- Page 1 All manuals and user guides at all-guides.com Service Guide SP-S200 SERVICE GUIDE KYE SYSTEMS CORP. SP-S200 Version : 1.0 Page 1 of 15...
-
Page 2: Revision History
All manuals and user guides at all-guides.com Service Guide SP-S200 Version : 1.0 Revision History Version Date Change 05/29/2007 Version : 1.0 Page 2 of 15... -
Page 3: Table Of Contents
All manuals and user guides at all-guides.com Service Guide SP-S200 Table of Contents Revision History …………………………………………………………………….2 Table of Contents ……………………………………………………………………3 Getting Started ………………………………………………………………………4 Conventions Used in this Guide ……………………………………….4 Safety Precautions ……………………………………………………..4 Chapter 1. How to Handle Defective Returns……………………………………..5 1.1 Overview …………………………………………………………..5 1.2 Problems …………………………………………………………...6... -
Page 4: Getting Started
All manuals and user guides at all-guides.com Service Guide SP-S200 Getting Started Conventions Used in this Guide Pay Special Attention : Instructions that are important to remember and may prevent mistakes . Caution : Information that, if not followed, may result in damage to the product . -
Page 5: Chapter 1. How To Handle Defective Returns
All manuals and user guides at all-guides.com Service Guide SP-S200 Chapter 1. How to Handle Defective Returns 1.1 Overview Receiving Defective speakers from Customers Verifying problems Proceeding necessary tests Function NG Analyzing possible malfunction causes Deciding & proceeding the Function NG... -
Page 6: Problems
All manuals and user guides at all-guides.com Service Guide SP-S200 1.2 Problems Item Problem Description 1.2.1 One or more channels no sound 1.2.2 Power LED (indicator) no light 1.2.3 Volume no function Version : 1.0 Page 6 of 15... - Page 7 All manuals and user guides at all-guides.com Service Guide SP-S200 Attention Please follow the numbered sequence marked within parenthesis given in individual Flow chat, in that this is the best-recommended sequence to rectify the problems. 1.2.1 One or more channels no sound...
- Page 8 All manuals and user guides at all-guides.com Service Guide SP-S200 1.2.2 Power LED (indicator) no light Power LED (indicator) no light Problem Defective SW, R1, Ac cord of transformer Analyzer and Power switch or LED defective C1, D1~D4 disconnected or defective...
-
Page 9: Chapter 2. Specifications
All manuals and user guides at all-guides.com Service Guide SP-S200 Chapter 2. Specifications NO. Description Unit Specifications ≧ 3 Out Power at THD 10% 400 ± 50 Sensitivity Freq. Response (Ref:-3dB) Hz 29Hz ~ 20KHz dB ≧ 40 Separation dB ≧ 50 S/N ratio mV ≦... -
Page 10: Chapter 3. Block Diagram
All manuals and user guides at all-guides.com Service Guide SP-S200 Chapter 3. Block Diagram Volume R.CH Speaker Power Increase Amplifier AUDIO IN Volume L.CH Speaker Decrease Power AC IN Conditioner Version : 1.0 Page 10 of 15... -
Page 11: Chapter 4. Exploded View
All manuals and user guides at all-guides.com Service Guide SP-S200 Chapter 4. Exploded View Host Version : 1.0 Page 11 of 15... - Page 12 All manuals and user guides at all-guides.com Service Guide SP-S200 Satellite Version : 1.0 Page 12 of 15...
-
Page 13: Chapter 5. Part List
3 SP-S200/Body-230V-EU(Silver cloth) 13-101-03 4 SP-S200/Body-240V-AU 13-101-04 5 SP-S200/Body-240V-UK 13-101-05 6 Loud Speaker 2.5” 4ohm 3W E1049-23 7 Rubber pad, SP-S200 13-100-01 8 PCBA, SP-S200 13-101-06 9 IC, SJ2025 E1065-2A 10 Transformer, 120V:10.7VAC & 0.8A E1074-10R 11 Transformer, 230V:10.7VAC & 0.8A E1074-9R 12 Transformer, 240V:10.7VAC &... -
Page 14: Chapter 6. Schematic Diagram
All manuals and user guides at all-guides.com Service Guide SP-S200 Chapter 6. Schematic Diagram Version : 1.0 Page 14 of 15... -
Page 15: Chapter 7. Important Notes
All manuals and user guides at all-guides.com Service Guide SP-S200 Chapter 7. Important Notes 7.1 Packing Requirement for Sending the PCB Assembly by Post PCB assembly is a kind of sophisticated electronic circuit board. Well packing will be required when sending them by post.
