Panasonic SA-AKX75P Service Manual
  1. Manuals
  2. Brands
  3. Panasonic Manuals
  4. Stereo System
  5. SA-AKX75P
  6. Service manual
Panasonic SA-AKX75P Service Manual

Panasonic SA-AKX75P Service Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Please refer to the original service manual for:
CD Mechanism Unit , Order No. PSG1102001CE
Speaker system SB-AKX75P-K, Order No. PSG1304043AE

TABLE OF CONTENTS

1 Safety Precautions----------------------------------------------- 3
1.1. General Guidelines---------------------------------------- 3
1.2. Before Repair and Adjustment ------------------------- 3
1.3. Protection Circuitry ---------------------------------------- 4
1.4. Caution For Fuse Replacement------------------------ 4
1.5. Safety Parts Information --------------------------------- 5
2 Warning -------------------------------------------------------------- 6
2.2. Precaution of Laser Diode------------------------------- 7
prevention --------------------------------------------------10
3 Service Navigation ----------------------------------------------11
PAGE
SA-AKX75P
Model No.
Product Color: (K)...Black Type
3.1. Service Information -------------------------------------- 11
4 Specifications ---------------------------------------------------- 12
5 General/Introduction------------------------------------------- 13
5.1. Media Information---------------------------------------- 13
6.2. Main Unit Key Button Operation---------------------- 15
7 Installation Instructions -------------------------------------- 16
7.1. Speaker and A/C Connection ------------------------- 16
8 Service Mode ----------------------------------------------------- 17
8.1. Cold-Start -------------------------------------------------- 17
8.2. Doctor Mode Table--------------------------------------- 18
8.4. Self-Diagnostic Mode ----------------------------------- 22
© Panasonic Corporation 2013. All rights reserved.
Unauthorized copying and distribution is a violation
of law.
PSG1304027CE
CD Stereo System
A6
PAGE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SA-AKX75P and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Panasonic SA-AKX75P

Summary of Contents for Panasonic SA-AKX75P

  • Page 1: Table Of Contents

    8.3. Reliability Test Mode (CD Mechanism Unit)------- 21 prevention --------------------------------------------------10 8.4. Self-Diagnostic Mode ----------------------------------- 22 8.5. Self-Diagnostic Error Code Table -------------------- 22 3 Service Navigation ----------------------------------------------11 © Panasonic Corporation 2013. All rights reserved. Unauthorized copying and distribution is a violation of law.
  • Page 2 8.6. Sales Demonstration Lock Function ---------------- 23 9 Troubleshooting Guide---------------------------------------- 24 10 Disassembly and Assembly Instructions --------------- 25 10.1. Screw Types----------------------------------------------- 25 10.2. Disassembly Flow Chart-------------------------------- 26 10.3. Main Components and P.C.B. Locations ---------- 27 10.4. Disassembly of Top Cabinet--------------------------- 28 10.5.

  • Page 3: Safety Precautions

    1 Safety Precautions 1.1. General Guidelines 1. IMPORTANT SAFETY NOTICE There are special components used in this equipment which are important for safety. These parts are marked by in the Schematic Diagrams, Circuit Board Layout, Exploded Views and Replacement Parts List. It is essential that these critical parts should be replaced with manufacturer’s specified parts to prevent X-RADIATION, shock, fire, or other hazards.

  • Page 4: Protection Circuitry

    1.3. Protection Circuitry The protection circuitry may have operated if either of the following conditions are noticed: • No sound is heard when the power is turned on. • Sound stops during a performance. The function of this circuitry is to prevent circuitry damage if, for example, the positive and negative speaker connection wires are “shorted”, or if speaker systems with an impedance less than the indicated rated impedance of the amplifier are used.

  • Page 5: Safety Parts Information

    1.5. Safety Parts Information Safety Parts List: There are special components used in this equipment which are important for safety. These parts are marked by in the Schematic Diagrams, Exploded View & Replacement Parts List. It is essential that these critical parts should be replaced with manufacturer’s specified parts to prevent shock, fire or other hazards.

  • Page 6: Warning

    2 Warning 2.1. Prevention of Electrostatic Discharge (ESD) to Electrostatically Sensi- tive (ES) Devices Some semiconductor (solid state) devices can be damaged easily by static electricity. Such components commonly are called Elec- trostatically Sensitive (ES) Devices. The following techniques should be used to help reduce the incidence of component damage caused by electrostatic discharge (ESD).

  • Page 7: Precaution Of Laser Diode

    2.2. Precaution of Laser Diode Caution: This product utilizes a laser diode with the unit turned “on”, invisible laser radiation is emitted from the pickup lens. Wavelength: 790 nm (CD) Maximum output radiation power from pickup: 100 µW/VDE Laser radiation from the pickup unit is safety level, but be sure the followings: 1.

  • Page 8: Service Caution Based On Legal Restrictions

    2.3. Service caution based on Legal restrictions 2.3.1. General description about Lead Free Solder (PbF) The lead free solder has been used in the mounting process of all electrical components on the printed circuit boards used for this equipment in considering the globally environmental conservation. The normal solder is the alloy of tin (Sn) and lead (Pb).

