WiFi time-control relay GRT8-WS
Instruction Manual
Technical parameters
Function
Supply terminals
Voltage range
Burden
Supply voltage tolerance
Supply indication
Time setting
Time deviation
Output
Min.breaking capacity DC
Output indication
Mechanical life
Electrical life(AC1)
Operating temperature
Storage temperature
Mounting/DIN rail
Protection degree
Operating position
Overvoltage cathegory
Pollution degree
Dimensions
Weight
Standards
Networking settings
1.Install App
You can scan this QR code to download Tuya Smart, or search for Tuya Smart
in the App store to download this App.
General
Applications
-It turns on and off the load periodically and regularly, and usually controls
household equipment such as lights and appliances.
Function Features
-Support access to Tuya's App Tuya smart.
-The on and off time of the load can be conveniently set through the App.
-On and off can be controlled manually.
-The cycle on / off can be set during the on time.
-1-MODULE,DIN rail mounting.
Model and connotation
GRT8
GRT8-WS
WiFi time-control relay
A1-A2
AC/DC 110-240V 50Hz
AC 0.09-3VA/DC 0.05-1.7W
-15%;+10%
green LED
APP
±30s
×
1 SPDT
16A/AC1
500mW
red LED
1×10
5
1×10
-20℃ ~ +55℃
-35℃ ~ +75℃
Din rail EN/IEC 60715
IP20
any
1×2.5mm 或 2×1.5mm
0.4N·m
90mm×18mm×64mm
62g
GB/T14048.5,IEC60947-5-1,EN 61812-1
-1-
GEYA ELECTRICAL CO.,LTD
Add:Wenzhou Brige Industrial Zone,Beibaixiang Town,
Yueqing,Zhejiang,China 325603
E-mail:sale@cngeya.com
Web:www.geya.net
WS
Rated control supply voltage:
N240:AC/DC110V-240V
WiFi time-control relay
GTS8 Series
Panel Diagram
WIFI status
indication
ON/OFF
WIFI configuration
Wiring Diagram
A1
~
( )
WIFI
~
( )
A2
Relay output
R
indicator
APP download
QR code
GRT8-WS
15
R
16
18
Advertisement
Related Manuals for GEYA GRT8-WS
Summary of Contents for GEYA GRT8-WS
- Page 1 GEYA ELECTRICAL CO.,LTD Add:Wenzhou Brige Industrial Zone,Beibaixiang Town, Yueqing,Zhejiang,China 325603 E-mail:sale@cngeya.com WiFi time-control relay GRT8-WS Web:www.geya.net Instruction Manual General Applications -It turns on and off the load periodically and regularly, and usually controls household equipment such as lights and appliances.
- Page 2 2. You can press and hold the button for 5 seconds at any time, and the device will re-enter the WIFI configuration state. At this point, you can add this device again through the App. Online status Distribution network status GRT8-WS 15 16 18 Disposal of Electrical Waste Caution All electrical waste should be The products must be installed by qualified electricians.
