- Page 1 All manuals and user guides at all-guides.com Document Number: Rev: Revision Date: 02/24/2014 MAN – FD932DVD-LP-2-AV Page 1 of 26 FD932DVD-LP-2-AV Installation and Operation Manual Low-Profile DVD PLAYER with AUDIO/VIDEO INPUTS TECHNICAL SUPPORT 470-239-7421, or www.FlightDisplay.com...
- Page 2 Revision Date: 02/24/2014 MAN – FD932DVD-LP-2-AV Page 2 of 26 FD932DVD-LP-2-AV Low-Profile DVD PLAYER with AUDIO/VIDEO INPUTS © 2014 Flight Display Systems. All Rights Reserved. Flight Display Systems 6435 Shiloh Road, Suite D Alpharetta, GA 30005 678-867-6717 Phone 678-867-6742 Fax sales@FlightDisplay.com...
-
Page 3: Table Of Contents
All manuals and user guides at all-guides.com Document Number: Rev: Revision Date: 02/24/2014 MAN – FD932DVD-LP-2-AV Page 3 of 26 Table of Contents General Information .........................4 Features ..........................4 Additional Information ....................3 Front View/Cautions .......................5 Specifications ..........................6 Installation Instructions ......................6 Power ..........................6 Video Wiring Suggestions ......................7... - Page 4 All manuals and user guides at all-guides.com Document Number: Rev: Revision Date: 02/24/2014 MAN – FD932DVD-LP-2-AV Page 4 of 26 Troubleshooting ........................19 Technical Support ........................20 Instructions for Continued Airworthiness ................20 Warranty Information ......................20 Log of Revisions ........................21...
-
Page 5: General Information
This window will display all folders on the left and the folder contents will be displayed on the right. The FD932DVD-LP-2-AV will always play the first song on the SD media upon starting. It does not recognize the last song played when turned off. The FD932DVD-LP-2-AV can support SD cards up to 2GB in Size. -
Page 6: Front View/Cautions
Page 6 of 26 Front View FD932DVD-LP-2-AV Cautions In order to prevent damage to the FD932DVD-LP-2-AV, please follow the following precautions: Do not open and/or disassemble the unit. Do not attempt to insert a 3” disc (Mini-CD/Mini-DVD) Do not use sharp objects (such as pens, pencils, ice pick, etc.) to operate the... -
Page 7: Specifications
Power The FD932DVD-LP-2-AV requires 12VDC rated at a minimum of .50 Amps or 28VDC rated at a minimum of .25 Amps to function. The rated current of the equipment should be taken into consideration when selecting wire gauge. -
Page 8: Video Wiring Suggestions
All manuals and user guides at all-guides.com Document Number: Rev: Revision Date: 02/24/2014 MAN – FD932DVD-LP-2-AV Page 8 of 26 Video Wiring Suggestions Avoid routing video wiring parallel to: AC wiring Strobe wiring DC motor supply cables ... -
Page 9: Pinout For Db-9
All manuals and user guides at all-guides.com Document Number: Rev: Revision Date: 02/24/2014 MAN – FD932DVD-LP-2-AV Page 9 of 26 Wiring Pinout for DB-9 Part numbers for DB-9 connectors, manufactured by Amp: Connector P/N M24308/2-281 Crimp Contacts P/N M39029/63-368 DB9 Pinout & Female Mating Face Profile... - Page 10 MAN – FD932DVD-LP-2-AV Page 10 of 26 There are two ways to connect an auxiliary input device to the FD932DVD-LP-2-AV: 1) Connect RCA AV inputs on the front face of the unit. 2) Connect pins 6, 7, 8 & 9 on the DB9 to a Composite Video/Audio source.
-
Page 11: Rca Breakout Cable
Page 11 of 26 RCA Breakout Cable Flight Display Systems supplies an optional RCA breakout cable which allows for power on a DB9 connector with (3) RCA Connectors for Composite Video <OUT> (Yellow), Left Audio <OUT> (White), and Right Audio <OUT> (Red). - Page 12 All manuals and user guides at all-guides.com Document Number: Rev: Revision Date: 02/24/2014 MAN – FD932DVD-LP-2-AV Page 12 of 26 Signals - Composite (Yellow), Center Left Audio (White), Right Audio (Red) Shield Ground...