  • Page 9: Handling Precautions For Traverse Unit

    2.4. Handling Precautions for Traverse Unit The laser diode in the optical pickup unit may break down due to static electricity of clothes or human body. Special care must be taken avoid caution to electrostatic breakdown when servicing and handling the laser diode in the traverse unit. Cautions to Be Taken in Handling the Optical Pickup Unit 2.4.1.

  • Page 10: Grounding For Electrostatic Breakdown Prevention

    2.5. Grounding for electrostatic breakdown prevention • As for parts that use optical pick-up (laser diode), the optical pick-up is destroyed by the static electricity of the working environ- ment. Repair in the working environment that is grounded. 2.5.1. Worktable grounding •...

  • Page 11: Service Navigation

    3 Service Navigation 3.1. Service Information This service manual contains technical information which will allow service personnel’s to understand and service this model. Please place orders using the parts list and not the drawing reference numbers. If the circuit is changed or modified, this information will be followed by supplement service manual to be filed with original service manual.

  • Page 12: Specifications

    250 W per channel (3 Ω), 1 kHz, 30% THD Front Lo System: SC-AKX75P-K 250 W per channel (3 Ω), 100 Hz, 30% THD Main Unit: SA-AKX75P-K Subwoofer Ch Speakers System: SB-AKX75P-K 400 W per channel (2 Ω), 100 Hz, 30% THD...

  • Page 13: General/Introduction

    5 General/Introduction 5.1. Media Information...

  • Page 14: Location Of Controls And Components

    6 Location of Controls and Components 6.1. Remote Control Key Button Operation...

  • Page 15: Main Unit Key Button Operation

    6.2. Main Unit Key Button Operation...

  • Page 16: Installation Instructions

    7 Installation Instructions 7.1. Speaker and A/C Connection...

  • Page 17: Service Mode

    8 Service Mode 8.1. Cold-Start Here is the procedure to carry out cold-start or initialize to shipping mode. 1. Unplug AC power cord 2. Press & hold [POWER] button 3. Plug AC power cord while [POWER] button being pressed FL Display will show “_ _ _ _ _ _ _ _” 4.

  • Page 18: Doctor Mode Table

    8.2. Doctor Mode Table 8.2.1. Doctor Mode Table 1 Item Key Operation FL Display Mode Name Description Front Key Doctor Mode To enter into Doctor Mode In CD Mode: 1. Press [ ] button on main unit follow by [4] and [7] on remote control.
  • Page 19 8.2.2. Doctor Mode Table 2 Item Key Operation FL Display Mode Name Description Front Key Volume Setting To check the volume setting of the In Doctor Mode: Check main unit. 1. Press [7], [8], [9] button on the remote control. Press [7]: VOL50 Volume Press [8]: VOL35...
  • Page 20 8.2.3. Doctor Mode Table 3 Item Key Operation FL Display Mode Name Description Front Key To display result of In Doctor Mode : Self- Adjustment self-adjustment for CD. 1. Press [10] [4] button Test on the remote control. Display of auto adjustment result Reference table: ERROR Code...

  • Page 21: Reliability Test Mode (Cd Mechanism Unit)

    8.3. Reliability Test Mode (CD Mechanism Unit) Below is the process flow chart of the aging test for the CD Mechanism Unit . OPEN First Track Operation Access OPEN wait First Track for 1 s Play 5 s CLOSE Count up Last Track Operation Access...

  • Page 22: Self-Diagnostic Mode

    8.4. Self-Diagnostic Mode Item Key Operation FL Display Mode Name Description Front Key Self Diagnostic To enter into self diagnostic checking Step 1: Select CD mode Mode (Ensure no disc is inserted). Step 2: Press & hold [ ] button follow by [ ] on main unit for 2 seconds.

  • Page 23: Sales Demonstration Lock Function

    8.5.2. CD Mechanism Error Code Table (CD Mechanism Unit) Error Code Diagnostic Contents Description of error Automatic FL Display Remarks CD H15 CD Open Abnormal During operation Press [ ] on main unit for POS_SW_R On fail to be next error. detected with 4 sec.

  • Page 24: Troubleshooting Guide

    9 Troubleshooting Guide "Contents for this section is not available at time of issue"...

  • Page 25: Disassembly And Assembly Instructions

    10 Disassembly and Assembly Instructions Caution Note: • This section describes the disassembly and/or assembly procedures for all major printed circuit boards & main compo- nents for the unit. (You may refer to the section of “Main components and P.C.B Locations” as described in the service manual) •...

  • Page 26: Disassembly Flow Chart

    10.2. Disassembly Flow Chart 10.4.Top Cabinet 10.5 Front Panel Unit 10.10. Rear Panel 10.15. Fan Unit 10.6. Panel P.C.B., 10.12. SMPS P.C.B. 10.11. Main P.C.B. Memory LED P.C.B. and Music Port P.C.B. 10.13. CD Mechanism Unit 10.7. Remote Sensor P.C.B. 10.14.

  • Page 27: Main Components And P.c.b. Locations

    10.3. Main Components and P.C.B. Locations...

  • Page 28: Disassembly Of Top Cabinet

    10.4. Disassembly of Top Cabinet Step 4 Slightly lift up the Top Cabinet in an outward direction as shown. Step 1 Remove 2 screws on each side. Step 5 Remove the Top Cabinet. Step 2 Remove 5 screws. Step 3 Slightly release both side of Top Cabinet outwards as arrow shown.

