TERMHD0400*
TERMHD0401*
TERMHD0402*
L FE
4
Current
Model
Power Supply
(mA) Max.
TERMHD0400***
12-30V/DC
902mA
459mA
TERMHD0401***
48V/DC
195mA
TERMHD0402***
85-250V AC/DC 50Hz
Sound Intensity
Sound Intensity
Sound Intensity
Melody
Cable Color
(dB max) (10cm)
(dB max) (100cm)
1
Red
123
113
2
Green
128
112
3
Yellow
130
109
127
113
4
Blue
5
White
123
107
6
Orange
128
113
7
Brown
128
119
8
Misuse
126
117
Model
Weight
Color
TERMHD0400***
3534gr
(1) Red
(2) Green
TERMHD0401***
3534gr
(3) Yellow
(4) Blue
TERMHD0402***
3590gr
(5) White
T.E.R. Tecno Elettrica Ravasi Srl
a socio unico
Advertisement
Related Manuals for TER TERMHD0400 Series
Summary of Contents for TER TERMHD0400 Series
- Page 1 Model Weight Color TERMHD0400*** 3534gr (1) Red TERMHD0400* (2) Green TERMHD0401* TERMHD0401*** 3534gr (3) Yellow TERMHD0402* (4) Blue TERMHD0402*** 3590gr (5) White Current Model Power Supply (mA) Max. TERMHD0400*** 12-30V/DC 902mA 459mA TERMHD0401*** 48V/DC 195mA TERMHD0402*** 85-250V AC/DC 50Hz L FE Sound Intensity Sound Intensity Sound Intensity...
- Page 2 YEDEK PARÇALAR WIRING INSTRUCTION SPARE PARTS TECHNICAL DIAGRAM WIRING DIAGRAM 12-30V/DC - 48V/DC 1. LIGHT & MELODY TERMSP0700 Melody&Light Wires: Red-Green-Yellow-Blue-White-Orange-Brown GREEN 2. LIGHT & MELODY Signal Wires: Black Power Supply Cable: 2x0,50 TTR YELLOW 3. LIGHT & MELODY (Red-Black for 12-24V AC/DC and 48V DC Blue-Brown for 40-250V AC/DC) BLUE 4.
