TERMHD0700*
TERMHD0701*
TERMHD0702*
4
SMD
LED
Current
Model
Power Supply
(mA) Max.
TERMHD0700***
12-30V AC/DC
650mA
TERMHD0701***
48V AC
310mA
120mA
TERMHD0702***
85-250V AC/DC 50Hz
Sound Intensity
Sound Intensity
Sound Intensity
Melody
Cable Color
(dB max) (10cm)
(dB max) (100cm)
-
Empty
-
-
1
Red
127
121
2
Green
121
110
3
Dark Blue
118
107
4
Purple
126
117
5
Light Blue
120
105
6
Yellow
122
110
7
White
126
117
Model
Weight
TERMHD0700***
1600gr
TERMHD0701***
1600gr
TERMHD0702***
1900gr
T.E.R. Tecno Elettrica Ravasi Srl
a socio unico
Advertisement
Related Manuals for TER TERMHD0700 Series
Summary of Contents for TER TERMHD0700 Series
- Page 1 Model Weight TERMHD0700*** 1600gr TERMHD0700* TERMHD0701*** 1600gr TERMHD0701* TERMHD0702*** 1900gr TERMHD0702* Current Model Power Supply (mA) Max. TERMHD0700*** 12-30V AC/DC 650mA TERMHD0701*** 48V AC 310mA 120mA TERMHD0702*** 85-250V AC/DC 50Hz Sound Intensity Sound Intensity Sound Intensity Melody Cable Color (dB max) (10cm) (dB max) (100cm) Empty Green...
- Page 2 KABLOLAMA TALIMATLARI WIRING DIAGRAM WIRING INSTRUCTION TECHNICAL DIAGRAM LIGHT MODE SELECTION 12-30V AC/DC - 48V AC Melody&Light Wires: Red-Blue-Green-Violet-Light Blue-Yellow-White 1. LIGHT & MELODY Signal Wires: Black Caution Of Power Supply Cable: 2x0,50 TTR BLUE 2. LIGHT & MELODY High Voltage (Red-Black for 12-24V AC/DC and 48V AC Blue-Brown for 40-250V AC/DC) GREEN...