  • Page 29: Disassembly Of Front Panel Unit

    10.5. Disassembly of Front Panel Step 4 Release tab at the left side of the Front Panel Unit. Unit • Refer to “Disassembly of Top Cabinet”. Step 1 Detach 30P FFC at the connector (CN2004) on Main P.C.B.. Step 2 Detach 5P Cable at the connector (CN2001) on Main P.C.B..

  • Page 30: Disassembly Of Panel P.c.b., Memory Led P.c.b. And Music Port P.c.b

    Step 6 Release tabs at bottom. 10.6. Disassembly of Panel P.C.B., Memory LED P.C.B. and Music Port P.C.B. • Refer to “Disassembly of Top Cabinet”. • Refer to “Disassembly of Front Panel Unit”. Step 1 Remove the Volume Knob. Step 2 Remove the Control Knob. Step 7 Detach the Front Panel Unit as arrow shown.
  • Page 31 Step 4 Release catches by following the sequences (1-9). Step 5 Lift up the Panel P.C.B. and Memory LED P.C.B. from the Front Panel Unit. Caution: During assembling, ensure that the Memory LED P.C.B. is properly insert to the Front Panel Unit.

  • Page 32: Disassembly Of Remote Sensor P.c.b

    Caution: During assembling, ensure that the Panel P.C.B. Caution: During assembling, ensure that the Music Port is seated properly onto the locators & fully catched. P.C.B. is seated properly into the locators & fully catched. 10.7. Disassembly of Remote Sensor P.C.B.

  • Page 33: Disassembly Of Usb P.c.b

    10.8. Disassembly of USB P.C.B. 10.9. Disassembly of CD Lid • Refer to “Disassembly of Top Cabinet”. • Refer to “Disassembly of Top Cabinet”. • Refer to “Disassembly of Front Panel Unit”. • Refer to “Disassembly of Front Panel Unit”. Step 1 Remove 1 screw.

  • Page 34: Disassembly Of Rear Panel

    10.10. Disassembly of Rear Panel Step 4 Lift up to remove Inner Chassis Unit from the Rear Panel. • Refer to “Disassembly of Top Cabinet”. Step 1 Remove 9 screws. Step 5 Release tabs. Step 6 Remove Rear Panel. Step 2 Release catch at the Fan Unit . Step 3 Remove the Fan Unit .

  • Page 35: Disassembly Of Main P.c.b

    10.11. Disassembly of Main P.C.B. Step 4 Remove 2 screw. Step 5 Lift up the Main P.C.B.from the slots at the Inner Chas- • Refer to “Disassembly of Top Cabinet”. sis Unit according to arrow shown. • Refer to “Disassembly of Front panel Unit”. Step 1 Detach 2P Wire at the connector (CN2007) on Main P.C.B..

  • Page 36: Disassembly Of Smps P.c.b

    Step 6 Detach 10P FFC at the connector (FP8251) on the Main Step 2 Remove 3 screws. P.C.B.. Step 3 Detach 13P Cable Wire at the connector (CN5802) on Step 7 Detach 24P FFC at the connector (FP8201) on the Main SMPS P.C.B..

  • Page 37: Disassembly Of Cd Mechanism Unit

    10.13. Disassembly of CD Mecha- Step 3 Release catches. Step 4 Lift up and remove the Inner Chassis Unit. nism Unit • Refer to “Disassembly of Top Cabinet”. • Refer to “Disassembly of Front Panel Unit”. • Refer to “Disassembly of Main P.C.B”. Step 1 Remove 3 screws.

  • Page 38: Disassembly Of Cd Interface P.c.b

    Step 5 Remove 2 screws. 10.14. Disassembly of CD Interface Step 6 Remove the CD Mechanism Unit. P.C.B. • Refer to “Disassembly of Top Cabinet”. • Refer to “Disassembly of Front Panel Unit”. • Refer to “Disassembly of Main P.C.B.”. •...

  • Page 39: Disassembly Of Fan Unit

    10.15. Disassembly of Fan Unit • Refer to “Disassembly of Top Cabinet”. Step 1 Remove 1 screw. Step 2 Detach 2P Wire at a connector (CN2007) on the Main P.C.B.. Step 3 Release catch. Step 4 Remove the Fan Unit. Caution: During assembling, ensure that the Fan Unit is catched onto the Rear Panel properly.

  • Page 40: Service Position

    11 Service Position Note: For description of the disassembly procedures, see 11.3. Checking of Main P.C.B. (Side the Section 10. 11.1. Checking of Panel P.C.B. Step 1 Remove Top Cabinet. Step 1 Remove Top Cabinet. Step 2 Remove Front Panel Unit. Step 2 Remove Front Panel Unit.

  • Page 41: Checking Of Smps P.c.b

    Step 7 Attach 10P FFC at the connector (FP8251) on the Main 11.4. Checking of SMPS P.C.B. P.C.B.. Step 1 Remove Top Cabinet. Step 8 Attch 24P FFC at the connector (FP8201) on the Main Step 2 Remove Front Panel Unit. P.C.B..

