TERMHD0600*
TERMHD0601*
TERMHD0602*
L FE
4
Current
Model
Power Supply
(mA) Max.
TERMHD0600***
12-30V/DC
1520mA
456mA
TERMHD0601***
48V/DC
210mA
TERMHD0602***
85-250V AC/DC 50Hz
Sound Intensity
Sound Intensity
Sound Intensity
Melody
Cable Color
(dB max) (10cm)
(dB max) (100cm)
1
Red
128
121
2
Green
123
119
3
Yellow
121
119
4
Blue
125
117
5
White
117
107
6
Orange
128
117
7
Brown
117
105
8
Misuse
123
115
Model
Weight
Color
TERMHD0600***
3310gr
(1) Red
(2) Green
TERMHD0601***
3310gr
(3) Yellow
(4) Blue
TERMHD0602***
3360gr
(5) White
T.E.R. Tecno Elettrica Ravasi Srl
a socio unico
