W
1 "
x 10 / )
4
12
0.2 W (approximate)
Main Unit: SA-AKX75P-K
Speakers System: SB-AKX75P-K