  • Page 43: Block Diagram

    OPEN SW OPEN SW OPEN SW CD OPEN SW CN7001 CN7002 FP8251 CLOSE SW CLOSE SW CLOSE SW CD CLOSE SW CD INTERFACE P.C.B. NOTE: “ * ” REF IS FOR INDICATION ONLY SA-AKX75P SERVO & SYSTEM CONTROL (1/2) BLOCK DIAGRAM...
  • Page 44 STOP/TUNE MODE PLAY/PAUSE KEY3 CN2004 CN6001 KEY3 KEY3 94 REMOTE SENSOR P.C.B. IR6500 REMOTE CONTROL SENSOR CN2004 CN6001 CN6002 CN6500 +3.3V RMT 86 NOTE: “ * ” REF IS FOR INDICATION ONLY SA-AKX75P SERVO & SYSTEM CONTROL (2/2) BLOCK DIAGRAM...

  • Page 45: Audio

    DAP VALID MPORT R ZJ6300* ZJ6000* CN6001 CN2004 MPORT R MUSIC PORT ZJ6300* ZJ6000* CN6001 CN2004 MPORT L MPORT L IC2002 C0JBAR000367 AUDIO PANEL P.C.B. SELECTOR NOTE: “ * ” REF IS FOR INDICATION ONLY SA-AKX75P AUDIO (1/2) BLOCK DIAGRAM...
  • Page 46 INPUT A BST A OUT A JK2501 TO AUDIO OUT A BLOCK (1/2) SUBWOOFER JK2501 INPUT B OUT B BST B /RST BST C OUT C /CLIP OUT D /OTW OUT D /FAULT BST D SA-AKX75P AUDIO (2/2) BLOCK DIAGRAM...

  • Page 47: Power Supply

    VSENSE 7 Q5701 SWITCH DRIVE D5728 Q5711 CURRENT LIMITING SWITCH +36V SENSE CN5802 CN2008 +36V SENSE PW +36V 5,6,7 5,6,7 FEEDBACK CIRCUIT IC5801 C0DAZYY00039 SHUNT REGULATOR PC5720 TO POWER SUPPLY BLOCK (2/2) PRIMARY SECONDARY SA-AKX75P POWER SUPPLY (1/2) BLOCK DIAGRAM...
  • Page 48 CN2001 ZJ6400* VBUS VBUS VBUS VBUS 4 IN OUT 5 VBUS 3 FLG FROM/TO SERVO & SYSTEM CONTROL 1 CTL TO POWER SUPPLY BLOCK (1/2) NOTE: “ * ” REF IS FOR INDICATION ONLY SA-AKX75P POWER SUPPLY (2/2) BLOCK DIAGRAM...

  • Page 49: Wiring Connection Diagram

    (TRAVERSE MEMORY LED P.C.B. MOTOR) CN7001 (SOLDER SIDE) IR6500 3 2 1 CN5802 CN5802 SENSOR TO LOADING P.C.B. (CD MECHANISM UNIT BRS11C) REMOTE SENSOR P.C.B. (SOLDER SIDE) NOTE: " * " REF IS FOR INDICATION ONLY. SA-AKX75P WIRING CONNECTION DIAGRAM...

  • Page 51: Schematic Diagram

    14 Schematic Diagram • Voltage and signal line : +B signal line : -B signal line 14.1. Schematic Diagram Notes : CD Audio input signal line : Tuner/Music Port/AUX Audio input signal line • This schematic diagram may be modified at any time : Audio output signal line with the development of new technology.

