GEYA GRT6-P Instruction Manual

Pulse output time relay
Instruction Manual
Technical parameters
Function
Supply terminals
Voltage range
Burden
Voltage range
Power input
Supply voltage tolerance
Supply indication
Time ranges
Time setting
Time deviation
Repeat accuracy
Temperature coecient
Output
Current rating
Switching voltage
Min.breaking capacity DC
Output indication
Mechanical life
Electrical life(AC1)
Reset time
Operating temperature
Storage temperature
Mounting/DIN rail
Protection degree
Operating position
Overvoltage cathegory
Pollution degree
solid wire max.1×2.5or 2×1.5/with sleeve max.1×2.5(AWG 12)
Dimensions
Weight
Standards
GRT6-P
General
■Applications
-It is used to delay and generate a pulse, which is used to delay the connection of
a load for a period of time.
■Function Features
-Separate delay time and pulse width setting can set di erent delay time.
-Time scale 0.1 s - 100 days.
-The delay time can be reset by shorting S-A1.
- With AC/DC 24V-240V ultra wide operating voltage speci cations are optional.
-Relay status is indicated by LED.
-1-MODULE,DIN rail mounting.
■Model and connotation
GRT6
GRT6-P1
Pulse output time relay
A1-A2
AC/DC 24-240V(50-60Hz)
AC 0.7-3VA/DC 0.5-1.7W
AC 230V(50-60Hz)
AC max.6VA/1.3W AC max.6VA/1.9W
-15%;+10%
green LED
0.1s-100days
potentionmeter
10%-mechanical setting
0.2%-set value stability
0.05%/℃,at=20℃(0.05%℉，at=68℉)
1×SPDT
10A/AC1
250VAC/24VDC
500mW
red LED
1×10
5
1×10
max.200ms
-20℃ to +55℃（-4℉ to 131℉）
-35℃ to +75℃（-22℉ to 158℉）
Din rail EN/IEC 60715
IP40 for front panel/IP20 terminals
any
90×18×64mm
1×SPDT:S240-53g,A230-65g
2×SPDT:S240-67g,A230-70g
EN 61812-1,IEC60947-5-1
P
Rated control supply voltage
S240:AC/DC24V-240V
Number of contacts
2:2×SPDT
Pulse output time relay
GRT6 Series
Panel Diagram
GRT6-P2
2×SPDT
Wiring Diagram
-1-
GEYA ELECTRICAL CO.,LTD
Add:Wenzhou Brige Industrial Zone,Beibaixiang Town,
Yueqing,Zhejiang,China 325603
Mobile:0086-13567770207
E-mail:sale@cngeya.com
Web:www.geya.net
Supply indication(green)
Un R
1h 10h
10m
Output indication(red)
1d
1m
10d
t1
30d
10s
100d
1s
Time1 range setting
40 50 60 70
30 80
Time1 setting
20 90
10
1h
10h
10m
1d
1m 10d
t2
Time2 range setting
30d
10s
100d
1s
40 50 60 70
Time2 setting
30 80
20 90
10
GRT6-P1
