- Page 1 DS3000 Installation Guide DS3000 Installation Guide...
-
Page 2: Table Of Contents
T T able of Contents able of Contents DS3000 Installation Guide DS3000 Installation Guide ....................................1 1 Pr Preface eface ....................................................2 2 Pr Product Ov oduct Over erview view ............................................4 4 Hardwar dware Ov e Over erview view ....................... - Page 3 Installation Guide Disclaimer Copyright © 2024 by Celestica. All Rights Reserved. The term “Celestica” refers to Celestica Inc. and/or its subsidiaries. For more information, go to www.Celestica.com. All trademarks, trade names, service marks, and logos referenced herein belong to their respective companies.
-
Page 4: Pr Preface Eface
Pr Preface eface This guide covers the installation and basic setup of the DS3000 Ethernet switch. Every effort has been made to ensure the accuracy and validity of this guide. Any updates of this guide are subject to change without notice. - Page 5 T T ype Gener Generaliz alized Definition ed Definition Indicates a hazardous situation that if not D D ANGER: ANGER: avoided, will result in death or serious injury.
-
Page 6: Pr Product Ov Oduct Over Erview View
Pr Product Ov oduct Over erview view The DS3000 is an advanced distribution layer Ethernet switch for data center leaf and spine applications. Ideal use cases include campus, enterprise, and IP metropolitan networks. Product Specifications T T ype DS3000 DS3000... - Page 7 The back panel of DS3000 includes dual500 W power supplies (providing redundancy), and four fans. Port Description DS3000 provides 32 QSFP28 ports, 1 SFP+ port and one RJ45 Ethernet port. The description is in the following: T T able 1.
- Page 8 ▪ 7M 24AWG Status LEDs The indicator LEDs on front panel of the DS3000 are 32 QSFP28 and 1 SFP+ port indicator LEDs, two power supply indicator LEDs and a system automatic diagnostic LED. They are described in the following table.
- Page 9 F F r r ont P ont Panel anel Indicat Indicator LED or LED LED Status LED Status Description Description Identifier Identifier (blinking) blinking / Minor alarm: 1Hz blinking System STAT Green / Amber Default CPLD alternating (4Hz) setting Green / Amber For systems alternating (1Hz) running ONIE...
- Page 10 T T able 4. able 4.Description of P Description of Por ort Indicat t Indicator LED or LED Indicat Indicator LED or LED Status Status Description Description Indicator LED of First Green The port and the link are active in 100 GbE mode, QSFP28 port Blinking and there is link activity.
-
Page 11: Har Hardwar Dware Ov E Over Erview View
5. Drive replacement maximum time is 10 minutes. P P ower Supply Unit (PSU) ower Supply Unit (PSU) Overview The DS3000 storage enclosure is powered by two 500 W redundant power supply units (PSUs) with the following features. ▪ Four 500 W ▪ 12 V +/- 5% ▪... - Page 12 Figur Figure 1. e 1. PSU View PSU View The PSU model displayed in this document may vary from the actual product. This NOTE: includes possible differences in efficiency, power output, connection type, LED(s) and location(s), and other specifications. P P ower Supply Condition ower Supply Condition LED State...
- Page 13 (OCP), over voltage protection (OVP), fan failure Power supply firmware updating 2 Hz Blink Green AC Power Cord The AC power sockets are located on the rear of the chassis. Contact Celestica if you want to use other types of power cords. CAUTION: UTION: For products with multiple power cords, all power cords must be disconnected ...
-
Page 14: Psu Removal
PSU Assembly Figur Figure 2. e 2. PSU Ov PSU Over erview view PSU Remo PSU Remov v al al Pr Procedur ocedure e 1 1 Rotate handle 90 degrees as shown. -
Page 15: Psu-Installation
2 2 Press latch 3 3 While pressing latch, use handle to pull PSU from chassis. PSU-Installation PSU-Installation Pr Procedur ocedure e 1 1 Rotate handle to a 90 degree angle as shown. -
Page 16: F F An Module An Module
2 2 Press latch and handle to slide PSU into chassis. 3 3 Rotate handled 90 degrees to close. F F an Module an Module Fan Overview The DS3000 enclosure houses five (5) fan modules in the back of the chassis for drive cooling. -
Page 17: Fan Removal
Figur Figure 3. e 3. F F an Module - F an Module - Fr r ont and Rear View ont and Rear View Fan Module LED Each fan module includes one status LED. Figur Figure 4. e 4. F F an Module Assembly T an Module Assembly Top View op View Fan Fault LED (Amber) - Page 18 2 2 Rotate handle to disengage locking mechanism.