  • Page 53: Main (Cd Servo/Micon/Damp) Circuit

    CMD_EMMC C8055 R8506 31 32 36 37 R8505 DAT2_SD IC8051 DAT1_SD C3ABMY000027 DAT0_SD 16M SDRAM DAT3_SD R8504 10 9 LB8052 R8507 J0JHC0000045 LB8501 C8054 C8042 J0JHC0000045 PW_3R3V_DIG C8506 DGND TO MAIN (CD SERVO) CIRCUIT (3/4) SA-AKX75P MAIN (CD SERVO) CIRCUIT...
  • Page 54 (CD MECHANISM UNIT BRS11C) VREF C8203 0.01 VCC(5V) R8215 CD-LD MD/LPD Q8201 B1ADCF000001 DVD-LD LASER DRIVE GND-LD R8212 C8259 C8202 PW_3R3V_CD D8250 C8260 DZ2J056M0L 0.01 C8201 PD_GND LB8202 D8251 DA2J10100L G1C100KA0101 PW_+5R4V TO MAIN (CD SERVO) CIRCUIT (4/4) SA-AKX75P MAIN (CD SERVO) CIRCUIT...
  • Page 55 LB8201 CD_STAT J0JHC0000045 PW_3R3V_DIG CD_MLD R8210 R8211 R8010 2.7K 100K C8013 C8018 R8011 R8002 6.3V100 0.33 100K NRST CD_RESET C8068 3300P R8005 R8006 X8101 MI: MAIN (MICON): SCHEMATIC DIAGRAM - 5 ~ 10 C8015 C8016 SA-AKX75P MAIN (CD SERVO) CIRCUIT...
  • Page 56 R8258 R8261 R8260 R8259 4.7K R8264 1.2K PW_3R3V_CD R8263 C8256 C8261 1000P K8208 C8262 C8252 C8251 CHASSIS GND 10V100 0.01 LB8252 J0JHC0000045 PW_+5R4V LB8251 J0JHC0000045 PW_+5R4V MI: MAIN (MICON): SCHEMATIC DIAGRAM - 5 ~ 10 SA-AKX75P MAIN (CD SERVO) CIRCUIT...
  • Page 57 3.3K R3033 R2070 4.7K QR2001 R2071 3.9K B1GBCFJJ0051 SWITCH R2114 6.8K X2002 TO MAIN (MICON) CD: MAIN (CD SERVO): SCHEMATIC DIAGRAM - 1 ~ 4 CIRCUIT (4/6) DA: MAIN (DAMP): SCHEMATIC DIAGRAM - 11 ~ 14 SA-AKX75P MAIN (MICON) CIRCUIT...
  • Page 58 A+IN PW_+12V +12V RED_LED RED_LED B+IN GREEN_LED R2157 C2081 R2154 GREEN_LED BLUE_LED BLUE_LED SUBW_LED R3106 SUBW_LED C2071 R2141 3.3K FAN_OUT C2070 R2139 3.3K DC_DET_AMP PW_+15V MGND TO MAIN (MICON) CIRCUIT (3/6) TO MAIN (MICON) CIRCUIT (5/6) SA-AKX75P MAIN (MICON) CIRCUIT...
  • Page 59 USB HIGH SIDE SWITCH C2030 R2057 QR2000 B1GBCFGN0016 R2061 LED DRIVE 100K DGND Q2000 B1ADCE000012 USB_PLAY_LED2 SWITCH LED_DRV_RST TO MAIN (MICON) CIRCUIT (2/6) CD: MAIN (CD SERVO): SCHEMATIC DIAGRAM - 1 ~ 4 TO MAIN (MICON) CIRCUIT (6/6) SA-AKX75P MAIN (MICON) CIRCUIT...
  • Page 60 6.3V220 0.47 L2005 L2006 L2000 G1C1R0MA0204 G2A380Y00002 PW_CD_3R3V R2011 JK2002 C2010 AM ANT AM ANT AM ANT R2012 R2015 4.7K 4.7K TU_SDA R2018 TU_SCL R2019 R2020 TU_RST DA: MAIN (DAMP): SCHEMATIC DIAGRAM - 11 ~ 14 SA-AKX75P MAIN (MICON) CIRCUIT...
  • Page 61 SDIN3 LRCLKD DAP_I2S_LRCKO SCLKD DAP_I2S_BCKO SDIN4 DAP_I2S_OUT VR_DIG SDOUT C3218 DGND C2075 C2078 LB3201 J0JBC0000134 PW_CD_3R3V R3224 CD: MAIN (CD SERVO): SCHEMATIC DIAGRAM - 1 ~ 4 DA: MAIN (DAMP): SCHEMATIC DIAGRAM - 11 ~ 14 SA-AKX75P MAIN (MICON) CIRCUIT...
  • Page 62 +3.3V VOLTAGE REGULATOR C2089 DZ2000 B0JCPG000030 R2169 COMP C2103 0.01 GND VOUT VSENSE SS/TR R3355 PW_CD_3R3V 1.8M R2170 R2178 PWGND RT/CLK R3354 Q2023 C3307 C2080 C2084 C2086 C2087 C2092 R2188 4700P B1GBCFJJ0041 6.3V1000 10V220 270K SWITCH DGND SA-AKX75P MAIN (MICON) CIRCUIT...
  • Page 63 TO MAIN (DAMP) SP_SW2- CIRCUIT (2/4) SP_FR+LO R2595 R2655 100K C2656 C2684 1000P 0.01 C2657 0.01 C2685 1000P R2656 R2596 100K C2693 1000P SP_FR-LO MI: MAIN (MICON): SCHEMATIC DIAGRAM - 5 ~ 10 TO MAIN (DAMP) CIRCUIT (3/4) SA-AKX75P MAIN (DAMP) CIRCUIT...
  • Page 64 FL-_LO INPUT_D PVDD_CD 0.22 R3631 SP_FL+LO DAMP_FAULT /FAULT PVDD_CD DAMP_OTW /OTW OUT_D DAMP_CLIP /CLIP OUT_D C2552 0.033 R3667 BST_C C2549 0.033 GVDD_CD BST_D C2714 R3652 R3651 MI: MAIN (MICON): SCHEMATIC DIAGRAM - 5 ~ 10 ZJGND_HS3 SA-AKX75P MAIN (DAMP) CIRCUIT...
  • Page 65 100K SP_FL-LO C2694 1000P SP_FL+HI C2695 1000P DGND R2589 R2661 100K C2650 C2686 1000P 0.01 C2651 0.01 R2590 R2662 100K SP_FL-HI R3653 R3654 ZJGND_HS4 C2679 R3501 DGND MI: MAIN (MICON): SCHEMATIC DIAGRAM - 5 ~ 10 SA-AKX75P MAIN (DAMP) CIRCUIT...
  • Page 66 DAMP_CLIP /CLIP OUT_D TO MAIN (DAMP) CIRCUIT (3/4) R3660 C2547 0.033 BST_C PW_+12V C2548 0.033 GVDD_CD BST_D C2524 DGND R3658 R3657 R3656 R3655 ZJGND_HS5 ZJGND_HS1 PW_+36V DAP_VALID MI: MAIN (MICON): SCHEMATIC DIAGRAM - 5 ~ 10 SA-AKX75P MAIN (DAMP) CIRCUIT...

