- Page 1 DS4101 Installation Guide DS4101 Installation Guide...
- Page 2 T T able of Contents able of Contents Revision History ........................1 DS4101 Installation Guide ....................2 Preface ........................... 3 Product Overview ......................... 4 Hardware Overview ......................7 PSU Removal ........................8 Fan Removal ........................10 Ground Lug Installation ....................12 Regulatory Information .....................
- Page 3 Revision Hist vision Histor ory y This section lists the summary of changes corresponding to each release. Release Release Date Date Change Summar Change Summary y 1.0.0 7/2024 New document 1.1.0 12/2024 Added Revision History 1.2.0 3/2025 Added Ground Lug Assembly (GLA) installation instructions...
- Page 4 Disclaimer Copyright © 2025 by Celestica. All Rights Reserved. "Celestica" refers to Celestica Inc. and its subsidiaries. For additional information, please visit our website at www.Celestica.com. All trademarks, trade names, service marks, and logos mentioned belong to their respective owners.
-
Page 5: Intended Audiences
Pr Preface eface Document Scope This document provides a detailed overview of the DS4101 data center switch's design features and offers guidance on its use. Intended Audiences ▪ System architects ▪ Firmware engineers ▪ System application engineers Document Conventions The following table describes various types of notes used within this installation guide. -
Page 6: Product Specifications
Pr Product Ov oduct Over erview view This document describes the installation process of the DS4101 data center switch. Features ▪ Interfaces: 32 OSFP 800Gbps ports, 10GbE / 25GbE / 40GbE / 50GbE / 100GbE / 200GbE / 400GbE capable, two 10GbE SFP+ ports, one 1GbE RJ45 management port, one RJ45 Serial Console Port, one USB 3.0 Type A Port... - Page 7 T T ype DS4101 DS4101 back) Operating Relative Humidity 5% - 85% Figur Figure 1. e 1. DS4101 F DS4101 Fr r ont View ont View Figur Figure 2. e 2. DS4101 Side View DS4101 Side View...
- Page 8 Figur Figure 3. e 3. DS4101 Rear View DS4101 Rear View Figur Figure 4. e 4. DS4101 Rear Side View DS4101 Rear Side View...
- Page 9 This section describes key hardware components of the DS4101 data center switch. Field Replaceable Units (FRUs) The DS4101 is designed with redundancy and availability in mind. DS4101 comes with 6+1 redundant fans and 1+1 redundant, hot swappable 2000W PSUs. The following sections cover...
- Page 10 PSU Remo PSU Remov v al al Pr Procedur ocedure e 1 1 Press the PSU latch to the left to release the PSU. 2 2 Use handle to pull PSU straight out of chassis.
- Page 11 3 3 Example of PSU when removed. 4 4 Reverse the steps to reinstall.
- Page 12 F F an Remo an Remov v al al Pr Procedur ocedure e 1 1 Press the blue latch release the fan tray from the chassis. 2 2 Use handle to pull straight back and remove the fan.
- Page 13 3 3 Example of fan when removed. 4 4 Reverse the steps to reinstall.
- Page 14 Context Context The ground lug assembly (GLA) is used to safely and effectively ground the DS4101's chassis to the rack in which it is installed. This is an important task in the overall installation process of the data center switch.
- Page 15 2 2 Verify the part numbers as listed within image.
- Page 16 CAUTION: UTION: The image shows the ground lug assembly and the grounding wire terminal. The terminal must have a #10 AWG wire (not shown) crimped within it. The other end of the grounding wire must be securely attached to an unpainted metal surface on the rack.
- Page 17 4 4 Remove both nuts and washers from grounding bracket.
- Page 18 5 5 Attach the grounding wire terminal and reinstall the washers and nuts.
- Page 19 6 6 Tighten both nuts to 4.5 inch/pounds (+/- 0.5 in/lb).
- Page 20 7 7 The GLA installation process is complete.
- Page 21 8 8 When crimping the 10AWG cable to the lug, remove 0.38" of shielding to expose the metal wire. Slide it into the lug and ensure metal-to-metal contact before crimping. The terminal must have a #10 AWG wire (not shown) crimped within it. CAUTION: UTION: ...
- Page 22 Any modifications made to this device that are not approved by Celestica may void NOTE: ...
- Page 23 In accordance with European Directive 2012/19/EU on Waste Electrical and Electronic Equipment (WEEE), the presence of the above symbol on the product or on its packaging indicates that this item must not be disposed of in the normal unsorted municipal waste stream. Instead, it is the user's responsibility to dispose of this product by returning it to a collection point designated for the recycling of electrical and electronic equipment waste.
-
Page 24: Contact Information
Customers can register and request support (as well as search information in the knowledge base) at: https://customersupport.celestica.com/csm In case there are any questions or issues using the customer portal visit: https://www.celestica.com/contact-us. For immediate questions, please feel free to call your responsible account manager.