-
Page 19: Fan Installation
3 3 Use handle to pull fan module from chassis. F F an Installation an Installation Pr Procedur ocedure e 1 1 Ensure fan module is aligned with the chassis fan slot and slide into place. - Page 20 2 2 Rotate handle into position. A 'click' may be audible when latch engages.
-
Page 21: Saf Safety Pr Ety Precautions Ecautions
The laser may hurt and/or damage your eyes. ▪ Do not install, move or open the DS3000 or its modules when the device is connected to power. Doing so may damage equipment and cause serious burns to skin. -
Page 22: P P Ower Ower
P P ower ower Depending on the type of power system your device has, the following symbols may be used. On - On - Connects power to the system. This can be AC or DC power depending on product and model. Off - Off - Disconnects power to the system. - Page 23 NOTE: This symbol is used when multiple power supplies are installed in a system. This warning label is typically found on the back of the device near the PSU. Power Connection Installation of this equipment must comply with local and regional electrical regulations governing the installation of information technology equipment by licensed electricians.
-
Page 24: Installation Notice
Installation Notice Installation Notice To ensure the proper operation of DS3000 and your physical security, please read carefully the following installation guide. ▪ Read through the installation instruction carefully before operating on the system. Make sure the installation materials and tools are prepared. And make sure the installation site is well prepared. -
Page 25: Electr Electrostatic Dischar Ostatic Discharge Ge
Electr Electrostatic Dischar ostatic Discharge Static electric discharges can cause damage to internal circuits, even the entire switch. Please read and familiarize yourself with the following guidelines to avoid ESD damage. ▪ Ensure proper earth grounding of the device. ▪ Perform regular cleaning to reduce dust. ▪... -
Page 26: Anti-Inter Anti-Interf F Er Erence Ence
Anti-inter Anti-interf f er erence ence All sources of interference, whether from the device/system itself or the outside environment, will affect operations in various ways, such as capacitive coupling, inductive coupling, electromagnetic radiation, common impedance (including the grounding system) and cables/ lines (power cables, signal lines, and output lines). -
Page 27: Chassis Installation
Chassis Installation Chassis Installation DS3000 is designed to be installed in a standard 19'' square hole, four post rack. The bracket kit is only for 19 inch (483mm) wide, standard square hole racks, with a depth ranging from 22 inches ~ 33.5 inches (558mm ~ 850mm) as measured from rack post to rack post. This chapter covers the tools and procedures necessary to correctly and safely install the DS3000 Ethernet switch. -
Page 28: Installing The Chassis
on the rack must be deployed. If a standard 19'' rack is not available, DS3000 can be placed on a clean, stable, and level surface. Leave a clearance of 100mm (~4 inches) around the chassis for ventilation. Do not place anything on top of the chassis. - Page 29 NOTE: The following illustrations may display a different product. However, the installation process is universal to all Celestica rack-mountable products. Pr Procedur ocedure e 1 1 Attach the two outer brackets with M4 screws provided in the accessory kit.
- Page 30 Figur Figure 5. e 5. Secur Secure Br e Brack acket t et to Chassis o Chassis Figur Figure 6. e 6. Inner Rail Br Inner Rail Brack acket Installed t et Installed to Chassis o Chassis 4 4 Push the chassis with the outer bracket locked in step 1 above from the front side by one person, and push the inner bracket into the outer brackets (sleeve) slot on the chassis...
- Page 31 from the rear side by another person at the same time, until guide pin (detail 1) and inner bracket guide pin (detail 3) fit in rack square holes. Then, lock them with M6 screws (PH#3 slotted screwdriver). 5 5 Press chassis and inner bracket until M6 screws fully lock. 6 6 Save enough space around the switch for good air circulation.
-
Page 32: Contact Information
Customers can register and request support (as well as search information in the knowledge base) at:https://customersupport.celestica.com/csm In case there are any questions or issues using the customer portal visit: https://www.celestica.com/contact-us. For immediate questions, please feel free to call your responsible account manager.