  • Page 67: Panel Circuit

    C6101 C6102 C6201 C6202 POWER SAVE CONTROL IN SCHEMATIC 100P 100P 100P 100P D6005 B0EAMM000057 DIAGRAM - 17 R6025 C6021 5.6K 25V220 R6109 R6110 R6208 R6209 PW_+15V R6032 D6012 B0BC2R4A0006 C6024 FL_GND 16V100 D6008 B0JAME000114 R6028 R6030 SA-AKX75P PANEL CIRCUIT...
  • Page 68 R6204 R6210 1.2K 1.5K 2.2K 3.3K 4.7K 6.8K S6107 S6204 S6200 S6203 S6202 S6206 S6207 S6201 S6208 DISPLAY POWER PRESET EQ MANUAL EQ DIMMER REWIND FORWARD D.BASS OPEN/CLOSE NOTE: “ * ” REF IS FOR INDICATION ONLY SA-AKX75P PANEL CIRCUIT...

  • Page 69: Usb, Music Port, Memory Led & Remote Sensor Circuit

    1000P DIAGRAM - 16 C6500 C6502 100P CN6500 16V33 DGND PANEL CIRCUIT SYS3.3V (CN6002) IN SCHEMATIC DIAGRAM - 15 NOTE: “ * ” REF IS FOR INDICATION ONLY SA-AKX75P USB / MUSIC PORT / MEMORY LED / REMOTE SENSOR CIRCUIT...

  • Page 70: Smps Circuit

    CURRENT R5728 C5720 100P 100K LIMITING SWITCH D5724 DA2J10100L D5722 DZ2J200M0L C5728 1000P C5721 D5723 220P C5722 DA2J10100L 1000P PC5701 FEEDBACK D5727 DA2J10100L R5810 QR5810 B1GBCFLL0037 PCONT SWITCH SA-AKX75P SMPS CIRCUIT NOTE: “ * ” REF IS FOR INDICATION ONLY...
  • Page 71 DZ2J091M0L SWITCHING MODE POWER SUPPLY CONTROL TO SMPS R5895 R5893 CIRCUIT (1/2) C5898 R5892 C5794 R5795 D5793 1000P 470K B0HAMP000094 C5790 2200P R5797 R5891 C5899 10V220 C5796 C5795 SA-AKX75P SMPS CIRCUIT NOTE: “ * ” REF IS FOR INDICATION ONLY...

  • Page 72: Voltage Selector & Cd Interface Circuit

    SPINDLE MOTOR CN7002 SPM+ SPM- CLOSE_SW REST_SW MAIN (CD SERVO) DGND CIRCUIT (FP8251) OPEN_SW IN SCHEMATIC LDM- S7201 DIAGRAM - 4 LDM+ RESET TRV- TRV+ M7301* TRAVERSE MOTOR NOTE: “ * ” REF IS FOR INDICATION ONLY SA-AKX75P CD INTERFACE CIRCUIT...

  • Page 73: Printed Circuit Board

    R2053 R2222 R3222 R2055 R2060 C2051 R2048 C3000 Q2003 R2109 R2163 R3022 R3007 R2056 R2157 Q2004 C2082 R2161 QR2003 C2071 R2158 R2155 R3016 IC2010 R2162 R2156 D2003 R3034 R3017 R3018 QR2002 R2154 C2081 3620A-1 3620A-1 (SIDE A) SA-AKX75P MAIN P.C.B.
  • Page 74 LB3401 (TO SUBWOOFER R3108 9-FL+_HIGH VA2002 FP9003 (SB-AKW75)) 1-SW+ 3-FR+_LOW 5-FR+_HIGH 7-FL+_LOW QR3104 1-GND 4-GND (FOR DEBUG) R3114 2-SW- 4-FR-_LOW 6-FR-_HIGH 8FL-_LOW 10-FL-_HIGH 3620A-1 3620A-1 JK2002 TO SPEAKERS AUX IN FM ANT AM ANT (SUBWOOFER/FRONT) (SIDE B) SA-AKX75P MAIN P.C.B.

  • Page 75: Panel, Usb, Music Port & Memory Led P.c.b

    R6101 (CD) (RADIO/EXT-IN) R6111 S6107 C6022 D6006 (CD OPEN/CLOSE) R6100 VR6200 S6104 C6201 R6208 (USB) C6202 R6209 S6103 (ALBUM/TRACK) ALBUM/TRACK NOTE: " * " REF IS FOR INDICATION ONLY SA-AKX75P PANEL / USB / MUSIC PORT / MEMORY LED P.C.B.

  • Page 76: Smps & Voltage Selector P.c.b

    W5531 L5801 R5865 C5818 R5805 R5814 IC5899 PC5702 W5916 Q5803 T5751 W5517 W5521 C5832 (SUB TRANSFORMER) D5896 W5519 W5918 R5898 R5893 CN5802 R5909 C5896 R5700 C5895 Q5898 W5908 NOTE: " * " REF IS FOR INDICATION ONLY SA-AKX75P SMPS P.C.B.

