- Page 1 Terra Aria monochromatic and rgbw inground spot series User manual Manuale d’uso...
-
Page 2: Ground Level
IMPORTANT BEFORE ASSEMBLING the TERRA / IMPORTANTE PRIMA DEL MONTAGGIO del TERRA ground level xture DRAINAGE PLASTIC CASE be sure to create su cient drainage around the plastic case... - Page 3 DRS MENU’ LIST / ELENCO MENU DRS DMX CHANNEL LIST / LISTA DEI CANALI DMX PHYSICAL / DIMENSIONI WARRANTY / GARANZIA CE STANDARD / DICHIARAZIONE CE TERRA POB version ARIA POB version TERRA 24V version ARIA 24V version rel.3-06/24 - Studio Due...
- Page 4 ........................ENG SAFETY INFORMATION (service personnel) IMPORTANT ! READ ALL CAUTIONS AND WARNINGS PRIOR TO OPERATE THIS EQUIPMENT. INSTRUCTION TO PREVENT INJURY OR DAMAGE DUE TO ELECTRIC SHOCK, FIRE, MECHANICAL HAZARDS, DANGEROUS MATTERS. • PROTECTION AGAINST DANGEROUS MATTERS At the end of its life, must be collected separately. It shouldn’t be thrown as urban waste and neither released in the environment. It must be collected from the nearest special waste collection point or consigned to your dealer that provides the service.
- Page 5 ........................ENG INTRODUCTION CHECK THAT THE FIXTURE HAS NOT BEEN DAMAGED DURING TRANSPORT. IF IT HAS BEEN DAMAGED OR IT DOES NOT WORK, ADDRESS THE SELLER. WHETHER THE FIXTURE HAS BEEN SHIPPED TO YOU DIRECTLY, PLEASE CONTACT THE SHIPPING COMPANY. ONLY THE CONSIGNEE (PERSON OR COMPANY) CAN CLAIM FOR THESE DAMAGES.
- Page 6 TERRA L5 POB RGBW (it. 210110) ........................ENG / ITA TECHNICAL FEATURES / CARATTERISTICHE TECNICHE TECHNICAL FEATURES TERRA - ARIA L5 POB (On Board Power Supply) Technical Specification LED type RGBW5050MULTICHIP Number of LEDs LED expected lifetime (hrs) 50000 Lumen MAX 1815 Red lumen (lm) Green lumen (lm)
- Page 7 TERRA L5 24V RGBW (it. 210160) ........................ENG / ITA TECHNICAL FEATURES / CARATTERISTICHE TECNICHE TECHNICAL FEATURES TERRA - ARIA L5 24V Technical Specification LED type RGBW5050MULTICHIP Number of LEDs LED expected lifetime (hrs) 50000 Lumen MAX 1815 Red lumen (lm) Green lumen (lm) Blu lumen (lm) White lumen (lm)
- Page 8 Studio Due ........................ENG / ITA Sede operativa: Strada Poggino, 100 - 01100 Viterbo (I) Sede operativa: Strada Poggino, 100 - IT14078001006 TECHNICAL FEATURES / CARATTERISTICHE TECNICHE TERRA WL5 POB WB (it. 210430) TERRA WL5 POB M (it. 210310) TECHNICAL FEATURES TERRA - ARIA WL5 POB WB and Monochromatic (On Board Power Supply) 2700K 6500K warm neutral cool...
- Page 9 Studio Due Sede operativa: Strada Poggino, 100 - 01100 Viterbo (I) ........................ENG / ITA IT14078001006 TECHNICAL FEATURES / CARATTERISTICHE TECNICHE TERRA WL5 POB PLUG-IN M (it. 210300) TECHNICAL FEATURES TERRA - ARIA WL5 24V Monochromatic warm neutral cool Technical Specification LED type WHITE 2700 K WHITE 4000 K...
- Page 10 MAINS connection cable BROWN / 100/240Vac - 50-60Hz SHIELD / GND RED / DMX - BLUE / NEUTRAL ORANGE / DMX + GREEN-YELLOW / GROUND TERRA POB FIXTURE (230V) to the fixture MAIN IN to other fixture MAINS MAINS 3x1mm...
- Page 11 3x1mm+3x0,25mm ORANGE / DMX + BLACK / 0V cable 60cm RED / +48V GREEN-YELLOW / GROUND 20-48VDC other fixture TERRA POB 24V TERRA POB 24V with connection box DMX LINE other fixture 20-48VDC+DMX CONNECTION commercial > IP65 connection box NOT INCLUDED...