-
Page 13: Remote Eye
Page 13 of 26 Remote Eye The FD932DVD-LP-2-AV has an available remote IR sensor (“remote eye”) that can be used to accept remote signals in addition to the main unit. For instance, the remote eye can be mounted by a monitor, to allow both the monitor and the DVD player to be controlled by pointing the remote at the same spot. -
Page 14: Ship Kit Items
All manuals and user guides at all-guides.com Document Number: Rev: Revision Date: 02/24/2014 MAN – FD932DVD-LP-2-AV Page 14 of 26 SHIP KIT ITEMS PRODUCT – FD932DVD-LP-2 SHIPPING MATERIALS 1 – SHIPKIT-DB9F-LATCH 1 – REMOTE CONTROL 1- 650-00056-00 Optional RCA Breakout Cable... - Page 15 All manuals and user guides at all-guides.com Document Number: Rev: Revision Date: 02/24/2014 MAN – FD932DVD-LP-2-AV Page 15 of 26 1 – REMOTE IR EXTENSION CABLE 1 - FERRITE INSTALL 1 – FERRITE (240-2072-ND) Additional Shipping Materials (2) MOUNTING BRACKETS...
-
Page 16: Operation Instructions
(away from the controls, if mounted vertically). The CD or DVD will load and automatically begin to play. The FD932DVD-LP-2-AV 2 does not retain the volume setting when powered down. When powered off either from the front panel on/off button or from the aircraft, it powers to half volume. - Page 17 All manuals and user guides at all-guides.com Document Number: Rev: Revision Date: 02/24/2014 MAN – FD932DVD-LP-2-AV Page 17 of 26...
-
Page 18: Remote Button Controls
*The remote control for the FD932DVD-LP-2-AV supports two different sets of IR commands, but the unit itself only supports one. If the FD932DVD-LP-2-AV does not seem to be responding to remote control button presses, press either A or B to make the remote switch between IR command sets A and B. -
Page 19: Auxiliary Panel Switch
Page 19 of 26 Auxiliary Panel Switch The FD932DVD-LP-2-AV has a toggle switch on the front panel. This switch allows the user to source either the DVD player or the AUX input connections located on the front & rear panels. -
Page 20: Usb & Sd Card Video File Types
Document Number: Rev: Revision Date: 02/24/2014 MAN – FD932DVD-LP-2-AV Page 20 of 26 USB & SD Card Video File Types The FD932DVD-LP-2 is capable of playing videos from the USB port and SD card slot on the front of the unit. Only certain types of files and encoding types are supported. This is a hardware limitation of the DVD player chipset and additional support cannot be added with firmware updates. -
Page 21: Technical Drawing
All manuals and user guides at all-guides.com Document Number: Rev: Revision Date: 02/24/2014 MAN – FD932DVD-LP-2-AV Page 21 of 26 Technical Drawing... - Page 22 All manuals and user guides at all-guides.com Document Number: Rev: Revision Date: 02/24/2014 MAN – FD932DVD-LP-2-AV Page 22 of 26...
-
Page 23: Troubleshooting
All manuals and user guides at all-guides.com Document Number: Rev: Revision Date: 02/24/2014 MAN – FD932DVD-LP-2-AV Page 23 of 26 Troubleshooting Video Noise Check for an incorrect ground in the installation wiring. See specific examples of video noise below, or visit http://flightdisplay.com/Grounding.pdf... -
Page 24: Technical Support
If the return of the unit to the factory is required, an RMA number will be issued at that time. Flight Display Systems will, upon receipt of the failed hardware, remanufacture or replace the unit at our discretion. - Page 25 This warranty does not cover a defect or failure that has resulted from improper or unreasonable installation, use or maintenance, as determined by Flight Display Systems. This warranty is void if there is any attempt to disassemble or open this product without factory authorization.
- Page 26 All manuals and user guides at all-guides.com Document Number: Rev: Revision Date: 02/24/2014 MAN – FD932DVD-LP-2-AV Page 26 of 26 Revisions Log Date Page Description 12/07/2010 Initial Release Removed product FD932DVD-LP-2-4B, Removed DB-15 Pinout, Updated product name descriptions, Updated cautions and remote...