  • Page 77: Remote Sensor & Cd Interface P.c.b

    CD INTERFACE P.C.B. (REP4945A) M7302* (SPINDLE MOTOR) CN6500 C6502 IR6500 S7201 (RESET) SENSOR CN7002 CN7001 M7301* TO LOADING P.C.B. (TRAVERSE (CD MECHANISM MOTOR) UNIT BRS11C) 3556A 3556A NOTE: " * " REF IS FOR INDICATION ONLY SA-AKX75P REMOTE SENSOR / CD INTERFACE P.C.B.

  • Page 79: Appendix Information Of Schematic Diagram

    CD PLAY STANDBY IC2006 REF NO. MODE CD PLAY STANDBY IC2006 REF NO. MODE CD PLAY STANDBY REF NO. IC2007 MODE POWER ON STANDBY IC2008 REF NO. MODE CD PLAY STANDBY IC2008 REF NO. MODE CD PLAY STANDBY SA-AKX75P MAIN P.C.B.
  • Page 80 IC2502 REF NO. MODE CD PLAY 11.8 29.0 29.0 18.1 18.1 37.4 37.4 37.4 18.1 18.1 37.4 37.4 37.4 18.1 18.1 STANDBY 11.8 29.0 29.0 18.1 18.1 37.4 37.4 37.4 18.0 18.1 37.4 37.4 37.4 18.1 18.1 SA-AKX75P MAIN P.C.B.
  • Page 81 CD PLAY STANDBY IC8001 REF NO. MODE CD PLAY STANDBY REF NO. IC8001 MODE CD PLAY STANDBY IC8001 REF NO. MODE CD PLAY STANDBY IC8001 REF NO. MODE CD PLAY STANDBY REF NO. IC8001 MODE CD PLAY STANDBY SA-AKX75P MAIN P.C.B.
  • Page 82 Q2003 Q2004 REF NO. MODE POWER ON 15.3 15.3 15.3 STANDBY 15.3 15.4 15.3 Q2006 Q2008 Q2010 Q2012 Q2022 REF NO. MODE POWER ON 11.6 11.6 12.2 12.3 15.4 12.9 STANDBY 11.6 11.6 12.2 12.3 15.4 12.9 SA-AKX75P MAIN P.C.B.
  • Page 83 STANDBY 12.0 12.0 QR3102 QR3103 QR3104 REF NO. MODE CD PLAY STANDBY SA-AKX75P MAIN P.C.B. 16.1.6. Panel P.C.B. REF NO. IC6000 MODE CD PLAY -16.1 -14.1 -21.5 -21.5 -19.7 -21.5 -17.8 STANDBY -16.1 -14.1 -21.5 -21.5 -19.7 -21.5 -17.8 IC6000 REF NO.
  • Page 84 33.6 IC5899 REF NO. MODE POWER ON STANDBY Q5701 Q5711 Q5720 Q5721 Q5803 REF NO. MODE POWER ON 14.0 20.0 19.5 18.9 37.4 STANDBY 14.0 20.0 19.5 18.9 37.4 REF NO. Q5898 QR5810 MODE POWER ON STANDBY SA-AKX75P SMPS P.C.B.

  • Page 85: Waveform Table

    16.1.8. Waveform Table 3.8Vp-p(50nsec/div) 4Vp-p(50nsec/div) 2Vp-p(10usec/div) 3.8Vp-p(10usec/div) 1.8Vp-p(50usec/div) 3.2Vp-p(1usec/div) 3.2Vp-p(1usec/div) 3.2Vp-p(1usec/div) 36Vp-p(500nsec/div) 36Vp-p(1usec/div) 3.2Vp-p(1usec/div) 36Vp-p(500nsec/div) 36Vp-p(1usec/div) 36Vp-p(1usec/div) 3.2Vp-p(1usec/div) 36Vp-p(500nsec/div)

  • Page 87: Exploded View And Replacement Parts List

    (PANEL P.C.B.) CN6002 CN6500 IR6500 CN6001 VR6200 (REMOTE SENSOR P.C.B.) T6000 VR6100 *ZJ6000 *ZJ6400 (USB P.C.B.) (MUSIC PORT P.C.B.) *ZJ6300 CN6400 *ZJ6301 JK6301 SA-AKX75P-K NOTE: " * " PART IS NOT SUPPLIED / REF IS FOR INDICATION ONLY. CABINET DRAWINGS...
  • Page 88 T5701 CN3105 FP9003 *HEATSINK B CN2008 *HEATSINK A FP8201 FP8251 P5701 ZJ2000 T5751 CN5802 (SMPS P.C.B.) (BRS11C) CN7002 (CD INTERFACE P.C.B.) CN7001 S7201 SA-AKX75P-K NOTE: " * " PART IS NOT SUPPLIED / REF IS FOR INDICATION ONLY. CABINET DRAWINGS...
  • Page 89 17.1.2. Packaging ACCESSORIES BAG REMOTE CONTROL A1-1 R/C BATTERY COVER AC CORD SA-AKX75P OI BOOK FM INDOOR ANTENNA SB-AKX75P AM LOOP ANTENNA AUDIO CABLE POLYFOAM (TOP) SC-AKX75P-K POLYFOAM (BOTTOM) PACKAGING DRAWINGS...