- Page 12 190,00 20-48VDC+DMX cable to POWER SUPPLY 20-48VDC+DMX max 10mt with n.10 fixture connected and DMX line 3x1mm+3x0,25mm cable TERRA POB 24V TERRA POB 24V TERRA POB 24V TERRA POB 24V TERRA POB 24V TERRA POB TERRA POB with connection box...
- Page 13 ........................ENG / ITA EXAMPLE OF CONNECTION DMX CONTROLLER - FIXTURES / ESEMPIO DI COLLEGAMENTO CENTRALINA - FARI Address Address Address Address Address Address Address Address set-up 4ch set-up 4ch set-up 4ch set-up 4ch set-up 4ch set-up 4ch set-up 4ch set-up 4ch =C001 =C005...
-
Page 14: Main Power
........................ENG SETUP AND CONFIGURATION BY DRS - DMX REMOTE SETUP The DRS it’s a new concept of professional LED Lighting fixtures suitable for outdoor permanent installations. The LED Lighting fixtures can be driven via DMX through a specific electronic device, the DRS DMX Remote Setup, that grant the possibility to set up the scenarios and the games remotely. - Page 15 ........................ENG SETUP AND CONFIGURATION BY DRS - DMX REMOTE SETUP dimmable version only / solo versione dimmerabile To make the set-up of the various fixture parameter, proceed as follow: •Disconnect the fixture to set-up from the other DMX/RDM devices •...
- Page 16 ........................ENG / ITA DRS MENU’ LIST / ELENCO MENU DRS Switching on the fixture you can see the model and the software version. For example: All’accensione, viene visualizzato il modello di apparecchio e la versione software. Per esempio: --> TerP --> 1-00 - than it’s shown the fist menu / poi viene visualizzato il primo menu Address (Addr) Set the DMX channel address / Imposta il canale DMX...
- Page 17 Test (tESt) Enables the test of the fixture and execute a factory program to check the right functioning/ Abilita il test dell’apparecchio ed esegue un programma di fabbrica per verificarne il funzionamento. (T-ON) > Select the value t-on with the UP/DOWN buttons. T-on is flashing: test in progress. Press any key to exit. >...
- Page 18 DMX CHANNEL LIST / LISTA DEI CANALI DMX 8 BIT FUNCTION GREEN BLUE WHITE FLASH 0,4Hz / 25Hz RAINBOW - FLASH 0,4Hz / 25Hz OPEN STROBE 128 -255 2 -127 0 - 1 DIMMER LED FADE FAST - 0,1 sec. SLOW 0 = CUT TIME...
- Page 19 DMX CHANNEL LIST / LISTA DEI CANALI DMX 8 BIT FUNCTION GREEN BLUE WHITE WHITE BALANCE DMX CHANNEL LIST / LISTA DEI CANALI DMX WHITE BALANCE 8 BIT FUNCTION BALANCED 16 - 255 0 - 15 NORMAL WHITE DIMMER FLASH 0,4Hz / 25Hz RAINBOW - FLASH 0,4Hz / 25Hz OPEN STROBE...
- Page 20 ........................ENG / ITA DMX CHANNELS MONOCHROMATIC / CANALI DMX MONOCROMATICO - (*) DMX line for Dimmable version. (setting 3ch or 1ch) -------------------------------------------------------------------------------------------------------------- - (*) linea DMX versione Dimmerabile. (settaggio 3ch o 1ch) 8 BIT FUNCTION DIMMER FLASH 0,4Hz / 25Hz RAINBOW - FLASH 0,4Hz / 25Hz OPEN STROBE...
- Page 21 PHYSICAL / DIMENSIONI 190,00 190,00 190,00 TERRA POB 24V TERRA POB 24V TERRA POB with connection box 0° ARIA POB ARIA POB 24V rel.3-06/24 - Studio Due...
-
Page 22: Warranty Card
WARRANTY / GARANZIA Warranty CARD Company name: ..........................Mr./Mrs./Miss: ..........................Address: ............................Tel. or E-mail : ..........................Dealer: ..................... SALE CONDITIONS 1) Price quoted are not inclusive of lamp and package. Package charge is 2% on the net price for all the items. These prices should be subject to possible variations for eventual rises of production costs or duties. - Page 23 CE STANDARD / DICHIARAZIONE CE Studio Due Doc. 2021 REV 1 - 09/21 TERRA and ARIA POB and 24V series IP67 s.r.l. 10/2021 Dichiarazione di conformità Declaration of conformity La ditta: STUDIO DUE The firm: Strada Poggino, 100 01100 VITERBO ITALY dichiara sotto la propria responsabilità...
