Flight Display Systems FD932DVD-LP-2-AV Installation And Operation Manual
Low profile dvd player with audio/video inputs
Hide thumbs
Also See for FD932DVD-LP-2-AV:
- Installation and operation manual (19 pages) ,
- Installation and operation manual (26 pages)
Table of Contents
Advertisement
Quick Links
Advertisement
Table of Contents
Related Manuals for Flight Display Systems FD932DVD-LP-2-AV
Summary of Contents for Flight Display Systems FD932DVD-LP-2-AV
- Page 1 All manuals and user guides at all-guides.com Document Number: Rev: Revision Date: 07/19/2011 MAN – FD932DVD-LP-2-AV Page 1 of 19 FD932DVD-LP-2-AV Installation and Operation Manual Low-Profile DVD PLAYER with AUDIO/VIDEO INPUTS TECHNICAL SUPPORT 678-867-6717, or www.FlightDisplay.com...
- Page 2 Rev: Revision Date: 07/19/2011 MAN – FD932DVD-LP-2-AV Page 2 of 19 FD932DVD-LP-2-AV Low-Profile DVD PLAYER with AUDIO/VIDEO INPUTS © 2010 Flight Display Systems. All Rights Reserved. Flight Display Systems 1765 Grassland Parkway Alpharetta, GA 30004 678-867-6717 Phone 678-867-6742 Fax sales@flightdisplay.com www.flightdisplay.com...
-
Page 3: Table Of Contents
All manuals and user guides at all-guides.com Document Number: Rev: Revision Date: 07/19/2011 MAN – FD932DVD-LP-2-AV Page 3 of 19 Table of Contents General Information ........................4 1. Features ..........................4 2. Front View ..........................5 3. Cautions ..........................5 Specifications ..........................6 Installation Instructions ......................6 1. -
Page 4: General Information
Page 4 of 19 General Information The FD932DVD-LP-2-AV is designed as a replacement for the popular Flight Display Systems FD932DVD-4B. Like the FD932DVD-4B, AV inputs are provided on the front of the unit for connecting an external video or audio source. A switch on the front lets the user select between the DVD player and the auxiliary input. -
Page 5: Front View
Page 5 of 19 Front View FD932DVD-LP-2-AV Cautions In order to prevent damage to the FD932DVD-LP-2-AV, please follow the following precautions: Do not open and/or disassemble the unit. Do not attempt to insert a 3” disc (Mini-CD/Mini-DVD) Do not use sharp objects (such as pens, pencils, ice pick, etc.) to operate the... -
Page 6: Specifications
Power The FD932DVD-LP-2-AV requires 12VDC rated at a minimum of .50 Amps or 28VDC rated at a minimum of .25 Amps to function. The rated current of the equipment should be taken into consideration when selecting wire gauge. -
Page 7: Video Wiring Suggestions
All manuals and user guides at all-guides.com Document Number: Rev: Revision Date: 07/19/2011 MAN – FD932DVD-LP-2-AV Page 7 of 19 Video Wiring Suggestions Avoid routing video wiring parallel to: AC wiring Strobe wiring DC motor supply cables ... -
Page 8: Wiring Options
Audio – Right Signal <IN> * There are two ways to connect an auxiliary input device to the FD932DVD-LP-2-AV. 1) Connect RCA AV inputs on the front face of the unit. or 2) Connect pins 7, 8 & 9 on the DB9 to a Composite Video/Audio source. -
Page 9: Option 2: Fd932Dvd-4B Replacement
Document Number: Rev: Revision Date: 07/19/2011 MAN – FD932DVD-LP-2-AV Page 9 of 19 Option 2: Molex Connector and RCA Note: This unit is capable of running either 12VDC or 28VDC. To replace an existing FD932DVD-4B player, plug the existing Molex connector into the rear panel Molex socket. -
Page 10: Remote Eye
Page 10 of 19 Remote Eye The FD932DVD-LP-2-AV has an available remote IR sensor (“remote eye”) that can be used to accept remote signals in addition to the main unit. For instance, the remote eye can be mounted by a monitor, to allow both the monitor and the DVD player to be controlled by pointing the remote at the same spot. -
Page 11: Ship Kit Items
All manuals and user guides at all-guides.com Document Number: Rev: Revision Date: 07/19/2011 MAN – FD932DVD-LP-2-AV Page 11 of 19 Ship Kit Items Product FD932DVD-LP-2-AV Shipping Materials (1) SHIPKIT-DB09F-LATCH (1) REMOTE IR EXTENSION CABLE (2) MOUNTING BRACKETS ... -
Page 12: Operation Instructions
To power the unit up, press the power button. The unit will light up and display a Flight Display Systems logo on the display(s). Insert a CD or DVD into the slot, with label side up (away from the controls, if mounted vertically). The CD or DVD will load and automatically begin to play. -
Page 13: Remote Button Controls
All manuals and user guides at all-guides.com Document Number: Rev: Revision Date: 07/19/2011 MAN – FD932DVD-LP-2-AV Page 13 of 19 Remote Button Controls 1. Power/Source 2. Mute 3. FF/FR 4. FF/FR 5. Direction Buttons 6. Stop/Pause 7. Prev/Next 8. Prev/Next 9. -
Page 14: Set Region Codes/Region Codes
Document Number: Rev: Revision Date: 07/19/2011 MAN – FD932DVD-LP-2-AV Page 14 of 19 How to Set Region Code If the DVD player is set to a region other than that of the disk inserted, the DVD player stops and displays “WRONG REGION.” To change the region, remove the DVD, (make sure that you are not in the USB/Card reader mode) and key in 5-1-6-8 with the remote. -
Page 15: Auxiliary Panel Switch
Page 15 of 19 Auxiliary Panel Switch The FD932DVD-LP-2-AV has a toggle switch on the front panel. This switch allows the user to source either the DVD player or the AUX input connections located on the front & rear panels. Toggle the switch RIGHT to source the DVD player and LEFT to source the AUX inputs. -
Page 16: Technical Drawing
All manuals and user guides at all-guides.com Document Number: Rev: Revision Date: 07/19/2011 MAN – FD932DVD-LP-2-AV Page 16 of 19 Technical Drawing... -
Page 17: Troubleshooting
All manuals and user guides at all-guides.com Document Number: Rev: Revision Date: 07/19/2011 MAN – FD932DVD-LP-2-AV Page 17 of 19 Troubleshooting Video Noise Check for an incorrect ground in the installation wiring. See specific examples of video noise below, or visit http://flightdisplay.com/Grounding.pdf... -
Page 18: Technical Support
07/19/2011 MAN – FD932DVD-LP-2-AV Page 18 of 19 Technical Support Should you have any questions concerning this product or other Flight Display Systems products, please contact our Product Support representatives at (678) 867-6717. Flight Display Systems 1765 Grassland Parkway Alpharetta, GA 30004... -
Page 19: Log Of Revisions
All manuals and user guides at all-guides.com Document Number: Rev: Revision Date: 07/19/2011 MAN – FD932DVD-LP-2-AV Page 19 of 19 Log of Revisions Date Page Description 12/07/2010 Initial Release Removed product FD932DVD-LP-2-4B, Removed DB-15 Pinout, Updated product name descriptions, Updated cautions and remote...