  • Page 91: Mechanical Replacement Part List

    17.1.3. Mechanical Replacement Part List Safety Ref. Part No. Part Name & Qty Remarks Description Safety Ref. Part No. Part Name & Qty Remarks RHD30007-K2J SCREW Description RHD30111-31 SCREW RHD30119-S SCREW CABINET RHDX031008 SCREW CHASSIS RMNV0079-1 FL HOLDER RMNX0298 PCB SPACER L6FALEFH0030 FAN UNIT RKAX0042-K...
  • Page 92 Safety Ref. Part No. Part Name & Qty Remarks Description RGC0050-W VOLUME LIGHT REFLECTOR RMZ1362 INSULATION SHEET RMZ1363-1 INSULATION TUBE J0KD00000162 FERRITE CORE TRAVERSE DECK RAE1036Z-V TRAVERSE ASS'Y XTN2+6GFJ SCREW PACKING MATERI- RPG0E05 PACKING CASE RPN2516 POLYFOAM RPFX0198-1 MIRAMAT ACCESSORIES N2QAYB000636 REMOTE CONTROL A1-1...

  • Page 93: Electrical Replacement Part List

    17.2. Electrical Replacement Part List Safety Ref. Part No. Part Name & Qty Remarks Description IC2012 C0DBAYY01594 (E.S.D) Safety Ref. Part No. Part Name & Qty Remarks IC2501 C1AB00003986 (E.S.D) Description IC2502 C1AB00003986 (E.S.D) IC2503 C1AB00003986 (E.S.D) PRINTED CIRCUIT IC5701 C1ZBZ0004646 (E.S.D) BOARDS...
  • Page 94 Safety Ref. Part No. Part Name & Qty Remarks Safety Ref. Part No. Part Name & Qty Remarks Description Description Q5701 B1DEHU000002 TRANSISTOR (E.S.D) D8251 DA2J10100L DIODE (E.S.D) Q5711 B1ABCF000176 TRANSISTOR (E.S.D) DZ2000 B0JCPG000030 DIODE (E.S.D) Q5720 B1BABG000007 TRANSISTOR (E.S.D) DZ5701 D4EAY511A127 VARISTOR...
  • Page 95 Safety Ref. Part No. Part Name & Qty Remarks Safety Ref. Part No. Part Name & Qty Remarks Description Description L6301 J0JBC0000019 INDUCTOR JACKS L6302 J0JBC0000019 INDUCTOR LB2000 J0JBC0000134 INDUCTOR JK2000 K4ZZ02000103 JK FM ANT LB2006 J0JBC0000134 INDUCTOR JK2001 K2HA204B0153 JK AUX IN LB3201 J0JBC0000134...
  • Page 96 Safety Ref. Part No. Part Name & Qty Remarks Safety Ref. Part No. Part Name & Qty Remarks Description Description W1063 D0GFR00JA017 1/4W R2075 D0GB472JA008 4.7K 1/10W W1064 D0GBR00JA008 1/10W R2077 D0GB473JA008 1/10W W1065 D0GFR00JA017 1/4W R2078 D0GB101JA008 1/10W W1070 D0GFR00JA017 1/4W R2083...
  • Page 97 Safety Ref. Part No. Part Name & Qty Remarks Safety Ref. Part No. Part Name & Qty Remarks Description Description R2203 D0GBR00JA008 1/10W R3022 D0GBR00JA008 1/10W R2204 D0GBR00JA008 1/10W R3023 D0GBR00JA008 1/10W R2205 D0GDR00JA017 1/8W R3024 D0GBR00JA008 1/10W R2206 D0GB103JA008 1/10W R3025 D0GBR00JA008...
  • Page 98 Safety Ref. Part No. Part Name & Qty Remarks Safety Ref. Part No. Part Name & Qty Remarks Description Description R3659 D0GB100JA008 1/10W R6016 D0GB221JA007 1/10W R3660 D0GB100JA008 1/10W R6017 D0GB471JA008 1/10W R3661 D0GB100JA008 1/10W R6018 D0GB221JA007 1/10W R3662 D0GB100JA008 1/10W R6019 D0GBR00JA008...
  • Page 99 Safety Ref. Part No. Part Name & Qty Remarks Safety Ref. Part No. Part Name & Qty Remarks Description Description R8259 D0GB472JA065 4.7K 1/10W C2081 F1J1A106A043 10uF R8260 D0GB473JA065 1/10W C2082 F1H1H104B047 0.1uF R8261 D0GB101JA065 1/10W C2084 F1J1A106A043 10uF R8262 D0GB100JA065 1/10W C2085...
  • Page 100 Safety Ref. Part No. Part Name & Qty Remarks Safety Ref. Part No. Part Name & Qty Remarks Description Description C2648 F1H1H103B047 0.01uF C5703 F0CAF104A105 0.1uF C2649 F1H1H103B047 0.01uF C5704 F1BAF471A013 470pF C2650 F1H1H103B047 0.01uF C5705 F1BAF471A013 470pF C2651 F1H1H103B047 0.01uF C5706 F1BAF471A013...
  • Page 101 Safety Ref. Part No. Part Name & Qty Remarks Safety Ref. Part No. Part Name & Qty Remarks Description Description C6322 F1H1H104B047 0.1uF C8254 F1H1H153A885 0.015uF 50V C6323 F1H1H391A889 390pF C8255 F1H1H182A219 1800pF C6500 F1H1H101B052 100pF C8256 F1H1H102A219 1000pF C6501 F1H1H102A219 1000pF C8258...
  • Page 102 MMH1304...

Table of Contents
